Heavy-Duty PDU Power Cord, C13 to C14 - 15A, 250V, 14 AWG, 6 ft. (1.83 m), Blue
Key Features
- Recommended for powering computers, servers and other network devices
- 6-ft. (1.83 m) length allows flexibility in placing devices in relationship to AC outlet
- PDU-style cord replaces or upgrades standard power cord provided by manufacturer
- Color-coded blue for fast, easy identification in a crowded rack or workstation
- Thick 14 AWG wire gauge manages high power levels required for larger equipment
Description
C14-to-C13 Power Cable for Network Devices That Require a Heavy-Gauge ConnectionThis IEC-320-C14 to IEC-320-C13 cable features 14 AWG wire suitable for high power connections, making it a reliable solution for large server applications that require a higher-rated, heavier-gauge cable. This C14 male to C13 female cord can be used to connect a computer, server, monitor or drive to a UPS system or PDU or replace or upgrade the standard power cord provided by the device's manufacturer. The 6-ft. (1.83 m) length allows you flexibility in placing equipment with respect to the power outlet.
Color-Coded to Avoid Misidentification That Can Cause Costly DowntimeThis computer power extension cord features a blue SJT jacket and fully molded blue ends. The color-coding allows easy, fast identification in a crowded rack or workstation and helps prevent the cable from becoming inadvertently disconnected
.Specifications
| Ports & interfaces |
|---|
| Connector 2 |
C13 coupler |
| Connector 1 |
C14 coupler |
| Cable length |
70.9" (1.8 m) |
| Features |
|---|
| Connector 1 form factor |
Straight |
| Connector 2 form factor |
Straight |
| Cable type |
SJT |
| AWG wire size |
14 |
| Certification |
UL |
| Connector 2 |
C13 coupler |
| Connector 1 |
C14 coupler |
| Cable length |
70.9" (1.8 m) |
| Connector 2 gender |
Female |
| Connector 1 gender |
Male |
| Product colour |
Blue |
| Power |
|---|
| Input voltage |
250 V |
| Input current |
15 A |
| Colour |
|---|
| Product colour |
Blue |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-20 - 60 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
10 - 85% |
| Storage relative humidity (H-H) |
10 - 85% |
| Certificates |
|---|
| Certification |
UL |
| Compliance certificates |
RoHS |
| Weight & dimensions |
|---|
| Width |
7" (177.8 mm) |
| Depth |
0.5" (12.7 mm) |
| Height |
9.9" (251.5 mm) |
| Weight |
10.2 oz (290 g) |
| Package width |
7" (177.8 mm) |
| Package depth |
0.5" (12.7 mm) |
| Package height |
9.9" (251.5 mm) |
| Package weight |
10.2 oz (290 g) |
| Packaging data |
|---|
| Package width |
7" (177.8 mm) |
| Package depth |
0.5" (12.7 mm) |
| Package height |
9.9" (251.5 mm) |
| Package weight |
10.2 oz (290 g) |
| Quantity per pack |
1 pc(s) |
| Technical details |
|---|
| Country of origin |
China |
| Applicability |
Universal |
| Master (outer) case GTIN (EAN/UPC) |
10037332199024 |
| Harmonized System (HS) code |
84733080 |
| Compliance certificates |
RoHS |
| Logistics data |
|---|
| Master (outer) case gross weight |
6.53 lbs (2.96 kg) |
| Products per master (outer) case |
10 pc(s) |
| Master (outer) case width |
13" (330.2 mm) |
| Master (outer) case length |
1" (25.4 mm) |
| Master (outer) case height |
18.9" (480.1 mm) |
| Master (outer) case GTIN (EAN/UPC) |
10037332199024 |
| Harmonized System (HS) code |
84733080 |
| Other features |
|---|
| Country of origin |
China |
