15.6-inch, In-Plane Switching, 1920 x 1080, 60 Hz
Description
Make productivity portable with ThinkVision M15. Its stunning form factor is meticulously designed to expand and match the screen real estate of multiple kinds of laptop, this light and slim 15.6-inch FHD resolution mobile monitor weighs just 860g while its head measures a mere 6 mm thick, making it perfect for multi-screen multitasking like spreadsheets in an airport lounge or sharing a presentation with a prospect in a restaurant.
Equipped with two identical USB Type-C ports, the monitor gives users indispensable Power Pass Through capability. That means they can power both the monitor and the laptop with a single power adapter, plugged into one port with a USB Type-C cable connected to the computer from the other port. Or they can simply power M15 from the laptop using just one USB Type-C connection. With safety ever in ThinkVision's minds, the M15 mobile monitor also comes equipped with TÜV Rheinland certified Low Blue Light technology, which protects users from eyestrain caused by certain frequencies of blue light. Simply turn it on with the press of a button.
Specifications
| Display |
|---|
| Display brightness (typical) |
250 cd/m² |
| Screen shape |
Flat |
| Display number of colours |
16.7 million colors |
| Native aspect ratio |
16:9 |
| Colour gamut |
45% |
| Maximum refresh rate |
60 Hz |
| HD type |
Full HD |
| Display technology |
LED |
| Contrast ratio (typical) |
1000:1 |
| Contrast ratio (dynamic) |
3000000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.00706 x 0.00706" (0.179 x 0.179 mm) |
| Viewable size, vertical |
13.5" (34.4 cm) |
| Viewable size diagonal |
7.64" (19.4 cm) |
| Backlight type |
W-LED |
| Display resolution |
1920 x 1080 pixels |
| Response time |
14 ms |
| Display diagonal |
15.6" |
| Response time (fast) |
6 ms |
| Touchscreen |
No |
| Panel type |
IPS |
| Colour gamut standard |
NTSC |
| Anti-glare screen |
Yes |
| Management features |
|---|
| On Screen Display (OSD) |
Yes |
| Design |
|---|
| Certification |
ENERGY STAR
CCC
RoHS
TÜV |
| Product colour |
Black |
| Ports & interfaces |
|---|
| Built-in USB hub |
Yes |
| USB hub version |
2.0 / 3.2 Gen 1 (3.1 Gen 1) |
| USB upstream port type |
USB Type-C |
| USB Type-C downstream ports quantity |
1 |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Number of USB Type-C upstream ports quantity |
1 |
| Technical details |
|---|
| Cable lock slot |
Yes |
| Product colour |
Black |
| Weight (with stand) |
30.3 oz (860 g) |
| Touchscreen |
No |
| Ergonomics |
|---|
| VESA mounting |
Yes |
| Cable lock slot |
Yes |
| Tilt angle range |
0 - 90° |
| On Screen Display (OSD) |
Yes |
| Height adjustment |
Yes |
| Cable lock slot type |
Kensington |
| Tilt adjustment |
Yes |
| Adjustable height (max) |
0.394" (1 cm) |
| Power |
|---|
| Power consumption (max) |
9.5 W |
| Power consumption (standby) |
0.3 W |
| Power consumption (typical) |
8 W |
| Energy efficiency scale |
A to G |
| Energy efficiency class (SDR) |
C |
| Energy consumption (SDR) per 1000 hours |
8 kWh |
| Weight & dimensions |
|---|
| Width (with stand) |
14.2" (360 mm) |
| Depth (with stand) |
4.27" (108.4 mm) |
| Height (with stand) |
9.27" (235.5 mm) |
| Weight (with stand) |
30.3 oz (860 g) |
| Package width |
16.1" (407.9 mm) |
| Package depth |
2.99" (75.9 mm) |
| Package height |
11" (279.9 mm) |
| Package weight |
3.73 lbs (1.69 kg) |
| Packaging data |
|---|
| Package width |
16.1" (407.9 mm) |
| Package depth |
2.99" (75.9 mm) |
| Package height |
11" (279.9 mm) |
| Package weight |
3.73 lbs (1.69 kg) |
| Other features |
|---|
| Certification |
ENERGY STAR
CCC
RoHS
TÜV |
| Power consumption (max) |
9.5 W |
| Energy efficiency scale |
A to G |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Touchscreen |
No |
| Certificates |
|---|
| Certification |
ENERGY STAR
CCC
RoHS
TÜV |
