Description
PTZ, 1920 x 1080, 60 Hz, CMOS, PoE
Key Features
- 1/2" sensor and long-range OptimizedIR; AXIS Object Analytics preinstalled; Electronic image stabilization; HDTV 1080p and 31x optical zoom; MIL-STD-810G and NEMA TS 2 compliant
Description
This heavy-duty PTZ camera meets the MIL-STD-810G standard, ensuring reliable operation in the toughest conditions. It offers HDTV 1080p resolution and a 1/2" sensor with 31x optical zoom. Featuring Lightfinder, Forensic WDR, and OptimizedIR it ensures sharp, clear images in any light conditions. This vandal-resistant, IK10-rated camera is resistant to both impacts and harsh weather conditions including wind speed up to 245 km/h (150 mph). It comes with built-in analytics preinstalled to alert you when needed. Additionally, Zipstream with H.264/ H.265 significantly reduces bandwidth and storage requirements without compromising image quality.Specifications
| Performance | |
|---|---|
| Infrared (IR) cut-off filter | Yes |
| Number of languages | 18 |
| Languages support | Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Korean, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese |
| Processor model | ARTPEC-7 |
| Type | IP security camera |
| Connectivity technology | Wired |
| PTZ control | Yes |
| Placement supported | Outdoor |
| Auto-tracking | Yes |
| Tour recording | Yes |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Certification | EN 55032 Class A, EN 50121-4, EN 61000-3-2, EN 61000-3-3, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(B), VCCI Class A, RCM AS/NZS CISPR 32 Class A, KS C 9832 Class A, KS C 9835 |
| Built-in processor | Yes |
| Design | |
| IK code | IK10 |
| Form factor | Box |
| Product colour | Gray |
| Mounting type | Wall |
| International Protection (IP) code | IP66, IP68 |
| Housing material | Aluminum |
| Camera | |
| Minimum illumination | 0.05 lx |
| Tilt angle range | -90 - 90° |
| Tilt speed | 150 °/sec |
| Pan speed | 150 °/sec |
| Camera shutter speed | 1/111000 - 1/2 s |
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Lens viewing angle, horizontal | 63.8° |
| Lens viewing angle, vertical | 37° |
| Progressive scan | Yes |
| Image sensor | |
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 1/2" |
| Lens system | |
| Maximum aperture number | 4.6 |
| Auto focus | Yes |
| Minimum aperture number | 1.36 |
| Zoom capability | Yes |
| Optical zoom | 31x |
| Digital zoom | 12x |
| Focal length range | 6.91 - 214.64 mm |
| Night vision | |
| Night vision | Yes |
| Night vision distance | 400 m |
| LED type | IR |
| Infra-red wavelength | 850 nm |
| Video | |
| Privacy masking | Yes |
| Video compression formats | H.264, H.265, M-JPEG |
| Maximum resolution | 1920 x 1080 pixels |
| Frame rate | 60 fps |
| Video streaming | Yes |
| Video recording | Yes |
| Network | |
| Bluetooth | No |
| Ethernet interface type | Gigabit Ethernet |
| Networking standards | IEEE 802.1x, IEEE 802.3bt |
| Quality of Service (QoS) support | Yes |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | IPv4/v6, ICMPv4/ICMPv6, HTTP, HTTP/2, HTTPSb, TLSb, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SOCKS, SSH, LLDP, NTCIP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf) |
| Storage | |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | SD, SDHC, SDXC |
| Internal memory | 1024 MB |
| Flash memory | 512 MB |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Processor | |
| Built-in processor | Yes |
| Memory | |
| Internal memory | 1024 MB |
| Flash memory | 512 MB |
| Hard drive | |
| Built-in HDD | No |
| Technical details | |
| Video compression formats | H.264, H.265, M-JPEG |
| Type | IP security camera |
| Form factor | Box |
| PTZ control | Yes |
| Placement supported | Outdoor |
| Product colour | Gray |
| Mounting type | Wall |
| Auto-tracking | Yes |
| Tour recording | Yes |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Progressive scan | Yes |
| Security | |
| Video motion detection | Yes |
| IP address filtering | Yes |
| HTTPS encryption | Yes |
| Password protection | Yes |
| Pixel counter | Yes |
| Digest authentication | Yes |
| Network access storage (NAS) | Yes |
| Material | |
| Housing material | Aluminum |
| Power | |
| Power source type | PoE |
| Power consumption (max) | 71 W |
| AC input voltage | 100 - 240 V |
| Power consumption (typical) | 25 W |
| Certificates | |
| International Protection (IP) code | IP66, IP68 |
| Certification | EN 55032 Class A, EN 50121-4, EN 61000-3-2, EN 61000-3-3, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(B), VCCI Class A, RCM AS/NZS CISPR 32 Class A, KS C 9832 Class A, KS C 9835 |
| Operational conditions | |
| Operating temperature (T-T) | -50 - 55 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 100% |
| Weight & dimensions | |
| Width | 12.3" (313 mm) |
| Depth | 8.27" (210 mm) |
| Height | 13" (330 mm) |
| Weight | 19.2 lbs (8.7 kg) |
| Packaging content | |
| Number of cameras | 1 |
| Manual | Yes |
| Cables included | LAN (RJ-45) |
| Other features | |
| Video compression formats | H.264, H.265, M-JPEG |
