1/2.9'', CMOS, 0.1 lx, 1920 x 1080, 4.4 W, IK10, IP66, white
Key Features
- AXIS Object Analytics; Audio input; Compact and flexible design; Lightfinder and Forensic WDR; Remote zoom and focus with i-CS
Description
This affordable, outdoor-ready camera is easy to install and operate. Enclosed in an IP66-, IK10- and NEMA 4X-rated casing, it supports PoE and redundant DC power to ensure your data is safeguarded in the event of a power outage. Featuring Axis Lightfinder and Axis Forensic WDR, it delivers true colors and great details in challenging light or near darkness. Plus, audio input lets you record video with sound. The camera's CS-mount enables flexibility for exchangeable lenses. With AXIS Object Analytics preinstalled, it’s possible to detect and classify humans and vehicles. Furthermore, Axis Zipstream with H.264/H.265 significantly lowers bandwidth and storage requirements.
Specifications
| Performance |
|---|
| PTZ modes |
Digital PTZ |
| Type |
IP security camera |
| Connectivity technology |
Wired |
| PTZ control |
Yes |
| Placement supported |
Indoor & outdoor |
| Wide Dynamic Range (WDR) |
Yes |
| Day/night mode |
Yes |
| Design |
|---|
| IK code |
IK10 |
| Form factor |
Box |
| Product colour |
White |
| Mounting type |
Wall |
| International Protection (IP) code |
IP66 |
| Camera |
|---|
| Minimum illumination |
0.1 lx |
| Lens viewing angle, horizontal |
90° |
| Lens viewing angle, vertical |
49° |
| Image sensor |
|---|
| Sensor type |
CMOS |
| Optical sensor size |
1/2.9" |
| Lens system |
|---|
| Focal length range |
3 - 10.5 mm |
| Night vision |
|---|
| Night vision |
Yes |
| Video |
|---|
| Video compression formats |
H.264, H.265, MPEG4 |
| Maximum resolution |
1920 x 1080 pixels |
| Video formats supported |
H.264, H.265 |
| Supported graphics resolutions |
160 x 90 |
| Frame rate |
30 fps |
| Total megapixels |
2 MP |
| Audio |
|---|
| Audio system |
2-way |
| Network |
|---|
| Networking standards |
IEEE 802.3af, IEEE 802.3at |
| Ethernet LAN |
Yes |
| Storage |
|---|
| Flash memory |
512 MB |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Connectivity technology |
Wired |
| Memory |
|---|
| Flash memory |
512 MB |
| Technical details |
|---|
| Video compression formats |
H.264, H.265, MPEG4 |
| Type |
IP security camera |
| Form factor |
Box |
| PTZ control |
Yes |
| Placement supported |
Indoor & outdoor |
| Product colour |
White |
| Mounting type |
Wall |
| Wide Dynamic Range (WDR) |
Yes |
| Day/night mode |
Yes |
| Power |
|---|
| Power source type |
DC, PoE |
| Power consumption (max) |
6.6 W |
| Power consumption (Power over Ethernet (PoE)) |
4.5 W |
| Power consumption (typical) |
4.4 W |
| DC output voltage |
10, 12, 15, 16, 24, 28 |
| Certificates |
|---|
| International Protection (IP) code |
IP66 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-20 - 50 °C |
| Storage temperature (T-T) |
-40 - 65 °C |
| Operating relative humidity (H-H) |
10 - 100% |
| Storage relative humidity (H-H) |
5 - 95% |
| Weight & dimensions |
|---|
| Width (with stand) |
5.63" (143 mm) |
| Depth (with stand) |
14.6" (372 mm) |
| Height (with stand) |
9.45" (240 mm) |
| Width |
5.63" (143 mm) |
| Depth |
12.5" (317 mm) |
| Height |
4.25" (108 mm) |
| Weight (with stand) |
3.97 lbs (1.8 kg) |
| Packaging content |
|---|
| Number of cameras |
1 |
| Other features |
|---|
| Video compression formats |
H.264, H.265, MPEG4 |
| Logistics data |
|---|
| Harmonized System (HS) code |
85258900 |
