Description
32”, 16:9, IPS, 3840x2160, 600 cd/㎡, 5ms, 2 x Thunderbolt™ 3 USB-C™, 3 x HDMI, DisplayPort, 9.7 kg
ASUS ProArt PA32UCX-PK is a 32-inch 4K HDR monitor designed for discerning content creators, including videographers, cinematographers and colorists. When multiple content creators work together on the same screen, it is necessary that everyone sees the same color and contrast level. With new Off-Axis Contrast Optimization (OCO) technology that reduces halo effects when viewing the screen from a wide angle, ProArt PA32UCX-PK features ensures on-screen content is displayed accurately to all viewers. ProArt PA32UCX-PK features a peak brightness of 1,200 nits and mini-LED backlighting, enabling 1,152 zones of local dimming control and support for multiple HDR formats, including Dolby Vision™, HLG and HDR-10. With true 10-bit color and quantum dot technology, support for the DCI-P3, Rec. 709, Rec. 2020 and Adobe RGB color spaces, together with a rich selection of connectivity, ProArt PA32UCX-PK delivers an exceptional image that takes the viewing experience to the next level.
Excellent Color and Contrast from Any Viewing Angle
Direct type LED backlight displays have narrow viewing angles, which can make collaboration with clients or colleagues on color-critical work challenging due to inaccurate colors being displayed to viewers seated to the side.
ASUS Off-Axis Contrast Optimization (OCO) technology solves this problem with a compensation layer that controls light transmittance around the edges, reducing halo effects by 80%* and providing a 7X* contrast-ratio enhancement for dark parts of the image when viewing the screen from an angle.
32-inch 4K Monitor with Mini LED Backlight
ASUS ProArt PA32UCX-PK 4K monitor incorporates the leading technology of mini LED backlight, which is packed in physically half smaller LEDs than the conventional in more densely to increases the granularity of brightness control. ProArt PA32UCX-PK offers individual backlight control of a whopping 1,152 zones with higher luminance and deeper darkness to deliver the best contrast and accurate reproduction of HDR contents.
ASUS Smart HDR Technology
ASUS ProArt PA32UCX-PK features ASUS Smart HDR Technology, which supports multiple HDR (high-dynamic-range) formats and multiple PQ curves to suit content creators' specific requirements. Dolby Vision HDR transforms your viewing experience with ultra vivid image — incredible brightness, contrast, and color to expand content creators' storytelling possibilities . It achieves this astonishing image quality through cinema-inspired HDR technology that can deliver billions of colors. HDR-10 support ensures compatibility with existing streaming video services and a growing list of HDR-enabled games, including PQ hard clip curve, PQ Optimized and PQ Basic, to cover all content creators' needs. The PA32UCX-PK HLG (hybrid log gamma) preset allows users to both immerse in, as well as create material for broadcast and satellite TV platforms such as the BBC iPlayer, Japan NHK TV, and DirecTV.
32-inch 4K Monitor to Support Dolby Vision™
Dolby Vision™ HDR transforms entertainment experience with ultra-vivid picture quality, providing incredible brightness, contrast, color and detail to bring entertainment to life. With Dolby Vision, the PA32UCX-PK can bring confidence for content creators that their images are represented with ultimate consistency.
Multiple PQ Curves with Quick Preview
ASUS ProArt PA32UCX-PK supports multiple HDR-10 (high-dynamic-range) curves, including PQ Hard Clip, PQ Optimized and PQ Basic which can cover all content creators' needs.
It also comes with HDR Preview, a feature which enables video creators to connect their camera directly to ProArt PA32UCX-PK and view captured HDR content with its full tonal range.
HDR Preview also automatically works in video editing software, enabling creators to view accurate simulations of final output for an easier and more streamlined editing experience.
PQ Hard Clip
Preserve PQ curve till displaying maximum luminance with accuracy. Any luminance higher than display maximum will be mapped to display maximum.
PQ Optimized
Reproduce accurate gradations corresponding to maximum brightness of the monitor.Deliver the optimized HDR performance of this display.
PQ Basic
Present general HDR performance.
Transform Your Viewing Experience
True 10-bit IPS with 1,200 nits peak brightness, supporting Quantum Dot technology provides an entire spectrum of colors to play with. PA32UCX-PK support 99% DCI-P3, 99.5% Adobe RGB, 100% sRGB, 100% Rec. 709 and 89% Rec.2020 color spaces for video editing and post-production.
The Most Flexible Hardware Calibration
Whether you're using a desktop, laptop, PC or Mac, ASUS ProArt™ Hardware Calibration offers color accuracy tuning and uniformity compensation to make things easy when it's time to recalibrate your display's brightness and color consistency.
ProArt displays are compatible with most major calibrators, including those from X-Rite, Datacolor and Klein, and also work seamlessly with Calman and Light Illusion ColourSpace CMS professional hardware calibration software to make calibration faster and easier. (Calman and Light Illusion ColourSpace CMS software are not included with ProArt PA32UCX-PK.)
ASUS ProArt™ Calibration lets you optimize color space settings for different content. Besides sRGB, you can create advanced setups comprising of five different color spaces and other customized settings.
ASUS ProArt™ Calibration gives you 3x3 and 5x5 uniformity compensation matrices to ensure consistent brightness throughout the screen to reduce color shift.
The ASUS ProArt™ Calibration Technology saves all color parameter profiles on the ProArt™ monitor's internal scaler IC chip instead of the PC. This lets you connect your monitor to different devices without needing to continuously change existing settings. It also reduces the signal distortion between the IC and the LCD optical spectrum. The color profiles can be easily activated by using the hotkey on the monitor next time without a PC or calibrators.
Connect to Your Workflow
ASUS ProArt PA32UCX-PK comes with HDMI (v2.0), DisplayPort1.2, Thunderbolt™ 3 USB-C and USB hub.
It is built for content creators to easily connect to gadgets including blu-ray player, control panel, peripheral, desktop and display with zero hassle.
Picture-in-Picture & Picture-by-Picture
Both Built-in Picture-in-Picture (PiP) and Picture-by-Picture (PbP) functionalities allow you to view content from multiple sources simultaneously, and switch between them easily. You can even select which audio source to play.
Picture-by-Picture (PbP) mode
To simultaneously experience different settings, place multiple input sources side by side onscreen and configure each individual window's color settings with sRGB, Adobe RGB, DCI-P3, Rec. 2020, User Mode 1 or User Mode 2.
Ergonomic Design
A comfortable viewing position is always easy to achieve with ProArt™ PA32UCX-PK, thanks to its slim profile and ergonomically designed stand that offers tilt, swivel, pivot, and height adjustments. Its onscreen menu even rotates automatically to display correctly when the monitor is used in portrait orientation.
Key Features
- 32-inch 4K HDR display for professionals features 1,152-zone mini-LED backlight with 1,200 cd/m2 peak brightness
- ASUS Off-Axis Contrast Optimization technology reduces halo effects by 80% and provides a 7X contrast-ratio enhancement for dark parts of the image when viewing the screen from an angle
- True 10 bit color with Quantum-dot technology provides 89% Rec. 2020, 99.5% Adobe RGB, 99% DCI-P3 and 100% sRGB color space for exceptional color fidelity
- Support multiple HDR formats (Dolby Vision, HDR-10, HLG) presents lifelike experience and flexibility
- World-leading delta-E (∆E) <1 color difference value for the sRGB and Adobe RGB color spaces and ASUS ProArt Hardware Calibration technology for color-accuracy optimization, uniformity and color profile write-back
- Thunderbolt™ 3 USB-C supports data transfers at up to 40 Gbps, and Power Delivery provides up to 60W of power to external devices
Description
Master Collaborative HDR WorkflowsASUS ProArt PA32UCX-PK is a 32-inch 4K HDR monitor designed for discerning content creators, including videographers, cinematographers and colorists. When multiple content creators work together on the same screen, it is necessary that everyone sees the same color and contrast level. With new Off-Axis Contrast Optimization (OCO) technology that reduces halo effects when viewing the screen from a wide angle, ProArt PA32UCX-PK features ensures on-screen content is displayed accurately to all viewers. ProArt PA32UCX-PK features a peak brightness of 1,200 nits and mini-LED backlighting, enabling 1,152 zones of local dimming control and support for multiple HDR formats, including Dolby Vision™, HLG and HDR-10. With true 10-bit color and quantum dot technology, support for the DCI-P3, Rec. 709, Rec. 2020 and Adobe RGB color spaces, together with a rich selection of connectivity, ProArt PA32UCX-PK delivers an exceptional image that takes the viewing experience to the next level.
Excellent Color and Contrast from Any Viewing Angle
Direct type LED backlight displays have narrow viewing angles, which can make collaboration with clients or colleagues on color-critical work challenging due to inaccurate colors being displayed to viewers seated to the side.
ASUS Off-Axis Contrast Optimization (OCO) technology solves this problem with a compensation layer that controls light transmittance around the edges, reducing halo effects by 80%* and providing a 7X* contrast-ratio enhancement for dark parts of the image when viewing the screen from an angle.
32-inch 4K Monitor with Mini LED Backlight
ASUS ProArt PA32UCX-PK 4K monitor incorporates the leading technology of mini LED backlight, which is packed in physically half smaller LEDs than the conventional in more densely to increases the granularity of brightness control. ProArt PA32UCX-PK offers individual backlight control of a whopping 1,152 zones with higher luminance and deeper darkness to deliver the best contrast and accurate reproduction of HDR contents.
ASUS Smart HDR Technology
ASUS ProArt PA32UCX-PK features ASUS Smart HDR Technology, which supports multiple HDR (high-dynamic-range) formats and multiple PQ curves to suit content creators' specific requirements. Dolby Vision HDR transforms your viewing experience with ultra vivid image — incredible brightness, contrast, and color to expand content creators' storytelling possibilities . It achieves this astonishing image quality through cinema-inspired HDR technology that can deliver billions of colors. HDR-10 support ensures compatibility with existing streaming video services and a growing list of HDR-enabled games, including PQ hard clip curve, PQ Optimized and PQ Basic, to cover all content creators' needs. The PA32UCX-PK HLG (hybrid log gamma) preset allows users to both immerse in, as well as create material for broadcast and satellite TV platforms such as the BBC iPlayer, Japan NHK TV, and DirecTV.
32-inch 4K Monitor to Support Dolby Vision™
Dolby Vision™ HDR transforms entertainment experience with ultra-vivid picture quality, providing incredible brightness, contrast, color and detail to bring entertainment to life. With Dolby Vision, the PA32UCX-PK can bring confidence for content creators that their images are represented with ultimate consistency.
Multiple PQ Curves with Quick Preview
ASUS ProArt PA32UCX-PK supports multiple HDR-10 (high-dynamic-range) curves, including PQ Hard Clip, PQ Optimized and PQ Basic which can cover all content creators' needs.
It also comes with HDR Preview, a feature which enables video creators to connect their camera directly to ProArt PA32UCX-PK and view captured HDR content with its full tonal range.
HDR Preview also automatically works in video editing software, enabling creators to view accurate simulations of final output for an easier and more streamlined editing experience.
PQ Hard Clip
Preserve PQ curve till displaying maximum luminance with accuracy. Any luminance higher than display maximum will be mapped to display maximum.
PQ Optimized
Reproduce accurate gradations corresponding to maximum brightness of the monitor.Deliver the optimized HDR performance of this display.
PQ Basic
Present general HDR performance.
Transform Your Viewing Experience
True 10-bit IPS with 1,200 nits peak brightness, supporting Quantum Dot technology provides an entire spectrum of colors to play with. PA32UCX-PK support 99% DCI-P3, 99.5% Adobe RGB, 100% sRGB, 100% Rec. 709 and 89% Rec.2020 color spaces for video editing and post-production.
The Most Flexible Hardware Calibration
Whether you're using a desktop, laptop, PC or Mac, ASUS ProArt™ Hardware Calibration offers color accuracy tuning and uniformity compensation to make things easy when it's time to recalibrate your display's brightness and color consistency.
ProArt displays are compatible with most major calibrators, including those from X-Rite, Datacolor and Klein, and also work seamlessly with Calman and Light Illusion ColourSpace CMS professional hardware calibration software to make calibration faster and easier. (Calman and Light Illusion ColourSpace CMS software are not included with ProArt PA32UCX-PK.)
ASUS ProArt™ Calibration lets you optimize color space settings for different content. Besides sRGB, you can create advanced setups comprising of five different color spaces and other customized settings.
ASUS ProArt™ Calibration gives you 3x3 and 5x5 uniformity compensation matrices to ensure consistent brightness throughout the screen to reduce color shift.
The ASUS ProArt™ Calibration Technology saves all color parameter profiles on the ProArt™ monitor's internal scaler IC chip instead of the PC. This lets you connect your monitor to different devices without needing to continuously change existing settings. It also reduces the signal distortion between the IC and the LCD optical spectrum. The color profiles can be easily activated by using the hotkey on the monitor next time without a PC or calibrators.
Connect to Your Workflow
ASUS ProArt PA32UCX-PK comes with HDMI (v2.0), DisplayPort1.2, Thunderbolt™ 3 USB-C and USB hub.
It is built for content creators to easily connect to gadgets including blu-ray player, control panel, peripheral, desktop and display with zero hassle.
Picture-in-Picture & Picture-by-Picture
Both Built-in Picture-in-Picture (PiP) and Picture-by-Picture (PbP) functionalities allow you to view content from multiple sources simultaneously, and switch between them easily. You can even select which audio source to play.
Picture-by-Picture (PbP) mode
To simultaneously experience different settings, place multiple input sources side by side onscreen and configure each individual window's color settings with sRGB, Adobe RGB, DCI-P3, Rec. 2020, User Mode 1 or User Mode 2.
Ergonomic Design
A comfortable viewing position is always easy to achieve with ProArt™ PA32UCX-PK, thanks to its slim profile and ergonomically designed stand that offers tilt, swivel, pivot, and height adjustments. Its onscreen menu even rotates automatically to display correctly when the monitor is used in portrait orientation.
Specifications
| Display | |
|---|---|
| HDCP | Yes |
| Display brightness (typical) | 600 cd/m² |
| Screen shape | Flat |
| Dynamic contrast ratio marketing name | SmartContrast |
| Display number of colours | 1.073 billion colors |
| Native aspect ratio | 16:9 |
| Maximum refresh rate | 142 Hz |
| sRGB coverage (typical) | 100% |
| Adobe RGB coverage | 99.5% |
| Display surface | Matt |
| HD type | 4K Ultra HD |
| Display technology | LED |
| Contrast ratio (typical) | 1000:1 |
| Contrast ratio (dynamic) | 1000000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Pixel pitch | 0.00726 x 0.00726" (0.184 x 0.184 mm) |
| Aspect ratio | 16:9 |
| Viewable size, horizontal | 27.9" (70.8 cm) |
| Viewable size, vertical | 15.7" (39.9 cm) |
| Digital horizontal frequency | 109 - 142 kHz |
| Digital vertical frequency | 29 - 65 Hz |
| Supported graphics resolutions | 3840 x 2160 |
| Display resolution | 3840 x 2160 pixels |
| Response time | 5 ms |
| Display diagonal | 32" |
| Touchscreen | No |
| High Dynamic Range (HDR) supported | Yes |
| Panel type | IPS |
| High Dynamic Range (HDR) technology | High Dynamic Range (HDR) 1000 |
| Colour gamut standard | sRGB |
| Audio | |
| Built-in speaker(s) | Yes |
| RMS rated power | 3 W |
| Performance | |
| Built-in speaker(s) | Yes |
| RMS rated power | 3 W |
| Built-in camera | No |
| Low Blue Light technology | Yes |
| Flicker-free technology | Yes |
| Management features | |
| Picture-in-Picture | Yes |
| Multimedia | |
| Number of speakers | 2 |
| Built-in speaker(s) | Yes |
| RMS rated power | 3 W |
| Built-in camera | No |
| Design | |
| Market positioning | Graphics design |
| Feet colour | Black |
| Certification | BSMI, CB, CCC, CEL level 0, CU, ErP, FCC, ISO-9241-307, J-MOSS, KCC, Mac ComplianPSE, UkrSEPRO, UL/cUL, VCCI, WEEE, WHQL (Windows 10, Windows 8.1, Windows 7), MEPS, RCM, TUV Flicker-free , KC , eStandby, TUV Low Blue Light, ICES-3, PC recycle, VESA DisplayHDR 1000 |
| Product colour | Black |
| Camera | |
| Built-in camera | No |
| Ports & interfaces | |
| Built-in USB hub | Yes |
| USB hub version | 3.2 Gen 1 (3.1 Gen 1) |
| USB upstream port type | USB Type-C |
| Number of upstream ports | 1 |
| USB Type-A downstream ports quantity | 3 |
| USB Type-C downstream ports quantity | 1 |
| Headphone out | Yes |
| DVI port | No |
| VGA (D-Sub) ports quantity | 0 |
| HDMI ports quantity | 3 |
| DisplayPorts quantity | 1 |
| HDCP | Yes |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
| HDMI | Yes |
| HDMI version | 2.0b |
| DisplayPort version | 1.2 |
| Thunderbolt 3 ports quantity | 2 |
| Technical details | |
| Height (without stand) | 16.8" (426 mm) |
| Depth (without stand) | 3.66" (93 mm) |
| Width (without stand) | 28.6" (727 mm) |
| Feet colour | Black |
| Cable lock slot | Yes |
| HDMI | Yes |
| Product colour | Black |
| Weight (with stand) | 32.2 lbs (14.6 kg) |
| Touchscreen | No |
| Ergonomics | |
| VESA mounting | Yes |
| Cable lock slot | Yes |
| Panel mounting interface | 100 x 100 mm |
| Swivelling | Yes |
| Swivel angle range | -60 - 60° |
| Tilt angle range | -5 - 23° |
| Pivot | Yes |
| Pivot angle | -90 - 90° |
| Picture-in-Picture | Yes |
| Height adjustment | Yes |
| Cable lock slot type | Kensington |
| Tilt adjustment | Yes |
| Adjustable height (max) | 5.12" (13 cm) |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.3 W |
| Energy efficiency scale | A to G |
| Energy efficiency class (SDR) | G |
| Energy efficiency class (HDR) | G |
| Energy consumption (SDR) per 1000 hours | 80 kWh |
| Energy consumption (HDR) per 1000 hours | 97 kWh |
| European Product Registry for Energy Labelling (EPREL) code | 429620 |
| Weight & dimensions | |
| Height (without stand) | 16.8" (426 mm) |
| Depth (without stand) | 3.66" (93 mm) |
| Width (without stand) | 28.6" (727 mm) |
| Width (with stand) | 28.6" (727 mm) |
| Depth (with stand) | 9.45" (240 mm) |
| Height (with stand) | 23.6" (600 mm) |
| Weight (with stand) | 32.2 lbs (14.6 kg) |
| Weight (without stand) | 21.4 lbs (9.7 kg) |
| Package width | 35.9" (913 mm) |
| Package depth | 20.7" (525 mm) |
| Package height | 15" (381 mm) |
| Package weight | 43.7 lbs (19.8 kg) |
| Packaging data | |
| Package width | 35.9" (913 mm) |
| Package depth | 20.7" (525 mm) |
| Package height | 15" (381 mm) |
| Package weight | 43.7 lbs (19.8 kg) |
| Stand included | Yes |
| Cables included | AC |
| Packaging content | |
| Stand included | Yes |
| Cables included | AC |
| Sustainability | |
| European Product Registry for Energy Labelling (EPREL) code | 429620 |
| Other features | |
| Certification | BSMI, CB, CCC, CEL level 0, CU, ErP, FCC, ISO-9241-307, J-MOSS, KCC, Mac ComplianPSE, UkrSEPRO, UL/cUL, VCCI, WEEE, WHQL (Windows 10, Windows 8.1, Windows 7), MEPS, RCM, TUV Flicker-free , KC , eStandby, TUV Low Blue Light, ICES-3, PC recycle, VESA DisplayHDR 1000 |
| Height (without stand) | 16.8" (426 mm) |
| Depth (without stand) | 3.66" (93 mm) |
| Width (without stand) | 28.6" (727 mm) |
| HDMI | Yes |
| Energy efficiency scale | A to G |
| Touchscreen | No |
| Certificates | |
| Certification | BSMI, CB, CCC, CEL level 0, CU, ErP, FCC, ISO-9241-307, J-MOSS, KCC, Mac ComplianPSE, UkrSEPRO, UL/cUL, VCCI, WEEE, WHQL (Windows 10, Windows 8.1, Windows 7), MEPS, RCM, TUV Flicker-free , KC , eStandby, TUV Low Blue Light, ICES-3, PC recycle, VESA DisplayHDR 1000 |
| Logistics data | |
| Harmonized System (HS) code | 85285210 |
