2-Port Full HD KVM Switch with HDMI and USB Connections
Key Features
- One USB keyboard, USB mouse, and HDMI monitor controls two HDMI computers
- Full HD video quality - up to 1920x1200@60Hz
- Plug-n-Play monitor support
- Molded-in cables to simplify setup
- Compact design features two attached KVM (USB and HDMI) cables
Description
2-Port Full HD KVM Switch with HDMI Connection and USB
IOGEAR's 2-Port Full HD KVM switch with HDMI and USB connections enables effortless control over 2 HDMI full HD computers using a single USB keyboard, a USB mouse and an HDMI monitor.
This Full HD KVM is HDCP Compliant and supports up to 1920 x 1080 @60Hz resolution on a widescreen HDMI display, perfect for those who need to get the job done in the office, at home and at school.
Easy Installation
The 2-Port Full HD KVM Switch is plug-and-play. And all the cables you need are included. The KVM shows which computer you are using with a light on the unit (either PC1 or PC2).
Toggling between two HDMI computers is as easy as clicking the remote port selector button allowing the user to multitask with two computers. Place the 6 ft remote port cable behind your computer set-up so the selector button can be placed on your desk for easy reach.
Specifications
| Ports & interfaces |
|---|
| Cable length |
4.76" (0.121 m) |
| Console USB ports quantity |
2 |
| Console ports |
HDMI, USB A |
| HDCP |
Yes |
| USB connector type |
USB Type-A |
| Number of computers controlled |
2 |
| Keyboard port type |
USB |
| Mouse port type |
USB |
| Video port type |
HDMI |
| HDMI ports quantity |
2 |
| USB 2.0 Type-A hub ports quantity |
2 |
| Console HDMI ports quantity |
1 |
| Technical details |
|---|
| Product colour |
Black |
| Plug and Play |
Yes |
| LED indicators |
Yes |
| Video |
|---|
| HD type |
WUXGA |
| Video bandwidth |
60 Hz |
| Maximum resolution |
1920 x 1200 pixels |
| Performance |
|---|
| HDCP |
Yes |
| HD type |
WUXGA |
| Video bandwidth |
60 Hz |
| Plug and Play |
Yes |
| Maximum resolution |
1920 x 1200 pixels |
| Design |
|---|
| Wired remote switch |
Yes |
| Product colour |
Black |
| Cable length |
4.76" (0.121 m) |
| LED indicators |
Yes |
| Housing material |
Plastic |
| Display |
|---|
| Built-in display |
No |
| Power |
|---|
| Input current |
1 A |
| Power source |
AC |
| AC input frequency |
50 - 60 Hz |
| System requirements |
|---|
| Windows operating systems supported |
Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1 |
| Linux operating systems supported |
Yes |
| Mac operating systems supported |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 50 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
0 - 80% |
| Packaging data |
|---|
| Package width |
2.25" (57.1 mm) |
| Package depth |
6.13" (155.7 mm) |
| Package height |
8.74" (222 mm) |
| Package weight |
13.6 oz (385.5 g) |
| Packaging content |
|---|
| Manual |
Yes |
| Weight & dimensions |
|---|
| Package width |
2.25" (57.1 mm) |
| Package depth |
6.13" (155.7 mm) |
| Package height |
8.74" (222 mm) |
| Package weight |
13.6 oz (385.5 g) |
| Logistics data |
|---|
| Master (outer) case width |
15.2" (387.3 mm) |
| Master (outer) case length |
8" (203.2 mm) |
| Master (outer) case height |
7" (177.8 mm) |
| Products per master (outer) case |
6 pc(s) |
| Master (outer) case net weight |
5.75 lbs (2.61 kg) |
