CYBEX SC Universal DP/H Secure Desktop Matrix 2x8 KVM with CAC, PP4.0
Key Features
- View information on two isolated computers simultaneously
- Block unauthorized USB devices while allowing secure switching of smart card and biometric devices between computers·
- Universal video connectors to support DP, HDMI, and DVI-D
- Vertiv™ patented keyboard lock status indication·
- Active intrusion detection and tamper-evident holographic labels prevent hardware from being compromised
Description
The Vertiv™ Cybex™ SCM145DPH secure desktop matrix KVM eliminates the need for multiple monitors, keyboards, mice and cables. The Cybex™ secure desktop matrix switch provides users flexibility by offering a universal video port, freeze DPP and audio channel capabilities as well as touch screen support. The Cybex SCM145DPH comes with native video support up to UHD 4K @ 60Hz and smart-card (CAC) or biometric readers for authentication on any attached computer.
- Designed for Common Criteria Protection Profile for Peripheral Sharing Device (PSD) v.4.0
- Secure KVM switching allows for instantaneous interaction between two computers from different security classifications
- Cursor Navigation Switching (CNS) seamlessly transitions keyboard and mouse control between computers when pressing the left CTRL key and moving the cursor across screen borders
- Native video supports up to UHD 4K at 60 Hz
- Unidirectional data flow of keyboard, mouse, video, and audio
Specifications
| Ports & interfaces |
|---|
| Console ports |
3.5mm headphone, DisplayPort, HDMI, USB A |
| Keyboard port type |
USB |
| Mouse port type |
USB |
| Video port type |
HDMI/DisplayPort |
| Headphone outputs |
1 |
| USB 2.0 Type-B ports quantity |
2 |
| USB 2.0 Type-A hub ports quantity |
3 |
| Console DisplayPorts ports quantity |
2 |
| Performance |
|---|
| HD type |
4K Ultra HD |
| Video bandwidth |
60 Hz |
| Maximum resolution |
3840 x 2160 pixels |
| Technical details |
|---|
| Product colour |
Black |
| Design |
|---|
| Product colour |
Black |
| Certification |
FCC class A, CE, TUV US, TUV Canada, RCM, VCCI |
| Power |
|---|
| Power source |
AC |
| Input voltage |
100 - 240 V |
| Video |
|---|
| HD type |
4K Ultra HD |
| Video bandwidth |
60 Hz |
| Maximum resolution |
3840 x 2160 pixels |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
0 - 80% |
| Weight & dimensions |
|---|
| Width |
17.3" (439 mm) |
| Depth |
7.28" (185 mm) |
| Height |
1.69" (43 mm) |
| Weight |
5.51 lbs (2.5 kg) |
| Certificates |
|---|
| Certification |
FCC class A, CE, TUV US, TUV Canada, RCM, VCCI |
