12GB GDDR6, 15 Gbps, PCI-E 4.0, 7680 x 4320, 8-pin x 1, 192 bits, DISPLAYPORT 1.4a, HDMI 2.1, 550W, 170W
Key Features
- Boost Clock 1807 MHz
- Memory Speed 15 Gbps
- 12GB GDDR6
- DisplayPort x 3 (v1.4a) / HDMI 2.1 x 1
- Afterburner Software - Take full control with the most recognized and widely used graphics card overclocking software in the world
- Two fans and a huge heatsink ensure a cool and quiet experience for you
- Dragon Center - MSI's exclusive Dragon Center software lets you monitor, tweak and optimize MSI products in real-time
- The custom PCB has been engineered with hardened circuits and optimized trace routing for performance and reliability
- The award-winning MSI TORX Fan 3.0 design creates high static pressure and pushes the limits of thermal performance
- An abundance of thermal pads use any chance for additional heat transfer directly from the components
Description
The GeForce RTX 3060 lets you take on the latest games using the power of Ampere—NVIDIA's 2nd generation RTX architecture. Get incredible performance with enhanced Ray Tracing Cores and Tensor Cores, new streaming multiprocessors, and high-speed G6 memory.
Specifications
| Processor |
|---|
| Graphics processor family |
NVIDIA |
| Processor frequency |
1807 MHz |
| Maximum displays per videocard |
4 |
| CUDA cores |
3584 |
| CUDA |
Yes |
| Maximum resolution |
7680 x 4320 pixels |
| Graphics processor |
GeForce RTX 3060 |
| Memory |
|---|
| Discrete graphics card memory |
12 GB |
| Data transfer rate |
15 Gbit/s |
| Memory bus |
192 bit |
| Graphics card memory type |
GDDR6 |
| Ports & interfaces |
|---|
| HDMI version |
2.1 |
| HDMI ports quantity |
1 |
| DisplayPort version |
1.4a |
| DisplayPorts quantity |
3 |
| Interface type |
PCI Express 4.0 |
| Video |
|---|
| DirectX version |
12.0 |
| OpenGL version |
4.6 |
| HDMI version |
2.1 |
| CUDA cores |
3584 |
| Performance |
|---|
| Virtual Reality (VR) ready |
Yes |
| DirectX version |
12.0 |
| OpenGL version |
4.6 |
| Design |
|---|
| Number of fans |
2 fan(s) |
| Cooling type |
Active |
| Power |
|---|
| Supplementary power connectors |
1x 8-pin |
| Power consumption (typical) |
170 W |
| Minimum system power supply |
550 W |
| Technical details |
|---|
| Cooling type |
Active |
| System requirements |
|---|
| Minimum system power supply |
550 W |
| Weight & dimensions |
|---|
| Weight |
23.7 oz (671.3 g) |
| Height |
4.88" (124 mm) |
| Depth |
1.65" (41.9 mm) |
| Packaging data |
|---|
| Package weight |
2.27 lbs (1.03 kg) |
