CyberPower EC750GTAA uninterruptible power supply (UPS) Standby (Offline) 0.75 kVA 450 W 12 AC outlet(s)

TAA UPS Systems, 750VA, 450W, 526J, 12 outlets, 1.5m, standby, black

Description

A compact UPS with standby topology, the CyberPower Ecologic EC750GTAA provides battery backup (using simulated sine wave output) and surge protection for desktop computers, workstations, networking devices, and home entertainment systems. It complies with the U.S. Trade Agreement Act (TAA). During power interruptions, the EC750GTAA offers reliable power protection and battery backup. When the battery backup detects that the computer is off or in sleep mode, computer peripherals connected to the ECO Mode, surge protected outlets will be automatically turned off, reducing power usage and lowering energy costs—USB connection required. The EC750GTAA comes with a three-year warranty (including coverage of batteries) and a $100,000 Connected Equipment Guarantee.

Battery Backup
Supplies power long enough for equipment to properly shut down when utility power fails. Helps prevent loss of data and minimizes the component stress caused by a hard shutdown.

Surge Protection
Diverts excess voltage away from sensitive electronic equipment during an AC power surge or power spike to prevent damage.

Data Line Protection
Prevents power surges that travel through telephone lines from causing damage to electronics.

Standby Topology
Ensures that when incoming power drops below or surges above safe voltage levels, the UPS switches to DC battery power and then inverts to AC power to run connected equipment.

Simulated Sine Wave Output
Uses pulse wave modulation to generate a stepped, approximated sine wave to supply cost-effective battery backup power for equipment that does not require sine wave output.

GreenPower UPS Bypass Design
Is a patented design that allows utility power to bypass the UPS transformer, when AC power is stable, which reduces energy consumption, noise, and heat buildup.

ECO Mode
Is an energy-efficient, user selectable feature for some surge-protected outlets. When the computer is off or is in sleep mode, the UPS automatically cuts power to computer peripherals connected to any outlets in ECO mode.

LED Status Lights
Indicate Power On, ECO on/off.

Ultra Quiet Design
Minimizes noise during operation for a quieter work environment.

PowerPanel Personal Edition Software
Provides a user-friendly dashboard interface for controlling and monitoring the UPS. Free software download available. See the Resources tab.

ENERGY STAR
This model is an ENERGY STAR certified Uninterruptible Power Supply (UPS) system. ENERGY STAR is the trusted, government-backed symbol for energy-efficient products and practices that help save money and protect the environment.

Three-Year Warranty
CyberPower will repair or replace a defective UPS system (including batteries) within three years of the purchase date. See warranty for details.

Connected Equipment Guarantee
CyberPower will repair or replace properly connected equipment if it is damaged by a power surge.

Specifications

Power
Output frequency	50/60 Hz
Output power	450 W
Input operation voltage (min)	96 V
Input operation voltage (max)	140 V
Output operation voltage (max)	120 V
Surge energy rating	526 J
Output power capacity	0.75 kVA
Input frequency	47/63 Hz
Ports & interfaces
Cable length	59.1" (1.5 m)
USB port	Yes
AC outlets quantity	12 AC outlet(s)
AC outlet types	NEMA 5–15R
Power plug	NEMA 5-15P
Modem (RJ-11) ports	2
Performance
UPS topology	Standby (Offline)
Waveform	Sine
Response time	4 ms
LED indicators	Power, Battery replacement
EMI/RFI noise filtering	Yes
Surge protection	Yes
Surge protection features	Telephone
Power protection features	Short circuit
Features
Output frequency	50/60 Hz
UPS topology	Standby (Offline)
Waveform	Sine
Response time	4 ms
Output power	450 W
Input operation voltage (min)	96 V
Input operation voltage (max)	140 V
Output operation voltage (max)	120 V
Surge energy rating	526 J
EMI/RFI noise filtering	Yes
Surge protection	Yes
Surge protection features	Telephone
Power protection features	Short circuit
Output power capacity	0.75 kVA
Input frequency	47/63 Hz
Battery
Battery voltage	120 V
Battery technology	Sealed Lead Acid (VRLA)
Battery recharge time	8 h
Typical backup time at half load	8.8 min
Typical backup time at full load	1.7 min
Design
Form factor	Compact
LED indicators	Power, Battery replacement
Product colour	Black
Certification	UL1778, cUL 107.3, FCC DOC Class B
Cable length	59.1" (1.5 m)
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 45 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 118110.2" (0 - 3000 m)
Non-operating altitude	0 - 590551.2" (0 - 15000 m)
Technical details
Output frequency	50/60 Hz
Sustainability certificates	ENERGY STAR
Compliance certificates	RoHS
Weight & dimensions
Weight	7.72 lbs (3.5 kg)
Width	12.2" (309.9 mm)
Height	3.1" (78.7 mm)
Depth	7" (177.8 mm)
Certificates
Certification	UL1778, cUL 107.3, FCC DOC Class B
