Wireless Ultra-Rugged Area-Imaging Scanner
Key Features
- Built to survive harsh treatment including 3 m (10 ft) drops, 7,000 1 m (3.3 ft) tumbles, operating temperatures from -30°C to 50°C (-22°F to 122°F) and IP67 sealing, Granit XP reduces service costs and increases device uptime
- Granit provides extreme performance scanning, even on damaged and low-quality barcodes. High-quality barcodes scan and transmit faster than ever
- The XR model is ideally suited to normal, near-field scanning operations on 1D and 2D barcodes, plus eXpanded Range scanning of UPC to 1.5 m (5 ft) and 100 mil codes to 10 m (33 ft)
- Honeywell Operational Intelligence software delivers on-demand scan insights, enabling higher employee productivity and throughput
- The Honeywell Scanner Management Utility (SMU) creates a holistic solution that automates how you deploy and update the scanners in your environment
Description
Ensure maximum productivity and uptime with Granit™ 1991iXR expanded range ultra-rugged barcode scanner. Best-in-class durability ensures low TCO. Premium scanning performance ensures even damaged or low quality codes scan quickly. Granit XP expands capabilities and redefines ultra-rugged scanning.
Following a legacy of successful deployments, the next generation Granit™ XP scanners expand capabilities and redefine ultra-rugged scanning. With a best-in-class 10’ drop spec, Granit™ XP is engineered to keep on working after the impact of drops from loading docks, fork trucks, and picking trucks. The 1 meter (3.3 foot) tumble test indicates long term durability with daily knocks and drops from workstation or waist height. A best-in-class 7,000 tumble specification ensures Granit™ scanners will be ready to work for the long term. And IP67 dust and moisture sealing protect scanning performance under harsh treatment.
With FlexRange technology, Granit 1991iXR model begins with no-sacrifice near field scanning, and expand that to read UPC codes to 1.5m (5 ft) and 100 mil (2.54mm) rack labels at 10m (33 ft), seamlessly handling many warehouse/distribution center and manufacturing workflows. Bad labels commonly occur in the warehouse/DC and industrial space due to low quality printing or damage during handling. Granit XP, built on Honeywell’s next-generation imaging platform, ensures that otherwise challenging labels do not create a bottleneck in your process.
The Granit™ XP 1991iXR model offers high-durability, extreme performance scanning for scanning operations from contact to the top rack of the warehouse. Created for applications where high speed scanning is needed to maximize productivity, and where durability is non-negotiable for low total cost of ownership, the Granit™ XP 1991iXR scanner offers the optimal solution.
Specifications
| Scanning |
|---|
| Type |
Handheld bar code reader |
| Scanner type |
1D/2D |
| Optical sensor resolution (W x H) |
1280 x 800 pixels |
| Ports & interfaces |
|---|
| Connectivity technology |
Wired & Wireless |
| Bluetooth version |
4.2 |
| Standard interfaces |
Keyboard wedge, RS-232, USB |
| Performance |
|---|
| International Protection (IP) code |
IP65, IP67 |
| Product colour |
Black, Red |
| Design |
|---|
| Type |
Handheld bar code reader |
| International Protection (IP) code |
IP65, IP67 |
| Product colour |
Black, Red |
| Power |
|---|
| Power source type |
Battery |
| Power consumption (typical) |
5 W |
| Power consumption (standby) |
0.6 W |
| Number of reads per charge |
50000 |
| Input voltage |
4 - 5.5 V |
| Battery type |
Built-in battery |
| Battery technology |
Lithium-Ion (Li-Ion) |
| Weight & dimensions |
|---|
| Width |
2.99" (76 mm) |
| Depth |
3.94" (100 mm) |
| Height |
7.56" (192 mm) |
| Technical details |
|---|
| Type |
Handheld bar code reader |
| International Protection (IP) code |
IP65, IP67 |
| Product colour |
Black, Red |
| Harmonized System (HS) code |
84716070 |
| Operational conditions |
|---|
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating temperature (T-T) |
-20 - 50 °C |
| Logistics data |
|---|
| Harmonized System (HS) code |
84716070 |
