NETGEAR GS524UP Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Gray

Gigabit Unmanaged Switch Series (GS524UP) 24-Port Gigabit Ethernet High-Power PoE+ Unmanaged Switch with 16-Ports PoE++ (480W)

Key Features

• PLUG-AND-PLAY - Simple set up with no software or configuration needed
• POWER-OVER-ETHERNET: impressive 480W PoE budget with 16 Ultra60 PoE++ ports and 8 PoE+ ports to power wireless AP, 4K/8K IP Cameras, LED lights, IoT devices, and much more
• COMPACT, FLEXIBLE FORM FACTOR – Small case with internal power supply and whisper-quiet fans, perfect for desktop, wall-mount, or rackmount deployment
• EASY-MONITORING - Per port LEDs for port activity and speed
• GIGABIT ETHERNET – 24 auto-sensing 10/100/1000 Mbps Gigabit Ethernet ports with up to 48Gb non-blocking switching
• PoE AUTO-BALANCE - unique PoE technology automatically balances the PoE power based on the device needs independent of PoE class detected. The switches deliver the power the device needs, at the most granular level

Description

Instant Connectivity and Reliable Performance
The NETGEAR Gigabit Unmanaged Switch series helps your business cost-effectively expand your network to Gigabit speeds and higher port counts. The GS524UP joins the series and offers 16 Ultra60 PoE++ ports and 8 PoE+ ports to power high-power PoE devices. With a total PoE power budget of 480W, deploy denser PoE+ and PoE++ devices to a single switch rather than multiple.
The GS524UP is energy efficient, built to last, and rigorously tested to provide the reliability your business needs. 802.1p traffic prioritization and jumbo frame support allow for seamless integration with more sophisticated networks.

Powerful Ultra60 PoE++
Ideal for powering and connecting 802.11AX wireless access points, 4K/8K IP surveillance cameras, PoE lighting, and high power audio speakers, the GS524UP gives you a highly cost-effective and powerful switch with the best cost/PoE budget ratio.
NETGEAR Ultra60 PoE++ Unmanaged Switches support the latest Energy Efficient Ethernet (IEEE 802.3bt) standard, powerful enough to support devices that require greater power. The GS524UP includes 16 PoE++ ports that can deliver up to 60W of power per port.

PoE Mode
Your business is always changing and growing, but not all your devices may be 802.3bt standard compatible. PoE mode on the GS524UP solves this problem by providing power to both pre-bt and bt standard devices.
- GS524UP by default uses 802.3bt standard, only compatible for bt standard devices
- 802.3bt Standard Devices: to power bt standard devices, select 802.3bt mode to receive 60W of power
- Pre-802.3bt Standard Devices: to power up pre-802.3bt standard products, select the pre-802.3bt mode to receive more than 30W of power
- If the GS524UP is set to pre-802.3bt mode but the device is standard 802.3bt, then PoE++ power will not be delivered to the device. The switch will only deliver 802.3af (<15W)

Specifications

Technical details
Form factor	1U
Product colour	Gray
Mean time between failures (MTBF)	809853.3 h
Housing material	Metal
Rack mounting	Yes
Management features
Switch type	Unmanaged
Quality of Service (QoS) support	Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Network
Networking standards	IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3i, IEEE 802.3p, IEEE 802.3u
Full duplex	Yes
Auto MDI/MDI-X	Yes
10G support	No
Half duplex	Yes
Data transmission
Packet forwarding rate (1 Gbps)	1448000 pps
Latency (1 Gbps)	12 µs
MAC address table	8000 entries
Switching capacity	48 Gbit/s
Design
Form factor	1U
Product colour	Gray
LED indicators	Activity, Link, PoE
Housing material	Metal
Rack mounting	Yes
Number of fans	2 fan(s)
Performance
Mean time between failures (MTBF)	809853.3 h
Indication
LED indicators	Activity, Link, PoE
Power
Power consumption (max)	578.8 W
Power supply included	Yes
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Input current	8 - 4 A
Power source	PoE
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port	60 W
Power over Ethernet plus (PoE+) ports quantity	24
Total Power over Ethernet (PoE) budget	480 W
Power over Ethernet (PoE)	Yes
Operational conditions
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90%
Operating altitude	0 - 118110.2" (0 - 3000 m)
Heat dissipation	1976.0232 BTU/h
Weight & dimensions
Width	15.4" (390 mm)
Depth	8.66" (220 mm)
Height	1.69" (43 mm)
Weight	6.83 lbs (3.1 kg)
