| Virtual LAN features |
|---|
| VLAN support |
Yes |
| Virtual LAN features |
Private VLAN |
| Technical details |
|---|
| Product colour |
Black |
| Housing material |
Aluminum |
| Management features |
|---|
| ARP inspection |
Yes |
| Switch type |
Managed |
| Ports & interfaces |
|---|
| Basic switching RJ-45 Ethernet ports quantity |
8 |
| Basic switching RJ-45 Ethernet ports type |
10G Ethernet (100/1000/10000) |
| Installed SFP+ modules quantity |
2 |
| Gigabit Ethernet (copper) ports quantity |
6 |
| Console port |
RJ-45 |
| 2.5G Ethernet (copper) ports quantity |
2 |
| Network |
|---|
| Networking standards |
IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt |
| VLAN support |
Yes |
| 10G support |
Yes |
| Virtual LAN features |
Private VLAN |
| Data transmission |
|---|
| Jumbo frames |
10240 |
| Throughput |
46.12 Mpps |
| MAC address table |
16000 entries |
| Switching capacity |
62 Gbit/s |
| Jumbo frames support |
Yes |
| Security |
|---|
| Security algorithms |
HTTPS |
| Access Control List (ACL) |
Yes |
| Password protection |
Yes |
| DHCP features |
DHCP snooping |
| Protocols |
|---|
| Supported network protocols |
IPv4, IPv6, HTTP, HTTPS, SMTP, Bonjour, UPnP®, SNMP v1/v2c/v3, DNS, NTP, RTSP, TCP, UDP, IGMP, ICMP, DHCP, ARP, SSH, RADIUS, TACACS+, Syslog, IEEE 802.1X, 802.1Q (VLAN), LLDP, LLDP-Med, STP, MSTP, RSTP, LACP, RRPP |
| Certificates |
|---|
| Certification |
EMC
EN 55035, EN 55032 Class A, EN 50121-4, EN 61000-6-1,
EN 61000-6-2, EN 61000-6-3, IEC 62236-4,
FCC part 15 Subpart B Class A, ICES-3(A)/NMB-3(A),
IEC 62236-4, VCCI Class A, RCM AS/NZS CISPR 32 Class A
Safety
IEC/EN/UL 62368-1 ed. 3
Environment
IEC 60068-2-6, IEC 60068-2-27, NEMA TS 2 (2.2.7-2.2.9),
60068-2-31 (Free fall - Procedure 1), IEC/EN 60529 IP30 |
| Design |
|---|
| Product colour |
Black |
| Housing material |
Aluminum |
| Certification |
EMC
EN 55035, EN 55032 Class A, EN 50121-4, EN 61000-6-1,
EN 61000-6-2, EN 61000-6-3, IEC 62236-4,
FCC part 15 Subpart B Class A, ICES-3(A)/NMB-3(A),
IEC 62236-4, VCCI Class A, RCM AS/NZS CISPR 32 Class A
Safety
IEC/EN/UL 62368-1 ed. 3
Environment
IEC 60068-2-6, IEC 60068-2-27, NEMA TS 2 (2.2.7-2.2.9),
60068-2-31 (Free fall - Procedure 1), IEC/EN 60529 IP30 |
| Power |
|---|
| Power source |
DC/PoE |
| Power over Ethernet (PoE) |
|---|
| Power over Ethernet (PoE) power per port |
90 W |
| Total Power over Ethernet (PoE) budget |
480 W |
| Power over Ethernet (PoE) ports quantity |
8 |
| Power over Ethernet (PoE) |
Yes |
| Operational conditions |
|---|
| Storage temperature (T-T) |
-40 - 85 °C |
| Storage relative humidity (H-H) |
5 - 95% |
| Operating temperature (T-T) |
-40 - 60 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Weight & dimensions |
|---|
| Width |
2.44" (62 mm) |
| Depth |
5.12" (130 mm) |
| Height |
6.61" (168 mm) |
| Weight |
31.5 oz (892 g) |
