StarTech.com Cisco QSFP-40G-SR4 Compatible QSFP+ Module 40GBASE-SR4 - 40GbE Multimode Fiber MMF Optic Transceiver - 40GE Gigabit Ethernet MPO 150m - 850nm - DDM Cisco Firepower, ASR1000 (QSFP40GSR4ST)
Key Features
- 100% CISCO QSFP-40G-SR4 COMPATIBLE: Works with Cisco switches like Firepower, ASR1000, ASR9000, C9300, C3850 and others
- TECHNICAL SPECS: 40GBASE-SR4 / 40 Gbps / Multi Mode (MMF) / MPO Connector / 850nm / Digital Diagnostic Monitoring (DDM) / Distances up to 150m (492ft)
- TESTED FOR OEM HOST COMPATIBILITY: Hot-swappable in Cisco routers and switches; DDM support reports the transceiver's status to most SNMP network management tools
- WORKS WITH MSA COMPLIANT SWITCHES: Also works with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link and more that accept uncoded modules
- THE IT PRO’S CHOICE: Designed and built for IT Professionals, this SFP module is backed for life (lifetime of module, not network switch), including free lifetime 24/5 multi-lingual technical assistance.
Description
40 Gbps | Multi Mode Fiber | MPO | 150 m (492 ft) | Lifetime Warranty
The QSFP40GSR4ST is a Cisco QSFP-40G-SR4 compatible fiber transceiver module that has been designed, programmed and tested to work with Cisco™ brand switches and routers. It delivers dependable 40 GbE connectivity over fiber cable, for 40GBASE-SR4 compliant networks, with a maximum distance of up to 150 m (492 ft).
Technical Specifications:
• Wavelength: 850nm
• Maximum Data Transfer Rate: 40 Gbps
• Type: Multi Mode Fiber
• Connection Type: MPO Connector
• Maximum Transfer Distance: 150 m (492 ft)
• MTBF: 1,649,326 hours
• Power Consumption: Less than 0.7 Watts
• Digital Diagnostics Monitoring (DDM): Yes
This QSFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.
The StarTech.com Advantage
Specifications
| Network |
|---|
| SFP transceiver type |
Fiber optic |
| Interface type |
QSFP+ |
| Maximum data transfer rate |
40000 Mbit/s |
| Fiber optic connector |
MPO |
| Networking standards |
IEEE 802.3ba |
| Performance |
|---|
| Country of origin |
China |
| Product colour |
Silver |
| Housing material |
Aluminum |
| Hot-swap |
Yes |
| Mean time between failures (MTBF) |
1649326 h |
| SFP transceiver type |
Fiber optic |
| Digital Diagnostics Monitoring (DDM) |
Yes |
| Interface type |
QSFP+ |
| Maximum data transfer rate |
40000 Mbit/s |
| Fiber optic connector |
MPO |
| Networking standards |
IEEE 802.3ba |
| Maximum transfer distance |
5905.5" (150 m) |
| Wavelength |
850 nm |
| Duplex system |
Full |
| Multi-mode fiber (MMF) supported |
Yes |
| SFP transceiver standard |
SR4 |
| Harmonized System (HS) code |
85369010 |
| Features |
|---|
| Country of origin |
China |
| Product colour |
Silver |
| Housing material |
Aluminum |
| Hot-swap |
Yes |
| Mean time between failures (MTBF) |
1649326 h |
| Power |
|---|
| Power consumption (typical) |
0.7 W |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 70 °C |
| Storage temperature (T-T) |
-40 - 85 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Weight & dimensions |
|---|
| Width |
0.724" (18.4 mm) |
| Depth |
2.83" (72 mm) |
| Height |
0.512" (13 mm) |
| Weight |
1.13 oz (32 g) |
| Package depth |
4.61" (117 mm) |
| Package width |
3.62" (92 mm) |
| Package height |
1.34" (34 mm) |
| Package weight |
3.35 oz (95 g) |
| Packaging data |
|---|
| Package depth |
4.61" (117 mm) |
| Package width |
3.62" (92 mm) |
| Package height |
1.34" (34 mm) |
| Package weight |
3.35 oz (95 g) |
| Technical details |
|---|
| Compliance certificates |
CE, RoHS |
| Logistics data |
|---|
| Master (outer) case width |
9.84" (250 mm) |
| Master (outer) case length |
11.8" (300 mm) |
| Master (outer) case height |
7.87" (200 mm) |
| Products per master (outer) case |
36 pc(s) |
| Harmonized System (HS) code |
85369010 |
| Quantity per pack |
1 pc(s) |
