7.68 TB, U.3 15 mm, PCIe, NVMe SSD, 6800 MB/s Read, 2000 MB/s Write, TCG Ruby, 147.3 g
Key Features
- Power loss protection, end-to-end data path protection, variable sector sizes, and more
- Sandisk NVMe 1.4 Compliant Controller and PCle® 4.0
- Sandisk BiCS5 3D TLC NAND
Description
Sandisk NVMe™ enterprise SSDs continue to be the ideal solution for cloud and server providers who need performant, high-capacity, cost-optimized, read-intensive performance for their data-intensive applications.
Unlocking the Full Potential of Enterprise SSDsWith dual-port redundancy and failover capability, end-to-end data protection and additional enterprise features, SANDISK SN655 NVMe SSDs help ensure your data is secure and available when needed. With high-capacity, low-latency performance reaching up to 1.1M IOPs, storage providers are efficiently able to increase capacity for modern applications processing large unstructured datasets and are reducing time-to-insights of big data and enabling efficient machine learning.
Features SANDISK SN655 NVMe SSDs includes the next generation Sandisk NVMe 1.4b controller with PCIe Generation 4.0 interface and Sandisk BiCS5 TLC 3D NAND to enable higher capacities and performance at scale for increasingly larger application workloads. Designed and built for the standard 2.5” SSD storage infrastructure, the SN655 includes support for U.2 and U.3 backplanes and features power loss protection and 2.5M MTBF (projected) and 1.0 DW/D with a 5 year limited warranty.
Emerging WorkloadsSANDISK SN65x NVMe SSDs are optimized for cloud and scaleout workloads, providing high QoS consistency for the emerging workloads for big data, artificial intelligence, and machine learning that are increasing in size and complexity making them the ideal solution for scaling capacity and maximizing GB/watt.
Specifications
| Hard drive |
|---|
| SSD capacity |
7.68 TB |
| Memory type |
TLC 3D NAND |
| Performance |
|---|
| Server operating systems supported |
Yes |
| Windows operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Interface |
PCI Express 4.0 |
| Component for |
Server/workstation |
| NVMe |
Yes |
| NVMe version |
1.4 |
| SSD capacity |
7.68 TB |
| Read speed |
6800 MB/s |
| Write speed |
2000 MB/s |
| Memory type |
TLC 3D NAND |
| Uncorrectable Bit Error Rate (UBER) |
< 1 per 10^15 bits read |
| Random write (4KB) |
80000 IOPS |
| Random read (4KB) |
980000 IOPS |
| Mean time between failures (MTBF) |
2500000 h |
| Write latency |
15 µs |
| Read latency |
78 µs |
| Hardware encryption |
Yes |
| Data transmission |
|---|
| Read speed |
6800 MB/s |
| Write speed |
2000 MB/s |
| Random write (4KB) |
80000 IOPS |
| Random read (4KB) |
980000 IOPS |
| Write latency |
15 µs |
| Read latency |
78 µs |
| Endurance |
|---|
| Uncorrectable Bit Error Rate (UBER) |
< 1 per 10^15 bits read |
| Mean time between failures (MTBF) |
2500000 h |
| Features |
|---|
| Interface |
PCI Express 4.0 |
| Component for |
Server/workstation |
| Server operating systems supported |
Yes |
| NVMe |
Yes |
| NVMe version |
1.4 |
| SSD capacity |
7.68 TB |
| Windows operating systems supported |
Yes |
| Read speed |
6800 MB/s |
| Write speed |
2000 MB/s |
| Linux operating systems supported |
Yes |
| Memory type |
TLC 3D NAND |
| Uncorrectable Bit Error Rate (UBER) |
< 1 per 10^15 bits read |
| Random write (4KB) |
80000 IOPS |
| Random read (4KB) |
980000 IOPS |
| Mean time between failures (MTBF) |
2500000 h |
| Write latency |
15 µs |
| Read latency |
78 µs |
| Hardware encryption |
Yes |
| SSD form factor |
U.3 |
| Power |
|---|
| Power consumption (idle) |
8 W |
| Operating voltage |
12 V |
| Design |
|---|
| Component for |
Server/workstation |
| SSD form factor |
U.3 |
| Weight & dimensions |
|---|
| Width |
2.75" (69.8 mm) |
| Weight |
5.2 oz (147.3 g) |
| Height |
0.587" (14.9 mm) |
| Depth |
3.95" (100.3 mm) |
| System requirements |
|---|
| Server operating systems supported |
Yes |
| Windows operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 70 °C |
| Storage temperature (T-T) |
-40 - 85 °C |
| Technical details |
|---|
| Interface |
PCI Express 4.0 |
| Operating temperature (T-T) |
0 - 70 °C |
| Storage temperature (T-T) |
-40 - 85 °C |
| Hardware encryption |
Yes |
| SSD form factor |
U.3 |
| Warranty period |
5 year(s) |
| Software |
|---|
| Windows operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Other features |
|---|
| Warranty period |
5 year(s) |
| Uncorrectable Bit Error Rate (UBER) |
< 1 per 10^15 bits read |
