| Scanning |
| Output greyscale depth |
8 bit |
| Output monochrome depth |
24 bit |
| Maximum scan size |
12 x 220" (304.8 x 5588 mm) |
| Optical scanning resolution |
600 x 600 DPI |
| Colour scanning |
Yes |
| Duplex scanning |
Yes |
| Input colour depth |
30 bit |
| Output colour depth |
24 bit |
| Input greyscale depth |
10 bit |
| Sensor type |
Dual CIS |
| Light source |
White LED |
| Scan file formats |
BMP, JPEG, PDF, PNG, PPTX, TIFF, XLSX |
| Daily duty cycle (max) |
40000 pages |
| Scan to |
E-mail, FTP, HTTP, PC, USB |
| Design |
| Built-in display |
Yes |
| Touchscreen |
Yes |
| Scanner type |
Sheet-fed scanner |
| Display diagonal |
2.7" |
| Display |
LCD |
| Product colour |
White |
| Colour display |
Yes |
| Performance |
| Sensor type |
Dual CIS |
| Light source |
White LED |
| Scan file formats |
BMP, JPEG, PDF, PNG, PPTX, TIFF, XLSX |
| Daily duty cycle (max) |
40000 pages |
| Scan to |
E-mail, FTP, HTTP, PC, USB |
| Scan drivers |
ICA,ISIS,TWAIN,WIA |
| Scanning noise level |
67 dB |
| Ultrasonic double sheet detection |
Yes |
| Sound pressure level (max) |
53 dB |
| Input capacity |
| Auto document feeder (ADF) input capacity |
120 sheets |
| Paper handling |
| Maximum ISO A-series paper size |
A3 |
| Scanning media types supported |
Business Card, Plastic Card, Post Card(JPN) |
| Maximum scan area (ADF) |
12 x 220" (304.8 x 5588 mm) |
| Minimum scan area (ADF) |
2 x 2.72" (50.8 x 69 mm) |
| Auto Document Feeder (ADF) media weight |
20 - 413 g/m² |
| Legal |
Yes |
| ISO A-series sizes (A0...A9) |
A3,A4,A5,A6,A7,A8 |
| Ports & interfaces |
| USB port |
Yes |
| USB version |
3.2 Gen 1 (3.1 Gen 1) |
| Software |
| Windows operating systems supported |
Windows 10,Windows 7,Windows 8,Windows 8.1,Windows Vista,Windows XP |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Server operating systems supported |
Windows Server 2003,Windows Server 2008,Windows Server 2008 x64,Windows Server 2012 R2,Windows Server 2016 |
| Bundled software |
Epson Document Capture (Mac), Epson Document Capture Pro (Windows), Epson Scan 2 |
| Scan drivers |
ICA,ISIS,TWAIN,WIA |
| Sound emission |
| Scanning noise level |
67 dB |
| Power |
| Power consumption (typical) |
20 W |
| Power consumption (standby) |
11 W |
| Power consumption (off) |
0.1 W |
| Input voltage |
100 - 240 V |
| Power supply type |
AC |
| Power consumption (sleep) |
1.4 W |
| Sleep mode |
Yes |
| Display |
| Touchscreen |
Yes |
| Display diagonal |
2.7" |
| Display |
LCD |
| Media formats |
| Legal |
Yes |
| ISO A-series sizes (A0...A9) |
A3,A4,A5,A6,A7,A8 |
| Packaging data |
| Quantity per pack |
1 pc(s) |
| Technical details |
| Scanner type |
Sheet-fed scanner |
| Product colour |
White |
| System requirements |
| Windows operating systems supported |
Windows 10,Windows 7,Windows 8,Windows 8.1,Windows Vista,Windows XP |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Server operating systems supported |
Windows Server 2003,Windows Server 2008,Windows Server 2008 x64,Windows Server 2012 R2,Windows Server 2016 |
| Operational conditions |
| Operating temperature (T-T) |
5 - 35 °C |
| Storage temperature (T-T) |
25 - 60 °C |
| Operating relative humidity (H-H) |
15 - 80% |
| Storage relative humidity (H-H) |
15 - 85% |
| Weight & dimensions |
| Width |
14.6" (371 mm) |
| Depth |
8.19" (208 mm) |
| Height |
8.62" (219 mm) |
| Weight |
12.8 lbs (5.8 kg) |
| Packaging content |
| Cables included |
USB |
| Bundled software |
Epson Document Capture (Mac), Epson Document Capture Pro (Windows), Epson Scan 2 |
| Other features |
| Scanner type |
Sheet-fed scanner |
| Quantity per pack |
1 pc(s) |
| Logistics data |
| Quantity per pack |
1 pc(s) |
