| Performance |
|---|
| Type |
IP security camera |
| Connectivity technology |
Wired |
| Placement supported |
Indoor & outdoor |
| Wide Dynamic Range (WDR) |
Yes |
| Day/night mode |
Yes |
| Design |
|---|
| IK code |
IK10 |
| Form factor |
Bulb |
| Product colour |
Black, White |
| Mounting type |
Ceiling/wall |
| International Protection (IP) code |
IP66, IP67 |
| Camera |
|---|
| Tilt angle range |
-75 - 75° |
| Pan range |
-100 - 110° |
| Angle of rotation |
170° |
| Camera shutter speed |
1/33500 - 1/5 s |
| Lens viewing angle, horizontal |
98 - 36° |
| Lens viewing angle, vertical |
69 - 27° |
| Lens viewing angle, diagonal |
133 - 46° |
| Image sensor |
|---|
| Sensor type |
CMOS |
| Optical sensor size |
1/2.7" |
| Panoramic camera |
|---|
| Sensor type (panoramic camera) |
CMOS |
| Optical sensor size (panoramic camera) |
1/2.7" |
| Camera shutter speed (panoramic camera) |
1/33500 - 1/5 s |
| Minimum illumination (panoramic camera) |
0.19 lx |
| Focal length range (panoramic camera) |
3.26 - 8.12 mm |
| Lens system |
|---|
| Number of lenses |
1 |
| Auto focus |
Yes |
| Zoom capability |
Yes |
| Focal length range |
3.26 - 8.12 mm |
| Night vision |
|---|
| Night vision |
Yes |
| LED type |
IR |
| Video |
|---|
| Image quality adjustment |
Brightness, Contrast, Sharpness |
| Privacy masking |
Yes |
| Video compression formats |
H.264, H.265, M-JPEG |
| Maximum resolution |
2592 x 1944 pixels |
| Supported graphics resolutions |
2560 x 1440, 2592 x 1944 |
| Frame rate |
30 fps |
| Video streaming |
Yes |
| Total megapixels |
2.5 MP |
| Audio |
|---|
| Built-in speaker(s) |
Yes |
| Audio system |
2-way |
| Audio codecs |
24bit LPCM, AAC-LC 8/16/32/44.1/48 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz, Opus 8/16/48 kHz |
| Network |
|---|
| Bluetooth |
No |
| Ethernet interface type |
Gigabit Ethernet |
| Networking standards |
IEEE 802.1x, IEEE 802.3at |
| Quality of Service (QoS) support |
Yes |
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| Supported network protocols |
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSa , HTTP/2, TLSa , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTCP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Syslog, Link-Local address (ZeroConf) |
| Live view |
Yes |
| Storage |
|---|
| Card reader integrated |
Yes |
| Built-in HDD |
No |
| Ports & interfaces |
|---|
| Microphone in |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Connectivity technology |
Wired |
| Hard drive |
|---|
| Built-in HDD |
No |
| Technical details |
|---|
| Video compression formats |
H.264, H.265, M-JPEG |
| Type |
IP security camera |
| Form factor |
Bulb |
| Placement supported |
Indoor & outdoor |
| Product colour |
Black, White |
| Mounting type |
Ceiling/wall |
| Wide Dynamic Range (WDR) |
Yes |
| Day/night mode |
Yes |
| Built-in speaker(s) |
Yes |
| Doesn't contain |
BFR, PVC |
| Security |
|---|
| Security algorithms |
HTTPS |
| IP address filtering |
Yes |
| Password protection |
Yes |
| Power |
|---|
| Power source type |
PoE |
| Power consumption (Power over Ethernet (PoE)) |
7.9 W |
| Certificates |
|---|
| International Protection (IP) code |
IP66, IP67 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-30 - 50 °C |
| Storage temperature (T-T) |
-40 - 65 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Weight & dimensions |
|---|
| Width |
5.24" (133 mm) |
| Depth |
8.19" (208 mm) |
| Height |
3.46" (88 mm) |
| Weight |
34.4 oz (975 g) |
| Packaging content |
|---|
| Number of cameras |
2 |
| Other features |
|---|
| Video compression formats |
H.264, H.265, M-JPEG |
| Audio codecs |
24bit LPCM, AAC-LC 8/16/32/44.1/48 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz, Opus 8/16/48 kHz |
