USB 3.0 SuperSpeed Active Extension Repeater Cable (USB-A M/F), 20M (65.61 ft.)
Key Features
- Daisy-chain 2 cables for max distance up to 130 ft.
- Supports data transfer rates up to 5 Gbps
- Built-in signal booster for peak performance
- Provides up to 360mA of power to connected device
- Backward compatible with previous USB generations
Description
The U330-20M USB 3.0 SuperSpeed Active Extension Repeater Cable (M/F) increases the length of a device cable up to 65 feet with no worry of signal loss. By daisy-chaining two cables while using external power, you can extend the length between USB devices up to 130 feet (39.6 meters).
Connect the male plug to a USB port on your computer or hub and the female end to a USB device cable. A built-in bus-powered signal booster ensures peak performance. Backward compatible with previous USB generations, this cable supports data transfer rates up to 5 Gbps.
The U330-20M works with all computers, devices and cables with USB-A connectors. It provides up to 360mA of power to a connected device (a 5V, 2A external power supply is required for power applications stronger than 360mA).
Premium foil and braid shielding delivers top-of-the-line signal quality and protection from EMI/RFI interference. Nickel-plated USB connectors with gold-plated copper contacts ensure excellent conductivity. Integral strain relief ensures the cable and connectors last a long time.
Specifications
| Features |
|---|
| Connector gender |
Male/Female |
| Country of origin |
China |
| Connector 1 form factor |
Straight |
| Connector 2 form factor |
Straight |
| Plug and Play |
Yes |
| Reversible connectors |
No |
| USB version |
USB 3.2 Gen 1 (3.1 Gen 1) |
| Connector 1 |
USB A |
| Connector 2 |
USB A |
| Cable length |
787.4" (20 m) |
| Connector contacts plating |
Nickel |
| Maximum data transfer rate |
5000 Mbit/s |
| Product colour |
Black |
| Connector 1 gender |
Male |
| Connector 2 gender |
Female |
| Maximum data transfer rate |
5 Gbit/s |
| Output voltage |
5 V |
| Quantity per pack |
1 pc(s) |
| Power |
|---|
| Output voltage |
5 V |
| Weight & dimensions |
|---|
| Cable length |
787.4" (20 m) |
| Package width |
14" (355.6 mm) |
| Package depth |
17" (431.8 mm) |
| Package height |
0.5" (12.7 mm) |
| Package weight |
3 lbs (1.36 kg) |
| Packaging data |
|---|
| Package width |
14" (355.6 mm) |
| Package depth |
17" (431.8 mm) |
| Package height |
0.5" (12.7 mm) |
| Package weight |
3 lbs (1.36 kg) |
| Quantity per pack |
1 pc(s) |
| Packaging content |
|---|
| Quantity per pack |
1 pc(s) |
| Ports & interfaces |
|---|
| USB version |
USB 3.2 Gen 1 (3.1 Gen 1) |
| Connector 1 |
USB A |
| Connector 2 |
USB A |
| Connector contacts plating |
Nickel |
| Data transmission |
|---|
| Maximum data transfer rate |
5000 Mbit/s |
| Technical details |
|---|
| Product colour |
Black |
| Country of origin |
China |
| Harmonized System (HS) code |
84733080 |
| Compliance certificates |
RoHS |
| Certificates |
|---|
| Compliance certificates |
RoHS |
| Other features |
|---|
| Product colour |
Black |
| Master (outer) case GTIN (EAN/UPC) |
10037332199710 |
| Compliance certificates |
RoHS |
| Logistics data |
|---|
| Country of origin |
China |
| Master (outer) case gross weight |
25.6 lbs (11.6 kg) |
| Products per master (outer) case |
10 pc(s) |
| Master (outer) case width |
11.8" (299.7 mm) |
| Master (outer) case length |
21.1" (535.9 mm) |
| Master (outer) case height |
6.6" (167.6 mm) |
| Master (outer) case GTIN (EAN/UPC) |
10037332199710 |
| Harmonized System (HS) code |
84733080 |
