Transcend SSD230S 512 GB 2.5" Serial ATA III 3D NAND

Transcend Internal SSD, SSD230S, 512GB, 2.5", SATA III, 560/500 MB/s

Key Features

• Up to 560 MB/s read; 520 MB/s write
• 3D NAND flash memory and DDR3 DRAM cache
• Engineered with a RAID engine and LDPC (Low-Density Parity Check) coding to ensure data integrity; built-in SLC caching technology for exceptional transfer speeds
• Supports DevSleep ultra low power state, S.M.A.R.T, TRIM and NCQ commands
• Download the SSD Scope software from Transcend's official website

Description

SATA III 6Gb/s SSD230

Transcend's SSD230 SATA III 6Gb/s SSD adopts the latest 3D NAND technology that features vertical expansion of storage cells by stacking one cell on top of the other. By using only high-quality flash chips and enhanced firmware algorithms, the SSD230 is guaranteed to deliver greater performance and reliability.

3D expansion to break through limits
Unlike the existing planar NAND chips, 3D NAND flash is a type of flash memory in which the memory cells are stacked vertically in multiple layers. 3D NAND is developed to break through density limitations of the 2D planar NAND, and thus can deliver a greater level of performance and endurance.

Transfer speed, transfer performance
Transcend's SSD230 is equipped with a DDR3 DRAM cache that provides an incredible 4K random read and write performance of up to 340MB/s, making it the perfect choice as a boot disk for everyday computing tasks and programs. Taking full advantage of the SATA III 6Gb/s interface and built in with SLC caching technology, the SSD230 achieves exceptional transfer speeds of up to 560MB/s read and 520MB/s write.

Endurance. Reliability.
In addition to blazing-fast transfer speeds, the SSD230 is engineered with a RAID engine and LDPC (Low-Density Parity Check) coding, a powerful ECC algorithm, in order to keep your data secure. Built-in wear-leveling technology ensures data integrity during transmission, prolonging the lifespan of the drive.

Save power, save time
With full support of SATA Device Sleep Mode (DevSleep), the SSD230 can prolong notebook battery life by intelligently shutting down the SATA interface when it is not in use. DevSleep features an ultra-low power state to conserve battery power. With a remarkable response time of less than 20 milliseconds, you can get back to work instantaneously.

Take control with SSD Scope
To keep your Transcend SSD running fast and error-free, Transcend's advanced SSD Scope software application is available for download for use with the SSD230. Monitor your SSD's health status with S.M.A.R.T. technology, enable the TRIM command for optimum write speeds, keep your SSD's firmware up-to-date, and migrate data from your original drive to a new SSD with just a few clicks.

Ultra-slim, ultra-portable
The SSD230 features an industry-standard 2.5" form factor. Yet, it measures just 6.8mm in height and weighs in at a mere 63g, making it supremely well-suited for ultra-thin computing devices such as Ultrabooks as well as mainstream PCs.

Specifications

Hard drive
SSD capacity	512 GB
Memory type	3D NAND
Performance
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Mac operating systems supported	No
Linux operating systems supported	Kernel 2.6.31
Interface	Serial ATA III
Component for	PC/Laptop
NVMe	No
Sequential write speed (CDM)	500 MB/s
Sequential read speed (CDM)	560 MB/s
DevSlp (device sleep) support	Yes
TBW rating	280
SSD capacity	512 GB
S.M.A.R.T. support	Yes
Read speed	560 MB/s
TRIM support	Yes
Write speed	500 MB/s
ECC	Yes
Memory type	3D NAND
Random write (4KB)	85000 IOPS
Random read (4KB)	80000 IOPS
Mean time between failures (MTBF)	2000000 h
Data transfer rate	6 Gbit/s
Data transmission
Read speed	560 MB/s
Write speed	500 MB/s
Random write (4KB)	85000 IOPS
Random read (4KB)	80000 IOPS
Data transfer rate	6 Gbit/s
Endurance
Mean time between failures (MTBF)	2000000 h
Features
Interface	Serial ATA III
Component for	PC/Laptop
NVMe	No
Sequential write speed (CDM)	500 MB/s
Sequential read speed (CDM)	560 MB/s
DevSlp (device sleep) support	Yes
TBW rating	280
SSD capacity	512 GB
Windows operating systems supported	Windows 10, Windows 7, Windows 8
S.M.A.R.T. support	Yes
Read speed	560 MB/s
TRIM support	Yes
Write speed	500 MB/s
Mac operating systems supported	No
Linux operating systems supported	Kernel 2.6.31
ECC	Yes
Memory type	3D NAND
Random write (4KB)	85000 IOPS
Random read (4KB)	80000 IOPS
Mean time between failures (MTBF)	2000000 h
Data transfer rate	6 Gbit/s
Certification	CE/FCC/BSMI/KC/RCM
SSD form factor	2.5"
Harmonized System (HS) code	84717070
Power
Operating voltage	5 V
Certificates
Certification	CE/FCC/BSMI/KC/RCM
Design
Component for	PC/Laptop
Housing material	Aluminum
Product colour	Silver
Certification	CE/FCC/BSMI/KC/RCM
SSD form factor	2.5"
Weight & dimensions
Width	3.94" (100 mm)
Weight	1.87 oz (53 g)
Height	2.75" (69.8 mm)
Depth	0.268" (6.8 mm)
Package type	Box
Packaging data
Package type	Box
System requirements
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Mac operating systems supported	No
Linux operating systems supported	Kernel 2.6.31
Operational conditions
Operating temperature (T-T)	0 - 70 °C
Technical details
Interface	Serial ATA III
S.M.A.R.T. support	Yes
Operating temperature (T-T)	0 - 70 °C
Housing material	Aluminum
TRIM support	Yes
ECC	Yes
Product colour	Silver
SSD form factor	2.5"
Software
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Mac operating systems supported	No
Linux operating systems supported	Kernel 2.6.31
Other features
Housing material	Aluminum
Product colour	Silver
Logistics data
Harmonized System (HS) code	84717070
