Thermaltake PS-TPD-0600NNFAG –600W, 600 W, 100 - 240 V, 720 W, 47 - 63 Hz, 10 A, Active
Description
Thermaltake PS-TPD-0600NNFAG –600W. Total power: 600 W, AC input voltage: 100 - 240 V, Peak power: 720 W. Motherboard power connector: 24-pin ATX, Motherboard power cable length: 23.6" (60 cm), SATA power cable length: 150,500 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product color: Black, Cooling type: Active, Fan diameter: 5.51" (14 cm). Width: 5.91" (150 mm), Depth: 3.39" (86 mm), Height: 5.51" (140 mm)
Specifications
| Cooling |
|---|
| Fan diameter |
5.51" (14 cm) |
| Cooling type |
Active |
| Design |
|---|
| 80 PLUS certification |
80 PLUS Gold |
| Product colour |
Black |
| Fan diameter |
5.51" (14 cm) |
| Illumination |
No |
| Cooling type |
Active |
| Power |
|---|
| Total power |
600 W |
| Peak power |
720 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
47 - 63 Hz |
| Input current |
10 A |
| Power Factor Correction (PFC) type |
Active |
| Combined power (+3.3V) |
110 W |
| Combined power (+12V) |
588 W |
| Combined power (+5V) |
110 W |
| Combined power (-12V) |
3.6 W |
| Combined power (+5Vsb) |
12.5 W |
| Max output current (+3.3V) |
20 A |
| Max output current (+12V) |
49 A |
| Max output current (+5V) |
20 A |
| Max output current (-12V) |
0.3 A |
| Max output current (+5Vsb) |
2.5 A |
| Number of +12V rail(s) |
1 |
| Ports & interfaces |
|---|
| Motherboard power cable length |
23.6" (60 cm) |
| SATA power cable length |
150,500 mm |
| CPU power cable length |
25.6" (65 cm) |
| Motherboard power connector |
24-pin ATX |
| Number of SATA power connectors |
8 |
| Peripheral (Molex) power connectors (4-pin) |
4 |
| PCI Express power connectors (6+2 pin) |
2 |
| CPU P4 connector (4-pin) |
1 |
| CPU power connector (4+4 pin) |
Yes |
| Cabling type |
Non-Modular |
| EPS power connector (4+4 pin) |
Yes |
| Performance |
|---|
| Power supply unit (PSU) form factor |
ATX |
| 80 PLUS certification |
80 PLUS Gold |
| Purpose |
PC |
| Noise level |
26.5 dB |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating relative humidity (H-H) |
20 - 90% |
| Storage relative humidity (H-H) |
5 - 95% |
| Weight & dimensions |
|---|
| Width |
5.91" (150 mm) |
| Depth |
3.39" (86 mm) |
| Height |
5.51" (140 mm) |
| Certificates |
|---|
| 80 PLUS certification |
80 PLUS Gold |
