PTZ, 1/2.5 Exmor CMOS, 20X, 8.57 MP, FHD, EasyIP, HDMI, RS-232, 12 VDC, PoE+, White
Key Features
- 20x Optical zoom
- 1/2.5-type Exmor R CMOS sensor
- 70.2° horizontal field of view
- One EasyIP (Network PoE+) and one HDMI video output
- Supports up to two EasyIP Mixers or Decoders simultaneously
Description
The EasyIP 20 Camera brings professional AV quality performance to the EasyIP Ecosystem, an AV-over-IP solution for lecture capture, remote learning and videoconferencing in large meeting rooms, lecture halls, and houses of worship. It delivers 1080p/60 resolution feeds to EasyIP endpoints and connects to a 1 GB PoE+ switch – eliminating the need for costly USB extensions. A local HDMI output allows for easy IMAG (image magnification).
Specifications
| Camera |
|---|
| Megapixel (approx.) |
8.57 MP |
| Sensor type |
CMOS |
| Optical zoom |
20x |
| Minimum illumination |
100 lx |
| White balance |
ATW, Auto, Manual, One push, Outdoor |
| Focus adjustment |
Auto/Manual |
| Signal-to-Noise Ratio (SNR) |
60 dB |
| Auto focusing (AF) modes |
Auto, Manual, One Push Trigger |
| Aperture number of steps |
16 |
| Gain control type |
Auto/Manual |
| Effective sensor resolution |
8.51 MP |
| Horizontal field of view (wide) |
74° |
| Horizontal field of view (tele) |
7.6° |
| PTZ control |
Yes |
| Minimum working distance (wide) |
9.02" (22.9 cm) |
| Maximum working distance (tele) |
31.5" (80 cm) |
| Number of camera presets |
16 |
| Wide Dynamic Range (WDR) |
Yes |
| Video |
|---|
| Maximum video resolution |
1920 x 1080 pixels |
| Maximum frame rate |
60 fps |
| Resolution at capture speed |
1920x1080@25fps, 1920x1080@29.97fps, 1920x1080@59.94fps, 1920x1080@60fps |
| Supported video modes |
720p, 1080i, 1080p |
| HD type |
Full HD |
| Design |
|---|
| Product colour |
White |
| Tilt angle range |
-30 - 90° |
| Pan range |
-150 - 150° |
| Web-based management |
Yes |
| Tilt speed (max) |
90 °/sec |
| Pan speed (max) |
0.35 °/sec |
| Ports & interfaces |
|---|
| HDMI ports quantity |
1 |
| Power over Ethernet (PoE) ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| Power |
|---|
| Power source type |
PoE |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
20 - 80 °C |
| Technical details |
|---|
| Harmonized System (HS) code |
85258900 |
| Audio |
|---|
| Noise reduction |
Yes |
| Performance |
|---|
| Remote control function |
Yes |
| Remote control type |
RF Wireless |
| Logistics data |
|---|
| Harmonized System (HS) code |
85258900 |
| Packaging data |
|---|
| Package width |
7.05" (179.1 mm) |
| Package depth |
6.76" (171.6 mm) |
| Package height |
6.94" (176.3 mm) |
| Package weight |
4.85 lbs (2.2 kg) |
