USB HDMI HDBaseT™ 2.0 KVM Extender (4K@100 m)
Key Features
- Supports HDBaseT™ 2.0 technology
- • Extends video, audio, USB, RS-232, and Ethernet1 signals via a single Cat6 / 6a cable / 2L-2910 Cat 6 cable
- • Enhanced bit error detection and correction to resist signal interference during high-quality video transmissions
- • Status detection and LED indication for HDBaseT™ signal transmission on remote unit
- EDID Buffer for smooth power-up and the highest quality display
- HDMI (3D, Deep Color, 1080P, 4K); HDCP 2.2 Compatible
- Long distance with superior video quality
- • HDBaseT™ Standard mode up to 4K @ 100 m (Cat 6 / 6a / 2L-2910)
- • HDBaseT™ Long-Reach mode up to 1080P @ 150 m
- Long Reach mode switch – switches between HDBaseT™ Standard and Long Reach modes in a snap
- Supports individual 2-channel stereo audio and USB 2.0 full speed ports
- Supports PC wakeup function via single pushbutton through RS-232 channel2
- Built-in 8KV / 15KV ESD protection (Contact voltage 8KV; Air voltage 15KV)
- Note:
- 1. The CE820-AT supports Ethernet function, and the CE820-ATA does not.
- 2. The computer has to support Wake Up Ring for this function to work.
Description
The ATEN CE820 USB HDMI HDBaseT™ 2.0 KVM Extender integrates the latest HDBaseT™ 2.0 technologies to deliver 4K HDMI video, stereo audio, USB, Ethernet*, and RS-232 signals up to 100 meters using single Cat6 / 2L-2910 Cat 6 cable. The HDBaseT™ 2.0 guarantees the most reliable transmission on the market as well as enables the long-reach capability that extends full HD 1080P signals up to 150 meters. With an easy cable installation supporting various signals, the CE820 is ideal for applications where convenient remote access is required – such as transportation control centers, medical facilities, industrial warehouses, and extended workstations.
* Note: The CE820-AT supports Ethernet function and the CE820-ATA does not.
Specifications
| Features |
|---|
| Type |
Transmitter & receiver |
| Connectivity technology |
Wired |
| Maximum transfer distance |
5905.5" (150 m) |
| Cable types supported |
Cat5e, Cat6, Cat6a |
| Rack mounting |
Yes |
| Maximum digital resolution |
4096 x 2160 pixels |
| Product colour |
Black |
| Material |
Metal |
| USB 2.0 ports quantity |
4 |
| LED indicators |
Link, Power, Video |
| Transmitter |
|---|
| Transmitter video port type |
HDMI |
| Transmitter local video port |
Yes |
| Transmitter local video port type |
HDMI |
| Transmitter local keyboard/mouse port type |
USB |
| RJ-45 ports quantity (transmitter) |
1 |
| Receiver |
|---|
| Receiver local video port type |
HDMI |
| Receiver local keyboard/mouse port type |
USB |
| RJ-45 ports quantity (receiver) |
1 |
| Ports & interfaces |
|---|
| USB 2.0 ports quantity |
4 |
| Power |
|---|
| AC adapter output voltage |
5 V |
| Power consumption (transmitter) (max) |
2.87 W |
| Power consumption (receiver) (max) |
5.37 W |
| Weight & dimensions |
|---|
| Transmitter width |
7.17" (18.2 cm) |
| Transmitter depth |
4.8" (12.2 cm) |
| Transmitter height |
1.13" (2.87 cm) |
| Transmitter weight |
22.2 oz (630 g) |
| Receiver width |
7.17" (18.2 cm) |
| Receiver depth |
4.8" (12.2 cm) |
| Receiver height |
1.13" (2.87 cm) |
| Receiver weight |
22.9 oz (650 g) |
| Technical details |
|---|
| Harmonized System (HS) code |
84733080 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
0 - 80% |
