Micro Case, USB 3.0, USB 2.0, 2x 2.5", 2x 3.5”, SPCC
Reasons To Buy
Thermaltake Versa H17 Micro Case
Designed for entry-level PC builders and gamers, Thermaltake Versa H17 Micro Case features the simplicity appearance with easy cable management design, AIO liquid cooling compatible, and ample ventilation options. Supporting the latest PC hardware and all high-end GPU solutions, the Versa H17 is a good choice for those who opt for stylish PC case with manageable frame size and advanced features.
Handy I/O Ports
The top-front panel is designed a USB 3.0 data transfer port along with two standard USB 2.0 ports and a HD microphone and headset jacks, to grand direct access when needed.
Superior Hardware Support
The Versa H17 supports motherboards up to Micro ATX, a tower CPU cooler with maximum height 155mm, and a dual expansion slot VGA of up to 350mm in length without front fan. The hidden drive bays can house up to two 2.5” and two 3.5” storage devices at same time.
Optimized Ventilation
Standard equipped with one 120mm rear fan along with optional three 120mm or two 140mm intake fans as well as one 120mm/140mm exhaust fans provides efficient airflow for the system.
Description
Thermaltake Versa H17 Micro CaseDesigned for entry-level PC builders and gamers, Thermaltake Versa H17 Micro Case features the simplicity appearance with easy cable management design, AIO liquid cooling compatible, and ample ventilation options. Supporting the latest PC hardware and all high-end GPU solutions, the Versa H17 is a good choice for those who opt for stylish PC case with manageable frame size and advanced features.
Elegant Front Panel DesignFeaturing aluminum brushed like front panel to mask the extrusive drive devices, not only unify the appearance, but also provide a simple yet elegant aesthetic.
Handy I/O PortsThe top-front panel is designed a USB 3.0 data transfer port along with two standard USB 2.0 ports and a HD microphone and headset jacks, to grand direct access when needed.
Easy Cable ManagementWiring tangled problem no longer exists with the cable routing gap, hiding cables behind motherboard tray to ensure smoothness for building the system as well as better airflow. Plus, the pre-mounted PSU cover allows the entire bottom area of the case to be used to reorganize unused cables.
Superior Hardware SupportThe Versa H17 supports motherboards up to Micro ATX, a tower CPU cooler with maximum height 155mm, and a dual expansion slot VGA of up to 350mm in length without front fan. The hidden drive bays can house up to two 2.5” and two 3.5” storage devices at same time.
AIO Liquid Cooling CompatibleSupporting all types of AIO liquid cooling solutions, the Versa H17 has the capability to accommodate up to one 280mm radiator at the front and one 120mm radiator at the rear.
Optimized VentilationStandard equipped with one 120mm rear fan along with optional three 120mm or two 140mm intake fans as well as one 120mm/140mm exhaust fans provides efficient airflow for the system.
Specifications
| Technical details |
|---|
| Number of 5.25" bays |
0 |
| Number of 3.5" bays |
2 |
| Number of 2.5" bays |
2 |
| Number of internal 3.5" bays |
2 |
| Supported motherboard form factors |
micro ATX, Mini-ITX |
| Supported HDD sizes |
2.5,3.5" |
| Side window |
No |
| Number of internal 5.25" bays |
0 |
| Product colour |
Black |
| Number of expansion slots |
4 |
| Maximum CPU cooler height |
6.1" (15.5 cm) |
| Maximum graphics card length |
13.8" (35 cm) |
| Maximum PSU length |
8.66" (22 cm) |
| Type |
PC |
| Form factor |
Micro Tower |
| Material |
|---|
| Material |
SPCC |
| Indication |
|---|
| Illumination |
No |
| Ergonomics |
|---|
| On/off button |
Yes |
| Design |
|---|
| Number of external 5.25" bays |
0 |
| Material |
SPCC |
| Number of 5.25" bays |
0 |
| Number of 3.5" bays |
2 |
| Number of 2.5" bays |
2 |
| Number of internal 3.5" bays |
2 |
| Supported motherboard form factors |
micro ATX, Mini-ITX |
| Side window |
No |
| Number of internal 5.25" bays |
0 |
| Illumination |
No |
| Product colour |
Black |
| Number of expansion slots |
4 |
| Maximum CPU cooler height |
6.1" (15.5 cm) |
| Maximum graphics card length |
13.8" (35 cm) |
| Maximum PSU length |
8.66" (22 cm) |
| Type |
PC |
| Form factor |
Micro Tower |
| On/off button |
Yes |
| Power supply |
|---|
| Power supply included |
No |
| Power supply location |
Bottom |
| Ports & interfaces |
|---|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
| Audio input |
Yes |
| Audio output |
Yes |
| USB 2.0 ports quantity |
2 |
| Cooling |
|---|
| Front radiator installed |
No |
| Front radiator sizes supported |
240,280 mm |
| Rear radiator installed |
No |
| Rear radiator sizes supported |
120 mm |
| Top radiator installed |
No |
| Noise level (high speed) |
16 dB |
| Number of front fans supported (max) |
3 |
| Front fans diameters supported |
120,140 mm |
| Rear fans installed |
1x 120 mm |
| Number of rear fans supported (max) |
1 |
| Rear fans diameters supported |
120 mm |
| Number of top fans supported (max) |
1 |
| Top fans diameters supported |
120,140 mm |
| Fan speed |
1000 - 1000 RPM |
| Storage |
|---|
| Supported HDD sizes |
2.5,3.5" |
| Weight & dimensions |
|---|
| Width |
8.07" (205 mm) |
| Depth |
15" (380 mm) |
| Height |
15.4" (390 mm) |
| Weight |
9.92 lbs (4.5 kg) |
