Western Digital Ultrastar DC HC580 internal hard drive 24 TB 7200 RPM 512 MB 3.5" SAS
Description
Key Features
- New, improved OptiNAND technology enables more efficient storage footprint
- Energy-assisted magnetic recording (EAMR), triple-stage actuator (TSA), and HelioSeal for high capacity with low power
- ArmorCache improves performance and provides enterprise power loss protection
Description
24TB data center HDD with OptiNAND technologyThe relentless growth of data means organizations must find ways to efficiently store ever more data. The Ultrastar DC HC580 24TB1 HDD with improved OptiNAND technology is the next step in high-capacity hard drives, allowing data centers to maximize their storage, especially in footprint- and powerconstrained environments.
Keep up with exponential data growth
The 24TB1 Ultrastar DC HC580 HDD with OptiNAND technology’s capacity-enabling features provides more efficient storage on a 10-disk CMR drive, enabling you to store more in the same footprint
Innovative technologies for higher capacities
Improved OptiNAND technology, energy-assisted magnetic recording (EAMR), triplestage actuator (TSA), and HelioSeal enable high capacity with low power
Performance and protection
ArmorCache is a feature enabled by OptiNAND that offers higher performance in write cache disabled mode and provides enterprise power loss protection in write cache enabled mode
Designed for data center workloads
The Ultrastar DC HC580 is performance-optimized to handle heavy application workloads of up to 550TB2 per year.
Built with reliability in mind
This robust drive delivers dependability in intense data center environments with up to 2.5M hours MTBF3 (projected).
Specifications
| Software | |
|---|---|
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Hard drive | |
| Component for | Server/workstation |
| HDD sustained transfer rate | 298 MiB/s |
| HDD interface transfer rate | 12 Gbit/s |
| Workload rate limit | 550 TB/year |
| Average latency | 4.16 ms |
| Mean time between failures (MTBF) | 2500000 h |
| Hot-swap | No |
| HDD speed | 7200 RPM |
| HDD size | 3.5" |
| HDD capacity | 24 TB |
| Features | |
| Type | HDD |
| Component for | Server/workstation |
| HDD sustained transfer rate | 298 MiB/s |
| HDD interface transfer rate | 12 Gbit/s |
| Workload rate limit | 550 TB/year |
| Interface | SAS |
| Average latency | 4.16 ms |
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Mean time between failures (MTBF) | 2500000 h |
| Hot-swap | No |
| HDD speed | 7200 RPM |
| HDD size | 3.5" |
| HDD capacity | 24 TB |
| Storage drive buffer size | 512 MB |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^15 bits read |
| Power | |
| Power consumption (write) | 8.7 W |
| Power consumption (read) | 8.7 W |
| Power consumption (idle) | 5.8 W |
| Operating voltage | 5 / 12 V |
| System requirements | |
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 60 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating vibration | 0.7 G |
| Operating shock | 40 G |
| Non-operating vibration | 1.04 G |
| Non-operating shock | 200 G |
| Technical details | |
| Quantity per pack | 1 pc(s) |
| Warranty period | 5 year(s) |
| Interface | SAS |
| Mean time between failures (MTBF) | 2500000 h |
| Hot-swap | No |
| Weight & dimensions | |
| Width | 4" (101.6 mm) |
| Weight | 23.6 oz (670 g) |
| Height | 1.03" (26.1 mm) |
| Depth | 5.79" (147 mm) |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Other features | |
| Interface | SAS |
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Warranty period | 5 year(s) |
