Gigabit Unmanaged Switch Series (GS108PP) 8-Port Gigabit Ethernet High-power PoE+ Unmanaged Switch with FlexPoE (123W)
Description
PLUG AND PLAYSimple setup with no software or configuration needed
SMALL SIZE, METAL CASE AND SILENT OPERATIONDurable quality, space saver, and quietness for peace of mind
POWER-OVER-ETHERNET8 PoE+ ports with 123W total power budget, and includes NETGEAR FlexPoE allowing to reduce the power budget to 83W or even 60W (w/separately purchased power supply modules)
LIFETIME LIMITED WARRANTY & NEXT BUSINESS DAY REPLACEMENTNETGEAR has your back to ensure your network is up and running
FLEXIBLE MOUNTINGMount on rack, desktop, or wall
STURDY METAL CASE, DESKTOP/RACKMOUNT FORM FACTOR WITH QUIET FANSCan be placed on desk or on mounted rack and will operate quietly with assured durability
Specifications
| Technical details |
|---|
| Product colour |
Black |
| Mean time between failures (MTBF) |
2752476 h |
| Rack mounting |
Yes |
| Management features |
|---|
| Switch type |
Unmanaged |
| Quality of Service (QoS) support |
Yes |
| Ports & interfaces |
|---|
| Basic switching RJ-45 Ethernet ports quantity |
8 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity |
8 |
| Network |
|---|
| Networking standards |
IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x |
| Full duplex |
Yes |
| 10G support |
No |
| Data transmission |
|---|
| Jumbo frames |
9216 |
| MAC address table |
4000 entries |
| Switching capacity |
16 Gbit/s |
| Jumbo frames support |
Yes |
| Certificates |
|---|
| Certification |
CE, FCC, ICES-003, VCCI, RCM, BSMI, KC, CB, CE LVD, BSMI, EAC, RCM, KC, EN 60950-1 |
| Design |
|---|
| Wall mountable |
Yes |
| Product colour |
Black |
| LED indicators |
Yes |
| Certification |
CE, FCC, ICES-003, VCCI, RCM, BSMI, KC, CB, CE LVD, BSMI, EAC, RCM, KC, EN 60950-1 |
| Rack mounting |
Yes |
| Performance |
|---|
| Mean time between failures (MTBF) |
2752476 h |
| Indication |
|---|
| LED indicators |
Yes |
| Power |
|---|
| Power source |
DC/PoE |
| Power over Ethernet (PoE) |
|---|
| Power over Ethernet (PoE) power per port |
30 W |
| Power over Ethernet plus (PoE+) ports quantity |
8 |
| Total Power over Ethernet (PoE) budget |
123 W |
| Power over Ethernet (PoE) |
Yes |
| Operational conditions |
|---|
| Storage temperature (T-T) |
-20 - 70 °C |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
0 - 90% |
| Operating altitude |
0 - 118110.2" (0 - 3000 m) |
| Weight & dimensions |
|---|
| Width |
9.29" (236 mm) |
| Depth |
4.02" (102 mm) |
| Height |
1.06" (27 mm) |
| Weight |
21.2 oz (600 g) |
