1500 VA, 1350 W, 90-150 V, 47/70 Hz, 480J, 3:1, 6 x NEMA 5-15R, 1.83m, IP20, 2U
Description
Peace of mind that comes with full equipment compatibility and reliability of a leaderProvides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency tested and approved means that you can deploy Smart-UPS with confidence that they meet or exceed the industry’s most rigorous standards.
Save time with easy and convenient remote accessibility.Network manageable via serial, USB or optional Ethernet. Includes Powerchute Network Shutdown Software for convenient monitoring and control, safe operating system shutdown, and innovative energy management capabilities.
Low operating and maintenance costs with proven reliability and intelligent battery management.Intelligent battery management, pioneered by APC, maximizes battery performance and life through intelligent, precision temperature compensated charging. Automatic self tests insure battery reliability and warn customers in advance of battery replacement. Convenient, easy to connect, hot-swappable battery modules provide battery replacement without powering down.
Avoids costly power problems by keeping your IT equipment and data protected and available.Network grade power conditioning protects from damaging surges and disruptive noise. The double conversion architecture provides tight voltage regulation, frequency regulation ,and zero transfer time to battery during power events.
Specifications
| Power |
|---|
| Output frequency |
50/60 Hz |
| Output power |
1350 W |
| Input operation voltage (min) |
90 V |
| Input operation voltage (max) |
150 V |
| Surge energy rating |
480 J |
| Emergency Power Off (EPO) |
Yes |
| Output voltage Total Harmonic Distortion (THD) |
2% |
| Crest factor |
3:1 |
| Output power capacity |
1.5 kVA |
| Input frequency |
47/70 Hz |
| Ports & interfaces |
|---|
| Cable length |
72" (1.83 m) |
| USB port |
Yes |
| Serial interface |
Yes |
| Serial interface type |
RJ-45 |
| SmartSlot |
Yes |
| AC outlets quantity |
6 AC outlet(s) |
| AC outlet types |
NEMA 5-15R |
| Power plug |
NEMA 5-15P |
| Ethernet LAN (RJ-45) ports |
1 |
| Performance |
|---|
| UPS topology |
Double-conversion (Online) |
| Waveform |
Sine |
| LED indicators |
Status |
| Noise level |
50 dB |
| Audible alarm(s) |
Yes |
| Features |
|---|
| Output frequency |
50/60 Hz |
| Web-based management |
Yes |
| UPS topology |
Double-conversion (Online) |
| Waveform |
Sine |
| Output power |
1350 W |
| Input operation voltage (min) |
90 V |
| Input operation voltage (max) |
150 V |
| Surge energy rating |
480 J |
| Emergency Power Off (EPO) |
Yes |
| Output voltage Total Harmonic Distortion (THD) |
2% |
| Noise level |
50 dB |
| Crest factor |
3:1 |
| Audible alarm(s) |
Yes |
| Output power capacity |
1.5 kVA |
| Input frequency |
47/70 Hz |
| Battery |
|---|
| Battery life (max) |
5 year(s) |
| Number of batteries supported |
1 |
| Battery technology |
Sealed Lead Acid (VRLA) |
| Battery recharge time |
3 h |
| Hot-swap battery |
Yes |
| Cold start |
Yes |
| Automatic battery test |
Yes |
| Design |
|---|
| International Protection (IP) code |
IP20 |
| Rack capacity |
2U |
| Form factor |
Rackmount/Tower |
| LED indicators |
Status |
| Product colour |
Black |
| Certification |
CSA C22.2 No.107.3-05, |
| Cable length |
72" (1.83 m) |
| Display type |
LCD |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 50 °C |
| Operating relative humidity (H-H) |
0 - 95% |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating altitude |
0 - 118110.2" (0 - 3000 m) |
| Non-operating altitude |
0 - 590551.2" (0 - 15000 m) |
| Technical details |
|---|
| Output voltage |
120 V |
| Output frequency |
50/60 Hz |
| Sustainability certificates |
ENERGY STAR |
| Management features |
|---|
| Web-based management |
Yes |
| Weight & dimensions |
|---|
| Package width |
23.4" (594 mm) |
| Package depth |
29.5" (749 mm) |
| Package height |
9.69" (246 mm) |
| Weight |
48.5 lbs (22 kg) |
| Width |
17" (432 mm) |
| Package weight |
65.3 lbs (29.6 kg) |
| Height |
3.35" (85 mm) |
| Depth |
20" (508 mm) |
| Packaging data |
|---|
| Resource CD |
Yes |
| Rack mount kit |
Yes |
| Quick installation guide |
Yes |
| Cables included |
USB cable |
| Bracket |
Yes |
| Warranty card |
Yes |
| Software CD |
Yes |
| Package width |
23.4" (594 mm) |
| Package depth |
29.5" (749 mm) |
| Package height |
9.69" (246 mm) |
| Package weight |
65.3 lbs (29.6 kg) |
| Certificates |
|---|
| Certification |
CSA C22.2 No.107.3-05, |
| Other features |
|---|
| Output voltage |
120 V |
| Packaging content |
|---|
| Resource CD |
Yes |
| Rack mount kit |
Yes |
| Quick installation guide |
Yes |
| Cables included |
USB cable |
| Bracket |
Yes |
| Warranty card |
Yes |
| Software CD |
Yes |
