1500VA/1350W, 75 to 146 VAC, 1372J, NEMA 5-15R, VRLA, 438 x 510 x 88 mm, 42.6 kg
Key Features
- Liebert® PSI5 UPS operates at a high 0.9 output power factor
- Battery backup provides ample time for an orderly shutdown of your equipment
- Advanced rotatable LCD screen allows users to view real-time conditions, alarm notices, and runtime information
- Includes a USB port and software for local connectivity and management of the UPS
- The Liebert® TAA-compliant PSI5 UPS can accept external battery cabinets for long runtime applications
- Liebert® PSI5 UPS is compliant with the Restriction of Hazardous Substances Directive (RoHS)
Description
EASY MONITORING: The Vertiv™ Liebert® TAA-compliant PSI5 UPS offers a compact 2U rackmount/tower convertible form-factor, with an LCD panel that rotates 90-degrees to make the readout easy to see in either configuration.The LCD screen allows users to view real-time conditions, alarm notices, and runtime information.
HIGH-END ELECTRONICS: With advanced pure sinewave power conditioning, the Vertiv™ Liebert® PSI5 UPS protects critical IT and electronic equipment against the damage caused by power fluctuations.The Vertiv™ Liebert® PSI5 UPS also allows users to save their data and do an orderly shutdown of their equipment during an extended utility power outage.
Vertiv™ Trade-In Program. Contact a Vertiv partner for discount rates and to calculate your savings.
Not for sale in Vermont, Colorado, Washington.
Specifications
| Power |
|---|
| Output power |
1350 W |
| Input operation voltage (min) |
75 V |
| Input operation voltage (max) |
146 V |
| Output operation voltage (min) |
100 V |
| Output operation voltage (max) |
125 V |
| Power factor |
0.9 |
| Output power capacity |
1.5 kVA |
| Input frequency |
55/65 Hz |
| Ports & interfaces |
|---|
| Cable length |
94.5" (2.4 m) |
| AC outlets quantity |
6 AC outlet(s) |
| AC outlet types |
NEMA 5-15R |
| Power plug |
NEMA 5-15 |
| Ethernet LAN (RJ-45) ports |
1 |
| Network card slot |
Yes |
| Performance |
|---|
| UPS topology |
Line-Interactive |
| Waveform |
Pure sine |
| Automatic Voltage Regulation (AVR) |
Yes |
| Surge protection |
Yes |
| Noise level |
55 dB |
| Features |
|---|
| UPS topology |
Line-Interactive |
| Waveform |
Pure sine |
| Automatic Voltage Regulation (AVR) |
Yes |
| Output power |
1350 W |
| Input operation voltage (min) |
75 V |
| Input operation voltage (max) |
146 V |
| Output operation voltage (min) |
100 V |
| Output operation voltage (max) |
125 V |
| Surge protection |
Yes |
| Power factor |
0.9 |
| Noise level |
55 dB |
| Output power capacity |
1.5 kVA |
| Input frequency |
55/65 Hz |
| Battery |
|---|
| Battery technology |
Sealed Lead Acid (VRLA) |
| Typical backup time at half load |
18 min |
| Typical backup time at full load |
6 min |
| Design |
|---|
| Rack capacity |
2U |
| Form factor |
Rackmount/Tower |
| Product colour |
Black |
| Safety |
UL 1778, c-UL-us Listed |
| Certification |
Emissions FCC Part 15, Class B
UL 497 B |
| Cable length |
94.5" (2.4 m) |
| Network card slot |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-15 - 50 °C |
| Operating relative humidity (H-H) |
20 - 90% |
| Technical details |
|---|
| Compliance certificates |
RoHS, Trade Agreements Act (TAA) |
| Certificates |
|---|
| Certification |
Emissions FCC Part 15, Class B
UL 497 B |
| Compliance certificates |
RoHS, Trade Agreements Act (TAA) |
| Safety |
UL 1778, c-UL-us Listed |
| Safety regulation & standards |
|---|
| Safety |
UL 1778, c-UL-us Listed |
| Weight & dimensions |
|---|
| Package width |
10.2" (258 mm) |
| Package depth |
26.5" (672 mm) |
| Package height |
21.7" (550 mm) |
| Weight |
93.9 lbs (42.6 kg) |
| Width |
17.2" (438 mm) |
| Package weight |
114.2 lbs (51.8 kg) |
| Height |
3.46" (88 mm) |
| Depth |
20.1" (510 mm) |
| Packaging data |
|---|
| Package width |
10.2" (258 mm) |
| Package depth |
26.5" (672 mm) |
| Package height |
21.7" (550 mm) |
| Package weight |
114.2 lbs (51.8 kg) |
