600 g (1.32 lb), (8) 10/1001000 MbE RJ45 ports
Key Features
- (8) GbE RJ45 ports with 27V passive PoE that support 2-pair and 4-pair modes
- (1) 1G SFP port
- 110W PoE supply when powered with the included AC/DC adapter
- Fanless, thermal cooling for silent operation
- Wall-mountable (kit included)
- Easy, Bluetooth-powered setup via the UISP Mobile app
Description
Gigabit PoE router for MicroPoP applications.Ideal for wireless ISP (WISP) deployments, the UISP™ Router is a fanless PoE router featuring (8) GbE RJ45 ports and (1) 1G SFP port for an additional fiber uplink option. The UISP Router provides a cost-effective routing solution for WISPs looking to quickly and inexpensively deliver Gigabit wireless speeds to their customers. With its hefty 110W total PoE supply, the UISP Router delivers substantial power to every radio in your service network. The UISP Router is managed with the UISP application, a centralized platform where you can monitor and manage all of your UISP devices.
Works with the Ubiquiti Internet Service Provider (UISP™) Application- Centrally manage your networks and customers with ease
- Organize your subscription plans, setup billing and invoicing, and grow your customer base
- View your network's topology, advanced analytics, and more
- Set up devices quickly and manage them on the go with powerful mobile app support
Specifications
| Ethernet LAN features |
|---|
| Cabling technology |
10/100Base-T(X) |
| Memory |
|---|
| Flash memory |
512 MB |
| Internal memory |
512 MB |
| Performance |
|---|
| Flash memory |
512 MB |
| Internal memory |
512 MB |
| Processor frequency |
880 MHz |
| WAN connection |
|---|
| SFP WAN |
Yes |
| Ethernet WAN |
Yes |
| SIM card slot |
No |
| 3G/4G USB modem compatibility |
No |
| Network |
|---|
| Cabling technology |
10/100Base-T(X) |
| Ethernet interface type |
Gigabit Ethernet |
| Ports & interfaces |
|---|
| Power over Ethernet (PoE) ports quantity |
8 |
| Installed SFP modules quantity |
1 |
| Ethernet LAN (RJ-45) ports |
8 |
| DC-in jack |
Yes |
| Technical details |
|---|
| Processor frequency |
880 MHz |
| LED indicators |
Activity, LAN, Link, PoE, Power, Speed, WAN, WLAN |
| Product colour |
White |
| Harmonized System (HS) code |
85176990 |
| Features |
|---|
| Flash memory |
512 MB |
| Internal memory |
512 MB |
| Processor frequency |
880 MHz |
| Certification |
CE, FCC, IC |
| Processor model |
MIPS 1004Kc |
| Design |
|---|
| LED indicators |
Activity, LAN, Link, PoE, Power, Speed, WAN, WLAN |
| Product colour |
White |
| Power |
|---|
| Power source type |
DC, PoE |
| Output voltage |
24 - 28 V |
| Output current |
4.4 A |
| Power over Ethernet (PoE) |
Yes |
| Power consumption (typical) |
10 W |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-10 - 50 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Weight & dimensions |
|---|
| Width |
8.28" (210.4 mm) |
| Depth |
3.74" (95 mm) |
| Height |
1.14" (29 mm) |
| Weight |
21.2 oz (600 g) |
| Packaging data |
|---|
| AC adapter included |
Yes |
| Quick start guide |
Yes |
| Manual |
Yes |
| Logistics data |
|---|
| Harmonized System (HS) code |
85176990 |
| Certificates |
|---|
| Certification |
CE, FCC, IC |
| Packaging content |
|---|
| AC adapter included |
Yes |
| Quick start guide |
Yes |
| Manual |
Yes |
