| Ports & interfaces |
|---|
| Internal |
No |
| Interface |
WLAN |
| Host interface |
USB |
| Connectivity technology |
Wireless |
| Bandwidth |
|---|
| Maximum data transfer rate |
150 Mbit/s |
| Wireless LAN features |
|---|
| Wi-Fi band |
Single-band (2.4 GHz) |
| Network |
|---|
| Chipset |
RTL8188EUS |
| Channels quantity (USA) |
1 channels |
| Wi-Fi band |
Single-band (2.4 GHz) |
| Security algorithms |
64-bit WEP, 128-bit WEP, AES, TKIP, WPA, WPA-PSK, WPA2, WPA2-PSK, WPS |
| Networking standards |
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Modulation |
16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, DSSS, OFDM, QPSK |
| Maximum operating distance |
10800" (274.3 m) |
| Frequency range |
2.412 - 2.484 GHz |
| Maximum data transfer rate |
150 Mbit/s |
| Antenna |
|---|
| Transmit power range |
13 - 17 dBmW |
| Frequency range |
2.412 - 2.484 GHz |
| Technical details |
|---|
| Product colour |
Black |
| Transmit power range |
13 - 17 dBmW |
| Country of origin |
China |
| Quantity per pack |
1 pc(s) |
| Compliance certificates |
RoHS |
| Design |
|---|
| Product colour |
Black |
| Chipset |
RTL8188EUS |
| Certification |
FCC, CE |
| Internal |
No |
| LED indicators |
Activity, Link |
| Country of origin |
China |
| Housing material |
Plastic |
| Software |
|---|
| Windows operating systems supported |
Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 |
| Mac operating systems supported |
Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion |
| Indication |
|---|
| LED indicators |
Activity, Link |
| System requirements |
|---|
| Server operating systems supported |
Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 x64, Windows Server 2016 |
| Windows operating systems supported |
Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 |
| Mac operating systems supported |
Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Weight & dimensions |
|---|
| Width |
0.819" (20.8 mm) |
| Depth |
0.307" (7.8 mm) |
| Height |
0.591" (15 mm) |
| Weight |
0.159 oz (4.5 g) |
| Security |
|---|
| Security algorithms |
64-bit WEP, 128-bit WEP, AES, TKIP, WPA, WPA-PSK, WPA2, WPA2-PSK, WPS |
| Packaging data |
|---|
| Drivers included |
Yes |
| Quantity per pack |
1 pc(s) |
| Quick start guide |
Yes |
| Performance |
|---|
| Server operating systems supported |
Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 x64, Windows Server 2016 |
| Security algorithms |
64-bit WEP, 128-bit WEP, AES, TKIP, WPA, WPA-PSK, WPA2, WPA2-PSK, WPS |
| Windows operating systems supported |
Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 |
| Mac operating systems supported |
Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion |
| Certificates |
|---|
| Certification |
FCC, CE |
| Other features |
|---|
| Chipset |
RTL8188EUS |
| Housing material |
Plastic |
| Transmit power range |
13 - 17 dBmW |
| Quick start guide |
Yes |
| Quantity per pack |
1 pc(s) |
| Country of origin |
China |
| Packaging content |
|---|
| Drivers included |
Yes |
| Quick start guide |
Yes |
