HDMI/USB-C, 4K UHD, 18 Gbit/s, 2m, Black
Description
USB-C to HDMI 2.0 Active Cable - 2M, 4K60Hz HDREasily add an HDMI display to your USB-C DisplayPort 1.2 Alternate Mode or Thunderbolt 3 compatible computer, laptop, Ultra Book, tablet, or phone
- Easily converts a DisplayPort Alt 1.2 HBR2 enabled USB Type-C port (Thunderbolt 3 compatible) into a HDMI output allowing you to add an HDMI display
- Note: The USB-C source connection must pass DisplayPort 1.2 video/audio signal, aka DisplayPort Alternate/DisplayPort Alt mode, in order for the audio and video signals to pass through the adapter
- Allows transmission of HDMI Audio and video signals with resolutions of 720p HD, 1080p Full HD, 4K@60Hz YUV 4:4:4 8-bit, and 4K@60Hz YUV 4:2:0 10-bit HDR up to 6.6 ft (2 meters)
- Features USB-C reversible plug design, non-directional plug-in orientation, you will always plug-in the USB-C connector on the first try
- USB-C DisplayPort 1.2 Alt Mode or Thunderbolt 3 technology is available with many computers such as 2016 MacBook Pro, 2015 MacBook, Google Chromebook Pixel, Surface Pro 7, Dell XPS Precision/Latitude, HP Elitebook / Spectre, Thinkpad X1, plus many more
- Plug-n-Play, no driver installation and no external power adapter required
Specifications
| Features |
| Country of origin |
China |
| Chipset |
RTD2172U |
| HDMI version |
2.0 |
| Product colour |
Black |
| Cable length |
78.7" (2 m) |
| Connector 1 |
HDMI |
| Connector 2 |
USB-C |
| Connector 1 gender |
Male |
| Connector 2 gender |
Male |
| Jacket material |
Acrylonitrile butadiene styrene (ABS) |
| Data transfer rate |
18 Gbit/s |
| Maximum resolution |
3840 x 2160 pixels |
| HDCP |
Yes |
| Certification |
FCC, CE, RoHS |
| Connector 1 form factor |
Straight |
| Connector 2 form factor |
Straight |
| Connector gender |
Male/Male |
| HDCP version |
2.2 |
| Operational conditions |
| Operating temperature (T-T) |
0 - 60 °C |
| Storage temperature (T-T) |
-10 - 70 °C |
| Technical details |
| Country of origin |
China |
| Weight & dimensions |
| Weight |
2.4 oz (68 g) |
