USB 3.1 Gen2 Type-C, 3 x USB A 3.1, 2 x DisplayPort, HDMI, RJ-45, 240W
Reasons To Buy
Power your connections
Power your day: Dell ExpressCharge allows you to charge up to 80% in one hour , making it the most efficient way to manage the workday.
Adaptable to your workload: Conveniently choose between a single USB-C cable or dual USB-C functionality, a feature compatible with our Precision 7000 workstations. Plus, with magnetically separable USB-C cables, it is easy to get the flexibility you need.
Unmatched charging: Triple your power delivery and charge even faster with a dock that delivers up to 240W of power with dual USB-C connectors.
Built for the future
Mix and match: Evolve as your needs change with our most powerful and reliable dock. The future-ready design lets you swap out modules with ease if you need to do field replacements or upgrade your systems.
Ultimate connectivity: Dual USB-C connectivity makes it easier than ever to deliver power, data, audio and video as well as connect to system peripherals, no matter what system you use. Plus, with support for up to four displays, including a single 5K and dual 4K monitors, you can connect to everything you need.
Clean and clutter-free: Stay productive by mounting your dock behind your monitor or under your desk with the optional, secure VESA Mount, that offers the complete flexibility with the built-in 0.8 meter cable.
Information in a flash: With data transfer speeds of up to 10Gbps, you can stay productive when connected to all your devices.
Optimize your workspace
Smooth and seamless: Work without disruptions utilizing a single firmware on our most manageable docks ever. Plus, with Dell Client Command Suite and Microsoft System Center Configuration Manager, you can quickly and easily update your firmware without rebooting your dock.
Secure manageability: Keep your information safe with MAC Address pass-thru and remote port-disablement. Plus, with features like PXE Boot, Wake-on-LAN and more, it’s easier than ever to stay productive while managing your dock.
Description
Boost your PC’s power up to 240W on the world’s most powerful and first modular Dual USB-C dock with a future-ready design.
Specifications
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
| Host interface |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
| USB 2.0 ports quantity |
0 |
| Ethernet LAN (RJ-45) ports |
1 |
| HDMI ports quantity |
1 |
| HDMI version |
2.0 |
| DisplayPorts quantity |
2 |
| Microphone in |
No |
| Headphone outputs |
0 |
| DC-in jack |
Yes |
| Connectivity technology |
Wired |
| PowerShare |
Yes |
| DisplayPort version |
1.4 |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports |
1 |
| Performance |
|---|
| Maximum digital resolution |
5120 x 2880 pixels |
| On/off switch |
Yes |
| Product colour |
Black |
| Card reader integrated |
No |
| LED indicators |
Yes |
| VESA mounting |
Yes |
| Technical details |
|---|
| Product colour |
Black |
| Harmonized System (HS) code |
84733020 |
| Total carbon footprint (kg of CO2e) |
40.95 |
| Storage |
|---|
| Card reader integrated |
No |
| Power |
|---|
| Power source type |
DC |
| AC input voltage |
120 - 230 V |
| AC input frequency |
50 - 60 Hz |
| Power cable length |
31.5" (0.8 m) |
| Power supply |
240 W |
| Software |
|---|
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64 |
| Linux operating systems supported |
Yes |
| Indication |
|---|
| LED indicators |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 35 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
10 - 80% |
| Storage relative humidity (H-H) |
5 - 90% |
| Weight & dimensions |
|---|
| Weight |
20.6 oz (585 g) |
| Width |
8.07" (205 mm) |
| Depth |
3.54" (90 mm) |
| Height |
1.14" (29 mm) |
| Package width |
11.8" (300 mm) |
| Package depth |
12.4" (315 mm) |
| Package height |
2.44" (62 mm) |
| Design |
|---|
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64 |
| Product colour |
Black |
| LED indicators |
Yes |
| Packaging data |
|---|
| Quantity per pack |
1 pc(s) |
| Package width |
11.8" (300 mm) |
| Package depth |
12.4" (315 mm) |
| Package height |
2.44" (62 mm) |
| Carbon footprint |
|---|
| Total carbon footprint (kg of CO2e) |
40.95 |
| PAIA version |
PAIA/GaBi not used |
| Carbon emissions, energy usage (kg of CO2e) |
5.95 |
| Carbon emissions, manufacturing (kg of CO2e) |
29.8 |
| Carbon emissions, logistics (kg of CO2e) |
7.75 |
| Carbon emissions, end-of-life (kg of CO2e) |
-2.55 |
| Packaging content |
|---|
| Quantity per pack |
1 pc(s) |
| Logistics data |
|---|
| Harmonized System (HS) code |
84733020 |
