USB-C Multiport Adapter - 4K HDMI, USB 3.x (5Gbps) Hub Port, GbE, 60W PD Charging, HDCP, White
Key Features
- Transmits video signals from sources supporting USB-C DisplayPort Alt Mode
- Delivers UHD picture quality at resolutions up to 3840 x 2160 (4K x 2K) @ 30 Hz
- Connects you to a wired Gigabit Ethernet network when Wi-Fi is weak or unavailable
- Power Delivery port provides 20V 3A (60W) power output for charging connected device
- USB-A port provides up to 5V 1.5A (7.5W) of charging power and transers data at 5 Gbps
Description
USB-C Multiport Adapter Turns Your Device’s USB-C or Thunderbolt 3 Port into a Multifunction WorkstationThis USB 3.2 adapter expands the potential of your tablet, laptop, Chromebook, MacBook, smartphone or PC’s USB-C or Thunderbolt 3 port. It’s ideal for transmitting digital audio and 4K video to a large display, adding a thumb drive or other USB peripheral, powering and quickly charging a PD Charging-compliant mobile device, and connecting to a Gigabit Ethernet network—all at the same time.
Supports USB DisplayPort Alternate Mode for Transmitting Audio/Video ContentWith a source device that also supports USB DisplayPort Alt Mode, you can extend the desktop of your computer to a second display, duplicate the same video on both displays, or change the second display to your primary.
Transmits Crystal-Clear 4K Video and Digital Audio to an HDMI DisplayTo send 7.1-channel surround sound and Ultra High Definition video to a 4K-ready HDMI television, projector or monitor, connect the HDMI port to the display using a 4K-compatible HDMI cable (sold separately, such as the P568-Series). The HDMI port supports UHD video resolutions up to 4K x 2K (3840 x 2160) at 30 Hz.
Connects a USB PeripheralThe USB-A port accepts USB peripherals, such as a flash drive, mouse, keyboard or printer. It supports fast USB 3.2 Gen 1 data transfer rates up to 5 Gbps and is backward compatible with USB 2.0 and USB 1.1 devices. The port provides up to 5V 1.5A (7.5W) of fast-charging power to mobile devices.
Note: Host must support USB OTG (On-the-Go).
Charges a Connected DeviceThe USB-C Power Delivery (PD) port provides power and charging to the PD Charging-compliant host device (such as a MacBook, Chromebook or Android smartphone) the U444-06N-H4GU-C is connected to. Connect the device’s AC wall charger to the USB-C PD port, which supports power input up to 20V 3A (60W).
Note: USB-C PD port does not support Quick Charge (QC).
Accesses a Wired Gigabit Ethernet NetworkThe RJ45 port offers access to a Gigabit Ethernet network when no Wi-Fi is available or when a wired connection offers faster speeds. Connect using a UTP cable (sold separately, such as the N201-Series), and enjoy true 10/100/1000 Mbps Ethernet speeds for fast data transfers.
Built-In USB-C Cable Connects in Either DirectionConnect the reversible USB-C plug to your source device’s USB-C or Thunderbolt 3 port. The fumble-free USB-C plug connects in either direction to ensure fast, easy connection every time.
Ready to Use Right Out of the PackageThe plug-and-play USB to multiport adapter works with all operating systems. It requires no software, drivers or external power. The compact unit fits easily into a pocket, briefcase or laptop bag for connecting on the go.
Specifications
| Performance |
|---|
| Supported graphics resolutions |
3840 x 2160 |
| Maximum resolution |
3840 x 2160 pixels |
| Design |
|---|
| Product colour |
White |
| Weight & dimensions |
|---|
| Weight |
1.76 oz (50 g) |
| Package width |
3.9" (99.1 mm) |
| Package depth |
5.5" (139.7 mm) |
| Package height |
0.949" (24.1 mm) |
| Package weight |
2.82 oz (80 g) |
| Packaging data |
|---|
| Package width |
3.9" (99.1 mm) |
| Package depth |
5.5" (139.7 mm) |
| Package height |
0.949" (24.1 mm) |
| Package weight |
2.82 oz (80 g) |
| Packaging content |
|---|
| Manual |
Yes |
| Quantity per pack |
1 pc(s) |
| Technical details |
|---|
| Master (outer) case GTIN (EAN/UPC) |
10037332193961 |
| Harmonized System (HS) code |
84733080 |
| Compliance certificates |
RoHS |
| Logistics data |
|---|
| Country of origin |
Vietnam |
| Products per master (outer) case |
10 pc(s) |
| Master (outer) case width |
4.6" (116.8 mm) |
| Master (outer) case gross weight |
28.9 oz (820 g) |
| Master (outer) case length |
11.4" (289.6 mm) |
| Master (outer) case height |
5.4" (137.2 mm) |
| Quantity per pack |
1 pc(s) |
| Master (outer) case GTIN (EAN/UPC) |
10037332193961 |
| Harmonized System (HS) code |
84733080 |
