DLP, 1920x1200, 5000 lm, 16:10, HDMI 2.0, VGA, 3.5mm, RJ-45, RS-232, USB, 100-240V, 383x318x111 mm
Description
The ZU500USTe is powered by long-lasting, low maintenance DuraCore laser light source. The lamp-less and filter-free design vastly reduces running costs for a lower total cost of ownership.
Weighing only 12.5lbs, this projector can be mounted just inches away from a wall or surface and can project an image size of over 100 inches.
Supporting 24/7 operation and versatile orientation, the ZU500USTe is a flexible, powerful and bright ultra short throw projector that makes for a superb signage solution where space or accessibility can be limited, such as shop windows or retail displays.
Ultra Short ThrowWith an ultra-short throw lens, you can project an impressive image greater than 100” from only inches away. This allows you to place the projector closer to the wall, reducing shadows so you can present with ease; perfect for interactive applications.
DuraCoreIndustry leading lifetime is achieved using Optoma’s DuraCore technology. Implementing advanced laser diode cooling techniques and an innovative dust resistant design.
IP5X Dust resistant optical engineIndependently tested and certified to IEC standard 60529 with an IP5X dust resistance rating. Outstanding dust resistance combined with exceptional brightness ensures industry leading durability; ideal for 24/7 maintenance free operation in challenging environments.
Four corner correctionAdjust the keystone in both the vertical and horizontal plane. You can individually warp each corner of the image to create a perfectly square image. Ideal for image stacking, uneven walls or where projector placement is awkward and needs to be installed at an angle.
Amazing colorOptoma projectors provide reliable color performance suitable for any content and environment. From accurate sRGB colors for lifelike images to vibrant punchy presentations. We have a display mode to specifically meet your needs. Perfect for a range of graphic and video presentations.
Superior contrastAdd more depth to your image with a high contrast projector. Compared to competing technology, Optoma DLP projectors provide you with brighter whites and ultra-rich blacks, images come alive and text appears crisp and clear - ideal for business and education applications.
Specifications
| Projector |
|---|
| Projector native resolution |
WUXGA (1920x1200) |
| Native aspect ratio |
16:10 |
| Supported aspect ratios |
16:10, 16:9 |
| Screen size compatibility |
133 - 154" |
| Projection distance |
28.6 - 33.1" (0.727 - 0.84 m) |
| Contrast ratio (typical) |
100000:1 |
| Uniformity |
85% |
| Keystone correction, vertical |
15° |
| Keystone correction, horizontal |
15° |
| Projection technology |
DLP |
| Projector brightness |
500 ANSI lumens |
| Heat dissipation |
1608 BTU/h |
| Smart projector |
No |
| Light source |
|---|
| Light source type |
Laser |
| Service life of light source |
30000 h |
| Lens system |
|---|
| Fixed focal length |
0.146" (3.7 mm) |
| Throw ratio |
0.25:1 |
| Offset |
117% |
| Zoom type |
Fixed |
| Video |
|---|
| Analog signal format system |
NTSC 3.58, NTSC 4.43, NTSC J, NTSC M, PAL B, PAL D, PAL G, PAL H, PAL I, PAL M, PAL N, SECAM 4.25/4.4, SECAM B, SECAM D, SECAM G, SECAM K, SECAM K1, SECAM L |
| Full HD |
Yes |
| 3D |
Yes |
| Supported video modes |
480i, 480p, 576i, 576p, 720p, 1080p |
| Supported graphics resolutions |
640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080) |
| Ports & interfaces |
|---|
| HDMI connector type |
Full-size |
| VGA (D-Sub) ports quantity |
2 |
| HDMI ports quantity |
2 |
| USB 2.0 ports quantity |
1 |
| Serial interface type |
RS-232 |
| PC Audio out |
Yes |
| PC Audio in |
Yes |
| HDMI version |
2.0 |
| DVI port |
No |
| AC (power) in |
Yes |
| Network |
|---|
| Smart TV |
No |
| Ethernet LAN |
Yes |
| Storage |
|---|
| Card reader integrated |
No |
| Features |
|---|
| Interactive |
No |
| Password protection |
Yes |
| On Screen Display (OSD) |
Yes |
| Noise level |
35 dB |
| Number of OSD languages |
18 |
| Multimedia |
|---|
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
1 |
| RMS rated power |
10 W |
| Design |
|---|
| Market positioning |
Business |
| Product type |
Ultra short throw projector |
| Cable lock slot type |
Kensington |
| Product colour |
Gray |
| Cable lock slot |
Yes |
| Display |
|---|
| Built-in display |
No |
| Power |
|---|
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Power consumption (max) |
400 W |
| Power source |
AC |
| Power consumption (typical) |
250 W |
| Power consumption (standby) |
0.5 W |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
0 - 85% |
| Operating temperature (T-T) |
5 - 40 °C |
| Operating altitude |
0 - 118110.2" (0 - 3000 m) |
| Weight & dimensions |
|---|
| Weight |
15.9 lbs (7.22 kg) |
| Width |
15.1" (383 mm) |
| Depth |
12.5" (318 mm) |
| Height |
4.37" (111 mm) |
| Packaging content |
|---|
| Remote control included |
Yes |
| Manual |
Yes |
| Cables included |
AC |
| Batteries included |
Yes |
| Logistics data |
|---|
| Quantity per pack |
1 pc(s) |
