4-Port, 1xRS232, 1800 mm
Key Features
- Simple to use and install
- Eliminate desk clutter
- Easy channel switching with clear indication of the channel selected
- Compatible with four and eight port Cybex SC switches and Avocent SV switches
- Adjustable button light intensity for changes in ambient light
- Cybex AFP may be placed up to 6 feet from Cybex SC switches
- Disable Cybex SC switch's front panel buttons to prevent erroneous channel selection
- No external power required
- Communicates via standard RS232 which can be integrated with video wall controllers such as Crestron
Description
Simple to use and installThe AFP is a dedicated device that only requires its built-in cable be connected to the Cybex SC Switch’s RCU (Remote Control Unit) port.
Improve situational awarenessBy placing the AFP within the user’s field of view, such as on top of the display, the user sees which channel is selected while they are working.
Designed for both desk or display mountingThe AFP can be mounted on top of the display or on the desk.
Ideal for ergonomic sit-stand desks: Using the Cybex AFP means the Cybex SC switch may remain under the desk and only the peripheral keyboard, mouse, card reader, monitor, and AFP cables must extend with the desks movement.
Specifications
| Ports & interfaces |
|---|
| Cable length |
70.9" (1.8 m) |
| Keyboard port type |
USB |
| Mouse port type |
USB |
| Video port type |
HDMI |
| Ethernet LAN (RJ-45) ports |
1 |
| Technical details |
|---|
| Product colour |
Black, White |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Design |
|---|
| Product colour |
Black, White |
| Cable length |
70.9" (1.8 m) |
| Certification |
FCC class B, CE, ICES class B, RCM, VCCI |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
0 - 80% |
| Weight & dimensions |
|---|
| Width |
6.5" (165 mm) |
| Depth |
1.34" (34 mm) |
| Height |
0.669" (17 mm) |
| Weight |
2.12 oz (60 g) |
| Certificates |
|---|
| Certification |
FCC class B, CE, ICES class B, RCM, VCCI |
| Logistics data |
|---|
| Harmonized System (HS) code |
85176200 |
