75" Display, 3840 x 2160, 330 cd/m2 Brightness, 16/7 operation rating, 1.5GHz Quad-core embedded SoC processor, 2GB RAM, and 16GB of internal memory, RCA Audio In, SPDIF Audio Out, USB 2.0, USB Type C, RS232 In, HDMI 2.0 In(x2), VGA, Wi-Fi/Bluetooth Slot, Ethernet LAN (RJ45), 3.5mm Audio Out, 1683.8 x 965.3 x 71.3 mm, 27300 g
Key Features
- Ultra HD Resolution
- POWERFUL EMBEDDED SOC PLATFORM
- EMBEDDED LAN AND USB WIRELESS CONNECTIVITY
- VIEWBOARD ® CAST CONTENT SHARING SOFTWARE
- Remote Content Sharing from Anywhere
Description
The ViewSonic® CDE7512 is a 75” 4K Ultra HD large format wireless presentation display. With features including a razor-sharp resolution of 3840 x 2160, 330-nit high brightness, 178-degree ultra-wide viewing angles, 2 x 10W speakers, and wireless screen sharing, the CDE7512 transforms meeting rooms into a dynamic communications hub. The built-in ViewBoard® Cast screen sharing software* (along with the optional ViewSonic vCastSender app), and myViewBoard Display software, enables both on-site and online users to participate in conferences and simultaneously share content. Equipped with a 1.5GHz Quad-core embedded SoC processor, 2GB RAM, and 16GB of internal memory, the CDE7512 can play multimedia from internal storage or a USB flash drive 16 hours a day, seven days a week. And with remote configuration and content management system support, the ViewSonic® CDE7512 is also suitable for a wide array of diverse signage applications.
ULTRA HD RESOLUTIONWith four-times the resolution of Full HD, this Ultra HD 3840x2160 display delivers a breathtaking viewing experience with immersive images that are vibrant, clear, and as large as life.
POWERFUL EMBEDDED SOC PLATFORMThe ViewSonic® EMBEDDED Signage Platform (VESP) is a Linux-based Kernel OS, all-in-one solution that simplifies installation and maintenance. With VESP, there is no need for any external devices to communicate with the server or play digital media. Enjoy simplified development, reinforced capability with multiple web formats, and secured protection.
EMBEDDED LAN AND USB WIRELESS CONNECTIVITYAn integrated RJ45 connection, as well as a removable, integrated USB, provide Wi-Fi capabilities for content streaming.
FREE VIEWBOARD ® CAST CONTENT SHARING SOFTWAREViewBoard® Cast enables content to be streamed from mobile devices onto the display via wireless or cable networks. Multiple users can simultaneously annotate content (such as documents, cloud files, multimedia, etc.) on their devices in real time, and then stream and share that content onto the ViewSonic large format display. One-to-one, one-to-many, and 4-in-1 multi-screen options are also available.
REMOTE CONTENT SHARING FROM ANYWHEREmyViewBoard Display is a cloud-based and client-free app that allows you to share your screen from anywhere in the world from virtually any device, without having to worry about group policies or installing additional software.
ALL-IN-ONE SOLUTIONPerfect for conference rooms, huddle spaces and other collaborative environments, this bundle delivers the most useful items businesses need to get up and running with their wireless presentation display. You can quickly install the display with the included wall mount, while the included USB Wi-Fi plug-in module provides a robust and reliable wireless presentation experience.
STREAMLINED DEVICE MANAGEMENTmyViewBoard Manager™ is an easy-to-use, web-based application that allows you to securely set up, manage and maintain all of your display devices from a centralized dashboard. Cloud-based access allows IT managers to remotely access, monitor and manage devices from anywhere.
USB-C WITH POWER DELIVERYUSB-C connectivity provides up to 15W power delivery for convenient charging of your peripherals and accessories. It can also support DisplayPort 1.2 and USB 2.0 with optional adapters.
AV CONTROL SYSTEM CERTIFIEDThe AV control system is at the heart of all integrated AV systems and impacts the overall effectiveness of the entire system. Proper programming is essential for completing profitable projects, gaining user confidence and client satisfaction, and promoting relationships. These wireless presentation displays are Extron certified, AMX certified and Crestron compatible.
RELIABLE 16/7 CONTINUOUS OPERATIONFeaturing a long lifespan, this professional-grade commercial display is designed for reliable use 16 hours a day, 7 days a week. Ideal in virtually any commercial application and environment, this commercial display delivers peace of mind with its robust and durable design.
INTEGRATED CONTENT MANAGEMENT SYSTEMEnjoy a cloud-based 30-day trial service subscription from ViewSonic's content management software, powered by Revel Digital platform. This allows you to instantly transfer multimedia from any HTML5 browser-based device to the display no matter where you are. Works with optional ViewSonic Signage Manager CMS (SW-216) for local content push with perpetual license.
Specifications
| Display |
|---|
| Display number of colours |
1.07 billion colors |
| LED backlighting type |
Direct-LED |
| Touchscreen |
No |
| Display diagonal |
75" |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
330 cd/m² |
| HD type |
4K Ultra HD |
| Response time |
8 ms |
| Contrast ratio (typical) |
1200:1 |
| Contrast ratio (dynamic) |
5000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Panel life |
30000 h |
| Ports & interfaces |
|---|
| USB port |
Yes |
| HDMI version |
2.0 |
| Number of speaker outputs |
1 |
| Wi-Fi |
Yes |
| Ethernet LAN |
Yes |
| HDMI ports quantity |
2 |
| VGA (D-Sub) input ports |
1 |
| Audio (L/R) in |
1 |
| Audio (L/R) out |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| RS-232 interface |
Yes |
| USB version |
2.0 |
| USB ports quantity |
2 |
| HDMI input ports quantity |
2 |
| Audio |
|---|
| Number of built-in speakers |
2 |
| RMS rated power |
10 W |
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Product design |
Digital signage flat panel |
| Placement supported |
Indoor |
| Orientation |
Landscape |
| Product colour |
Black |
| Panel mounting interface |
600 x 400 mm |
| Certification |
cULus, FCC, Energy Star, RoHS |
| VESA mounting |
Yes |
| Mounting type |
Wall |
| Wall mountable |
Yes |
| Performance |
|---|
| Operating hours (hours/days) |
16/7 |
| Wi-Fi |
Yes |
| Panel life |
30000 h |
| Power |
|---|
| Power consumption (max) |
300 W |
| Power consumption (typical) |
240 W |
| Power consumption (standby) |
0.5 W |
| AC input voltage |
100-240 V |
| AC input frequency |
50-60 Hz |
| Computer system |
|---|
| Computer system |
Yes |
| Computer system type |
System on Chip (SoC) |
| Processor cores |
4 |
| Processor family |
ARM Cortex |
| Processor model |
Cortex-A53 |
| Processor frequency |
1.5 GHz |
| Operating system installed |
Android 9.0 |
| Internal memory |
2 GB |
| Internal storage capacity |
16 GB |
| Processor manufacturer |
ARM |
| Built-in processor |
Yes |
| On-board graphics card model |
ARM Mali-G52 |
| Weight & dimensions |
|---|
| Width |
66.3" (1683.8 mm) |
| Depth |
2.81" (71.3 mm) |
| Height |
38" (965.3 mm) |
| Weight |
60.2 lbs (27.3 kg) |
| Packaging data |
|---|
| Package width |
71.2" (1808 mm) |
| Package depth |
7.09" (180 mm) |
| Package height |
42.1" (1069 mm) |
| Package weight |
79.6 lbs (36.1 kg) |
| Remote control included |
Yes |
| Cables included |
HDMI, RS-232 |
| Packaging content |
|---|
| Remote control included |
Yes |
| Cables included |
HDMI, RS-232 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Certificates |
|---|
| Certification |
cULus, FCC, Energy Star, RoHS |
| Technical details |
|---|
| VESA mounting |
Yes |
| Response time |
8 s |
| LED backlighting type |
Direct-LED |
| Thin Client |
|---|
| Processor family |
ARM Cortex |
| Processor model |
Cortex-A53 |
| Processor frequency |
1.5 GHz |
| Operating system installed |
Android 9.0 |
| Internal memory |
2 GB |
| Internal storage capacity |
16 GB |
| Features |
|---|
| Wall mountable |
Yes |
| Other features |
|---|
| Response time |
8 s |
| Wi-Fi |
Yes |
| Power consumption (max) |
300 W |
| Aspect ratio |
16:9 |
