GS324P, 24x 1G RJ-45, 48 Gbps, 192 KB, QoS, PoE, 100-240V AC, 330x206x43 mm
Key Features
- ETHERNET PORT CONFIGURATION: 24 Gigabit ports
- POWER-OVER-ETHERNET: 16 PoE+ ports with 190W total power budget to power wireless AP, IP Cameras, IP Phones and much more
- PLUG-AND-PLAY: Simple set up with no software to install or configuration needed
- VERSATILE MOUNTING OPTIONS: Supports desktop, or rackmount placement, and includes all the necessary mounting hardware in the box
- PoE POWER AUTO-BALANCE AND ALLOCATION - NETGEAR’s unique PoE technology automatically balances the PoE power at the most granular level on each port, depending on the device needs
- QUIET OPERATION: Ideal for noise-sensitive environments
- ENERGY EFFICIENT: Designed to optimize power usage lowering its cost to operate. Compliant with IEEE802.3az Energy Efficient Ethernet mode
- BUILT TO LAST: Every NETGEAR Network switch is rigorously tested for reliability, quality, and performance
Description
The NETGEAR SOHO Ethernet Unmanaged Switches provide easy and affordable network connectivity to small offices and home/offices. They are easy to use, reliable, and rugged with metal enclosures. Power-over-Ethernet (PoE) support is also available for supplying both power and data across a single CAT-5 ethernet cable to devices such as IP security cameras, VoIP phones, wireless access points, etc. With these Plug-and-Play switches, you can quickly and easily expand your network connections to multiple devices, with no configuration required. Available with 5 ports to 48 ports, these switches also support energy saving technologies to help you save power and money.
Specifications
| Performance |
|---|
| Packet buffer memory |
0.192 MB |
| Auto-negotiation |
No |
| Mean time between failures (MTBF) |
1193574 h |
| Technical details |
|---|
| Form factor |
1U |
| Product colour |
Black |
| Mean time between failures (MTBF) |
1193574 h |
| Housing material |
Metal |
| Rack mounting |
Yes |
| Management features |
|---|
| Switch type |
Unmanaged |
| Quality of Service (QoS) support |
Yes |
| Ports & interfaces |
|---|
| Basic switching RJ-45 Ethernet ports quantity |
24 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Network |
|---|
| Networking standards |
IEEE 802.1p, IEEE 802.3at |
| Full duplex |
Yes |
| Auto MDI/MDI-X |
Yes |
| 10G support |
No |
| Auto-negotiation |
No |
| Data transmission |
|---|
| Packet forwarding rate (1 Gbps) |
1448000 pps |
| Jumbo frames |
10000 |
| Latency (1 Gbps) |
4 µs |
| Packet buffer memory |
0.192 MB |
| MAC address table |
8000 entries |
| Switching capacity |
48 Gbit/s |
| Jumbo frames support |
Yes |
| Security |
|---|
| Queue scheduling algorithms |
Weighted Round Robin (WRR) |
| Certificates |
|---|
| Electromagnetic compatibility |
CE, FCC 15 A, IC A, RCM, VCCI, KC |
| Certification |
CB, CE LVD, UL |
| Memory |
|---|
| Packet buffer memory |
0.192 MB |
| Design |
|---|
| Form factor |
1U |
| Product colour |
Black |
| LED indicators |
Activity, Link, PoE, Power, Speed |
| Housing material |
Metal |
| Electromagnetic compatibility |
CE, FCC 15 A, IC A, RCM, VCCI, KC |
| Certification |
CB, CE LVD, UL |
| Rack mounting |
Yes |
| Number of fans |
1 fan(s) |
| Indication |
|---|
| LED indicators |
Activity, Link, PoE, Power, Speed |
| Power |
|---|
| Power consumption (max) |
210 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Input current |
3 A |
| Power over Ethernet (PoE) |
|---|
| Power over Ethernet (PoE) power per port |
30 W |
| Total Power over Ethernet (PoE) budget |
190 W |
| Power over Ethernet (PoE) ports quantity |
16 |
| Power over Ethernet (PoE) |
Yes |
| Operational conditions |
|---|
| Storage temperature (T-T) |
-20 - 70 °C |
| Storage relative humidity (H-H) |
10 - 95% |
| Operating temperature (T-T) |
0 - 45 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Operating altitude |
0 - 118110.2" (0 - 3000 m) |
| Heat dissipation |
718.2 BTU/h |
| Weight & dimensions |
|---|
| Width |
13" (330 mm) |
| Depth |
8.11" (206 mm) |
| Height |
1.69" (43 mm) |
| Weight |
5.38 lbs (2.44 kg) |
