| Performance |
|---|
| Infrared (IR) cut-off filter |
Yes |
| Type |
IP security camera |
| Connectivity technology |
Wired |
| PTZ control |
Yes |
| Placement supported |
Outdoor |
| Wide Dynamic Range (WDR) |
Yes |
| Day/night mode |
Yes |
| Certification |
EN 50130-4, EN 55032 A, EN 55035, IEC/EN 61000-6-1,
IEC/EN 61000-6-2, FCC 15 B A,
ICES-3(A)/NMB-3(A), VCCI A, KC KN-32 A, KC KN-35, RCM AS/NZS CISPR 32 A, CISPR 24, CISPR 35
IEC/EN/UL 62368-1, CAN/CSA C22.2 No. 62368-1, IEC/EN 62471
EN 50130–5 I, IEC 60068-2-1, IEC 60068-2-2,
IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27,
IEC 60068-2-78, IEC/EN 60529 IP66, EN 60529 IP69,
ISO 20653 IP6K9K, IEC/EN 62262 IK10+, NEMA 250 4X
NIST SP500-267 |
| Design |
|---|
| IK code |
IK10+ |
| Form factor |
Dome |
| Product colour |
White |
| Mounting type |
Ceiling/wall |
| International Protection (IP) code |
IP66, IP69, IP69K |
| Housing material |
Stainless steel |
| Camera |
|---|
| Minimum illumination |
0 lx |
| Camera shutter speed |
1/32500 - 1/5 s |
| Camera pan control |
No |
| Camera tilt control |
No |
| Lens viewing angle, horizontal |
125° |
| Lens viewing angle, vertical |
95° |
| Progressive scan |
Yes |
| Image sensor |
|---|
| Sensor type |
CMOS |
| Progressive scan |
Yes |
| Optical sensor size |
1/2.5" |
| Number of sensors |
1 |
| Lens system |
|---|
| Number of lenses |
1 |
| Maximum aperture number |
2 |
| Fixed focus |
Yes |
| Fixed focal length |
0.0945" (2.4 mm) |
| Night vision |
|---|
| Night vision |
Yes |
| Night vision distance |
15 m |
| LED type |
IR |
| Infra-red wavelength |
940 nm |
| Video |
|---|
| Image quality adjustment |
Brightness, Contrast, Saturation, Sharpness |
| Text caption overlay |
Yes |
| Bit rate control |
Variable Bit Rate (VBR) |
| Video compression formats |
AVC, H.264, H.265, HEVC, M-JPEG |
| Maximum resolution |
2304 x 1728 pixels |
| Supported graphics resolutions |
320 x 240, 2304 x 1728 |
| Frame rate |
30 fps |
| Video streaming |
Yes |
| Audio |
|---|
| Voice codecs |
G.711, G.726, OPUS |
| Sample rate |
48 kHz |
| Built-in microphone |
Yes |
| Audio system full duplex |
Yes |
| Audio system |
2-way |
| Network |
|---|
| Bluetooth |
No |
| Ethernet interface type |
Fast Ethernet |
| Networking standards |
IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| Supported network protocols |
IPv4,IPv6 USGv6, HTTP, HTTPS , SSL/TLS , QoS L3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP , SNMP v1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, LLDP, SIP |
| Storage |
|---|
| Card reader integrated |
Yes |
| Built-in HDD |
No |
| Compatible memory cards |
MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Internal memory |
1024 MB |
| Flash memory |
512 MB |
| Ports & interfaces |
|---|
| Terminal block port |
Yes |
| HDMI ports quantity |
1 |
| Microphone in |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Connectivity technology |
Wired |
| Memory |
|---|
| Internal memory |
1024 MB |
| Flash memory |
512 MB |
| Hard drive |
|---|
| Built-in HDD |
No |
| Technical details |
|---|
| Video compression formats |
AVC, H.264, H.265, HEVC, M-JPEG |
| Type |
IP security camera |
| Form factor |
Dome |
| PTZ control |
Yes |
| Placement supported |
Outdoor |
| Product colour |
White |
| Mounting type |
Ceiling/wall |
| Wide Dynamic Range (WDR) |
Yes |
| Day/night mode |
Yes |
| Progressive scan |
Yes |
| Security |
|---|
| Video motion detection |
Yes |
| Security algorithms |
EAP-TLS, FIPS 140-2 |
| HTTPS encryption |
Yes |
| Password protection |
Yes |
| Material |
|---|
| Housing material |
Stainless steel |
| Power |
|---|
| Power source type |
PoE |
| Power consumption (max) |
10.8 W |
| Power consumption (typical) |
4.7 W |
| Certificates |
|---|
| International Protection (IP) code |
IP66, IP69, IP69K |
| Certification |
EN 50130-4, EN 55032 A, EN 55035, IEC/EN 61000-6-1,
IEC/EN 61000-6-2, FCC 15 B A,
ICES-3(A)/NMB-3(A), VCCI A, KC KN-32 A, KC KN-35, RCM AS/NZS CISPR 32 A, CISPR 24, CISPR 35
IEC/EN/UL 62368-1, CAN/CSA C22.2 No. 62368-1, IEC/EN 62471
EN 50130–5 I, IEC 60068-2-1, IEC 60068-2-2,
IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27,
IEC 60068-2-78, IEC/EN 60529 IP66, EN 60529 IP69,
ISO 20653 IP6K9K, IEC/EN 62262 IK10+, NEMA 250 4X
NIST SP500-267 |
| Weight & dimensions |
|---|
| Width |
8.23" (209 mm) |
| Depth |
6.93" (176 mm) |
| Height |
5.16" (131 mm) |
| Weight |
3.53 lbs (1.6 kg) |
| Packaging content |
|---|
| Number of cameras |
1 |
| Other features |
|---|
| Video compression formats |
AVC, H.264, H.265, HEVC, M-JPEG |
| Logistics data |
|---|
| Harmonized System (HS) code |
85258900 |
