5PX G2 UPS, 2U, 1440 VA, 1440 W, 5-15P input, Outputs: (8) 5-15R, 120V, Network card
Description
Eaton 5PX G2 UPS, 2U, 1440 VA, 1440 W, 5-15P input, Outputs: (8) 5-15R, 120V, Network card
Specifications
| Power |
|---|
| Input power factor |
1 |
| Output power |
1140 W |
| Input operation voltage (min) |
120 V |
| Input operation voltage (max) |
120 V |
| Efficiency |
98% |
| Output power capacity |
1.44 kVA |
| Input frequency |
50/60 Hz |
| Ports & interfaces |
|---|
| Cable length |
118.1" (3 m) |
| AC outlets quantity |
8 AC outlet(s) |
| AC outlet types |
NEMA 5-15R |
| Power plug |
NEMA 5-15P |
| Performance |
|---|
| UPS topology |
Line-Interactive |
| Features |
|---|
| UPS topology |
Line-Interactive |
| Input power factor |
1 |
| Output power |
1140 W |
| Input operation voltage (min) |
120 V |
| Input operation voltage (max) |
120 V |
| Efficiency |
98% |
| Output power capacity |
1.44 kVA |
| Input frequency |
50/60 Hz |
| Design |
|---|
| Rack capacity |
2U |
| Form factor |
Rackmount/Tower |
| Product colour |
Black |
| Certification |
CULus
RoHS
NOM
ENERGY STAR certified
IEC 62040-1 |
| Cable length |
118.1" (3 m) |
| Display type |
LCD |
| Weight & dimensions |
|---|
| Width |
17.2" (436 mm) |
| Height |
3.43" (87 mm) |
| Depth |
17.6" (447 mm) |
| Packaging data |
|---|
| Rack mount kit |
Yes |
| Quick installation guide |
Yes |
| Cables included |
RS-232, USB cable |
| Certificates |
|---|
| Certification |
CULus
RoHS
NOM
ENERGY STAR certified
IEC 62040-1 |
| Packaging content |
|---|
| Rack mount kit |
Yes |
| Quick installation guide |
Yes |
| Cables included |
RS-232, USB cable |
