5000 lumens, 2500000:1, 1.07 billion colors, 100 – 240 V, 50/60 Hz
Key Features
- 5,000 lumens of color and white brightness
- Full HD 1080p resolution; project up to 130" (16:9) diagonal
- 20,000-hour laser light engine with no lamps
- Convenient ultra short-throw design
- HDMI, HDBaseT and wireless connectivity
- Built-in edge blending and split screen features for easy, scalable projection
- Content management software and creative content app for easy creation and management of content for digital signage
Description
The budget-friendly classroom projector for high-quality, ultra bright displays.
Create dynamic, captivating classroom displays with the PowerLite 800F ultra short-throw laser projector. Offering 5,000 lumens of brightness1 and Full HD 1080p technology, this versatile projector provides large, true-to-life images up to 130" (16:9) for easy reading from nearly anywhere or use the built-in edge blend feature for an even larger than life experience. A durable and flexible solution, the PowerLite 800F provides ultra short-throw technology for convenient projection in small spaces and includes a virtually maintenance free 20,000-hour optical laser light source engine with no lamps to replace2 for lasting reliability. Presenting a variety of connectivity options, optional wireless and a built-in speaker, the PowerLite 800F offers the features you need to deliver lesson plans with engaging, immersive content on nearly any flat surface.
Specifications
| Projector |
|---|
| Number of colours |
1.07 billion colors |
| White light output |
5000 ANSI lumens |
| Colour light output |
5000 ANSI lumens |
| Projector native resolution |
WXGA (1366x768) |
| Native aspect ratio |
16:9 |
| Supported aspect ratios |
4:3, 16:10, 16:6, 21:9 |
| Screen size compatibility |
65 - 130" |
| Projection distance |
10.6 - 14.6" (0.27 - 0.37 m) |
| Contrast ratio (dynamic) |
2500000:1 |
| Matrix type |
3-panel (p-Si TFT active) |
| Keystone correction, vertical |
3° |
| Keystone correction, horizontal |
3° |
| Projection technology |
3LCD |
| Projector brightness |
5000 ANSI lumens |
| Light source |
|---|
| Light source type |
Laser |
| Service life of light source |
20000 h |
| Lens system |
|---|
| Fixed focal length |
0.154" (3.9 mm) |
| Zoom ratio |
1.35:1 |
| Zoom capability |
Yes |
| Focus |
Manual |
| Throw ratio |
0.27 - 0.37 |
| Zoom type |
Auto |
| Video |
|---|
| Video colour modes |
Blackboard, Cinema, DICOM simulation mode, Dynamic, Multi-projection, Presentation, sRGB |
| Full HD |
Yes |
| 3D |
No |
| Supported video modes |
1080p |
| Ports & interfaces |
|---|
| HDMI connector type |
Full-size |
| HDBaseT port |
Yes |
| USB 2.0 Type-B ports quantity |
1 |
| PC in (D-Sub) |
Yes |
| VGA (D-Sub) ports quantity |
2 |
| HDMI ports quantity |
4 |
| USB 2.0 ports quantity |
3 |
| Composite video in |
1 |
| Serial interface type |
RS-232C |
| DVI port |
No |
| USB 2.0 Type-A ports quantity |
2 |
| Network |
|---|
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Ethernet LAN (RJ-45) ports |
1 |
| Features |
|---|
| Interactive |
No |
| Noise level |
36 dB |
| Country of origin |
China |
| Design |
|---|
| Market positioning |
Education |
| Product type |
Ultra short throw projector |
| Product colour |
White |
| Power |
|---|
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Power source |
AC |
| Power consumption (typical) |
381 W |
| Power consumption (standby) |
2 W |
| Power consumption (PowerSave) |
0.5 W |
| Supplier features |
|---|
| Battery type |
AA |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
20 - 80% |
| Operating temperature (T-T) |
0 - 45 °C |
| Weight & dimensions |
|---|
| Weight |
21.4 lbs (9.71 kg) |
| Width |
18.1" (459.7 mm) |
| Depth |
17.7" (449.6 mm) |
| Height |
9" (228.6 mm) |
| Packaging content |
|---|
| Remote control included |
Yes |
| Battery type |
AA |
| Manual |
Yes |
| Batteries included |
Yes |
