| Performance |
|---|
| Infrared (IR) cut-off filter |
Yes |
| Number of languages |
18 |
| Languages support |
Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Korean, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese |
| PTZ modes |
Digital PTZ |
| Type |
IP security camera |
| Connectivity technology |
Wired |
| PTZ control |
Yes |
| Placement supported |
Indoor |
| Wide Dynamic Range (WDR) |
Yes |
| Day/night mode |
Yes |
| Alarm input/output |
Yes |
| Design |
|---|
| IK code |
IK08 |
| Form factor |
Dome |
| Product colour |
White |
| Mounting type |
Ceiling/wall |
| Protection features |
Dust resistant, Impact resistant, Water resistant |
| International Protection (IP) code |
IP42 |
| Housing material |
Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC) |
| Camera |
|---|
| Minimum illumination |
0.25 lx |
| Tilt angle range |
0 - 80° |
| Pan range |
0 - 175° |
| Angle of rotation |
175° |
| Camera shutter speed |
1/71500 - 1/5 s |
| Lens viewing angle, horizontal |
109° |
| Lens viewing angle, vertical |
56° |
| Progressive scan |
Yes |
| Image sensor |
|---|
| Sensor type |
CMOS |
| Progressive scan |
Yes |
| Optical sensor size |
1/2.8" |
| Number of sensors |
1 |
| Lens system |
|---|
| Focal length range |
2.9 mm |
| Night vision |
|---|
| Night vision |
Yes |
| Video |
|---|
| Image quality adjustment |
Brightness, Contrast, Sharpness |
| Privacy masking |
Yes |
| Video compression formats |
H.264, H.265, M-JPEG, MPEG4 |
| Maximum resolution |
3840 x 2160 pixels |
| Frame rate |
15 fps |
| Total megapixels |
8 MP |
| Audio |
|---|
| Audio system |
2-way |
| Network |
|---|
| Bluetooth |
No |
| Networking standards |
IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
| Quality of Service (QoS) support |
Yes |
| Number of users |
1 user(s) |
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| Supported network protocols |
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSb , HTTP/2, TLSb , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTCP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, DHCPv4/v6, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf) |
| Storage |
|---|
| Card reader integrated |
Yes |
| Built-in HDD |
No |
| Compatible memory cards |
MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Internal memory |
2048 MB |
| Flash memory |
512 MB |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Connectivity technology |
Wired |
| Memory |
|---|
| Internal memory |
2048 MB |
| Flash memory |
512 MB |
| Hard drive |
|---|
| Built-in HDD |
No |
| Technical details |
|---|
| Video compression formats |
H.264, H.265, M-JPEG, MPEG4 |
| Type |
IP security camera |
| Form factor |
Dome |
| PTZ control |
Yes |
| Placement supported |
Indoor |
| Product colour |
White |
| Mounting type |
Ceiling/wall |
| Protection features |
Dust resistant, Impact resistant, Water resistant |
| Wide Dynamic Range (WDR) |
Yes |
| Day/night mode |
Yes |
| Alarm input/output |
Yes |
| Progressive scan |
Yes |
| Doesn't contain |
BFR, PVC |
| Warranty period |
5 year(s) |
| Security |
|---|
| Video motion detection |
Yes |
| IP address filtering |
Yes |
| HTTPS encryption |
Yes |
| Password protection |
Yes |
| Pixel counter |
Yes |
| Digest authentication |
Yes |
| Network access storage (NAS) |
Yes |
| Material |
|---|
| Housing material |
Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC) |
| Power |
|---|
| Power source type |
PoE |
| Power consumption (max) |
4.2 W |
| Power consumption (typical) |
3.6 W |
| Certificates |
|---|
| International Protection (IP) code |
IP42 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 65 °C |
| Operating relative humidity (H-H) |
10 - 85% |
| Storage relative humidity (H-H) |
5 - 95% |
| Weight & dimensions |
|---|
| Height |
2.2" (56 mm) |
| Diameter |
3.98" (10.1 cm) |
| Weight |
5.29 oz (150 g) |
| Packaging content |
|---|
| Number of cameras |
1 |
| Manual |
Yes |
| Other features |
|---|
| Video compression formats |
H.264, H.265, M-JPEG, MPEG4 |
