| Performance |
|---|
| Infrared (IR) cut-off filter |
Yes |
| Number of languages |
11 |
| Languages support |
Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Portuguese, Russian |
| PTZ modes |
Digital PTZ |
| Type |
IP security camera |
| Connectivity technology |
Wired |
| Placement supported |
Indoor |
| Wide Dynamic Range (WDR) |
Yes |
| Day/night mode |
Yes |
| Design |
|---|
| IK code |
IK08 |
| Form factor |
Dome |
| Product colour |
White |
| Mounting type |
Ceiling/wall |
| International Protection (IP) code |
IP42 |
| Housing material |
Aluminum, Polycarbonate (PC) |
| Camera |
|---|
| Minimum illumination |
0.18 lx |
| Tilt angle range |
-40 - 65° |
| Pan range |
-180 - 180° |
| Camera shutter speed |
1/37500 - 1/5 s |
| Camera pan control |
Yes |
| Camera tilt control |
Yes |
| Progressive scan |
Yes |
| Image sensor |
|---|
| Sensor type |
CMOS |
| Progressive scan |
Yes |
| Optical sensor size |
1/2.7" |
| Number of sensors |
1 |
| Lens system |
|---|
| Number of lenses |
1 |
| Zoom capability |
Yes |
| Focal length range |
3 - 6 mm |
| Night vision |
|---|
| Night vision |
Yes |
| Night vision distance |
20 m |
| LED type |
IR |
| Infra-red wavelength |
855 nm |
| Video |
|---|
| Text caption overlay |
Yes |
| Privacy masking |
Yes |
| Flip & mirror |
Yes |
| Video compression formats |
H.264, H.265 |
| Maximum resolution |
2304 x 1728 pixels |
| Supported video modes |
720p, 1080p |
| Frame rate |
30 fps |
| Video streaming |
Yes |
| Total megapixels |
4 MP |
| Network |
|---|
| Bluetooth |
No |
| Networking standards |
IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
| Quality of Service (QoS) support |
Yes |
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| Supported network protocols |
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSb , TLSb , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, HDMI, LLDP, CDP, MQTT v3.1.1 |
| Storage |
|---|
| Built-in HDD |
No |
| Compatible memory cards |
MicroSD (TransFlash), MicroSDHC, MicroSDXC, SD |
| Internal memory |
1024 MB |
| Flash memory |
512 MB |
| Built-in SSD |
No |
| Ports & interfaces |
|---|
| HDMI ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| Connectivity technology |
Wired |
| Memory |
|---|
| Internal memory |
1024 MB |
| Flash memory |
512 MB |
| Hard drive |
|---|
| Built-in HDD |
No |
| Technical details |
|---|
| Video compression formats |
H.264, H.265 |
| Type |
IP security camera |
| Form factor |
Dome |
| Placement supported |
Indoor |
| Product colour |
White |
| Mounting type |
Ceiling/wall |
| Wide Dynamic Range (WDR) |
Yes |
| Day/night mode |
Yes |
| Progressive scan |
Yes |
| Doesn't contain |
BFR, PVC |
| Security |
|---|
| Alert notification type |
E-mail, Text alert message |
| Video motion detection |
Yes |
| Security algorithms |
EAP-TLS |
| IP address filtering |
Yes |
| HTTPS encryption |
Yes |
| Active tampering alarm |
Yes |
| Password protection |
Yes |
| Material |
|---|
| Housing material |
Aluminum, Polycarbonate (PC) |
| Software |
|---|
| Windows operating systems supported |
Yes |
| Power |
|---|
| Power source type |
PoE |
| Power consumption (max) |
9.7 W |
| Power consumption (typical) |
5 W |
| Certificates |
|---|
| International Protection (IP) code |
IP42 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 45 °C |
| Storage temperature (T-T) |
-40 - 65 °C |
| Operating relative humidity (H-H) |
10 - 85% |
| Storage relative humidity (H-H) |
5 - 95% |
| System requirements |
|---|
| Windows operating systems supported |
Yes |
| Weight & dimensions |
|---|
| Height |
2.8" (71 mm) |
| Diameter |
4.76" (12.1 cm) |
| Weight |
13.2 oz (375 g) |
| Packaging content |
|---|
| Number of cameras |
1 |
| Other features |
|---|
| Video compression formats |
H.264, H.265 |
