RoHS 6 Compliant 1GFC/2GFC/GE 850nm -20 to 85C SFP Transceiver
Description
Finisar's FTLF8519P3BNL Small Form Factor Pluggable (SFP) transceivers are compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA). They are simultaneously compatible with Gigabit Ethernet as specified in IEEE Std 802.3 and Fibre Channel FC- PI-2 Rev. 5.0. They are RoHS compliant and lead-free per Directive 2002/95/EC and Finisar Application Note AN-2038. Digital diagnostics functions are available via the 2-wire serial bus specified in the SFP MSA.
- Up to 2.125 Gb/s bi-directional data links
- Hot-pluggable SFP footprint
- Built-in digital diagnostic functions
- 850 nm Oxide VCSEL transmitter
- Duplex LC connector
- RoHS compliant and Lead-Free
- Up to 500m on 50/125 µm MMF, 300m on 62.5/125 µm MMF
- Metal enclosure, for lower EMI
- Single 3.3 V power supply
- <500mW power dissipation
- Extended operating temperature range: -20°C to 85°C
Specifications
| Performance |
|---|
| SFP transceiver type |
Fiber optic |
| Interface type |
SFP |
| Maximum data transfer rate |
2000 Mbit/s |
| Fiber optic connector |
LC |
| Maximum transfer distance |
19685" (500 m) |
| Wavelength |
850 nm |
| Fiber cable diameters supported (core/cladding) |
50/125 µm |
| Multi-mode fiber (MMF) supported |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-25 - 85 °C |
| Network |
|---|
| SFP transceiver type |
Fiber optic |
| Interface type |
SFP |
| Maximum data transfer rate |
2000 Mbit/s |
| Fiber optic connector |
LC |
