Axis 01925-004 security camera Dome IP security camera Indoor & outdoor 1920 x 1080 pixels Wall

Roll over image to zoom in Click on image to zoom

Axis 01925-004 security camera Dome IP security camera Indoor & outdoor 1920 x 1080 pixels Wall

Name: Axis 01925-004 security camera Dome IP security camera Indoor & outdoor 1920 x 1080 pixels Wall
Brand: Axis
SKU: 01925-004
Price: 3819.04 USD
Availability: InStock

Axis

Price:

$3,819.04

Stock:

In stock

Quantity:

1/2" CMOS, 1920x1080px, 60 fps, PTZ, 100-240V, 51W

Key Features

1/2" sensor with 31x optical zoom; Autotracking 2 and orientation aid; IR illumination, D/N functionality, Lightfinder 2.0; Laser focus for precise focus with quick-zoom <1 sec zoom speed; TPM, FIPS 140-2 level 2 certified

Description

AXIS Q6315-LE is a high-speed PTZ camera offering HDTV 1080p resolution. It features IR illumination and day/night functionality for surveillance in pitch darkness. With 31x optical zoom, laser focus for precise focus and quick-zoom functionality, it allows you to easily follow fast-moving objects. It includes orientation aid and autotracking 2 with click and track functionality. Privacy masking with mosaic lets you pixelate whole areas of the scene. Plus, with chameleon masking, it automatically changes the color in the masking depending on the background color of the image. Furthermore, the TPM module ensures secure storage of all cryptographic keys and certificates.

Specifications

Performance
Preset points	Yes
Infrared (IR) cut-off filter	Yes
Fog proof	Yes
Type	IP security camera
Connectivity technology	Wired
PTZ control	Yes
Placement supported	Indoor & outdoor
Tour recording	Yes
Wide Dynamic Range (WDR)	Yes
Day/night mode	Yes
Certification	55032 Class A, EN 55035, IEC 62236-4, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), VCCI Class A, RCM AS/NZS CISPR 32 Class A, CISPR 35, EAC, EN 50121-4, KC KN32 Class A, KC KN35, IEC/EN/UL 62368-1, CAN/CSA C22.2 No. 62368-1, IEC/EN/UL 60950-22, CAN/CSA-C22.2 No. 60950-22, IEC/EN 62471 risk group 2, IEC 60825-1 Class 1, IEC/EN 62262 IK10, IEC/EN 60529 IP66, NEMA 250, Type 4X, NEMA TS 2 (2.2.7–2.2.9), IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, ISO 21207 (Method B)
Design
IK code	IK10
Fog proof	Yes
Form factor	Dome
Product colour	Black, White
Mounting type	Wall
International Protection (IP) code	IP66, IP67
Housing material	Aluminum, Polycarbonate (PC)
Camera
Minimum illumination	0.001 lx
Tilt angle range	-90 - 20°
Tilt speed	550 °/sec
Pan range	0 - 360°
Pan speed	550 °/sec
Camera shutter speed	111000 - 1/2 s
Lens viewing angle, horizontal	60.6°
Lens viewing angle, vertical	36.5°
Progressive scan	Yes
Image sensor
Sensor type	CMOS
Progressive scan	Yes
Optical sensor size	1/2"
Number of sensors	1
Lens system
Number of lenses	1
Maximum aperture number	4.6
Auto focus	Yes
Minimum aperture number	1.36
Zoom capability	Yes
Optical zoom	31x
Digital zoom	12x
Focal length range	6.91 - 214.64 mm
Night vision
Night vision	Yes
Night vision distance	300 m
LED type	IR
Infra-red wavelength	850 nm
Video
Image quality adjustment	Brightness, Color depth, Sharpness
Text caption overlay	Yes
Privacy masking	Yes
Image stabilizer	Yes
Bit rate control	Variable Bit Rate (VBR)
Maximum resolution	1920 x 1080 pixels
Video formats supported	AVC, H.264, H.265, HEVC, M-JPEG, MPEG4
Supported graphics resolutions	320 x 180, 1920 x 1080 (HD 1080)
Frame rate	60 fps
Video streaming	Yes
Network
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Networking standards	IEEE 802.1x, IEEE 802.3bt
Quality of Service (QoS) support	Yes
Streaming method	Multicast
Ethernet LAN	Yes
Supported network protocols	IPv4, IPv6 USGv6, HTTP, HTTPS , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP , SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, SFTP, TCP, RTCP, DHCP, SOCKS, SSH, NTCIP, MQTT v3.1.1, Syslog
Storage
Card reader integrated	Yes
Compatible memory cards	SD, SDHC, SDXC
Flash memory	512 MB
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
Connectivity technology	Wired
Memory
Flash memory	512 MB
Technical details
Type	IP security camera
Form factor	Dome
PTZ control	Yes
Placement supported	Indoor & outdoor
Product colour	Black, White
Mounting type	Wall
Tour recording	Yes
Wide Dynamic Range (WDR)	Yes
Day/night mode	Yes
Progressive scan	Yes
Doesn't contain	PVC
Security
Security algorithms	EAP-TLS
IP address filtering	Yes
HTTPS encryption	Yes
Password protection	Yes
Digest authentication	Yes
Material
Housing material	Aluminum, Polycarbonate (PC)
Management features
Behavior analysis	Line crossing detection
Power
Power source type	AC
Power consumption (max)	51 W
AC input voltage	100-240 V
Power consumption (typical)	17 W
Certificates
International Protection (IP) code	IP66, IP67
Certification	55032 Class A, EN 55035, IEC 62236-4, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), VCCI Class A, RCM AS/NZS CISPR 32 Class A, CISPR 35, EAC, EN 50121-4, KC KN32 Class A, KC KN35, IEC/EN/UL 62368-1, CAN/CSA C22.2 No. 62368-1, IEC/EN/UL 60950-22, CAN/CSA-C22.2 No. 60950-22, IEC/EN 62471 risk group 2, IEC 60825-1 Class 1, IEC/EN 62262 IK10, IEC/EN 60529 IP66, NEMA 250, Type 4X, NEMA TS 2 (2.2.7–2.2.9), IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, ISO 21207 (Method B)
Operational conditions
Operating temperature (T-T)	-50 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 100%
Storage relative humidity (H-H)	5 - 95%
Weight & dimensions
Height	10.3" (261 mm)
Diameter	9.41" (23.9 cm)
Weight	10.6 lbs (4.8 kg)
