7.68TB DC3000ME U.2 PCIe 5.0 NVMe TCG Opal Enterprise SSD
Key Features
- Data Center SSD for Enterprise
- Gen5 PCIe NVMe U.2
- 3.84TB, 7.68TB, 15.36TB
- Up to 14,0000 MB/s read
- Up to 2,800,000 read IOPS
Description
PCIe 5.0 NVMe U.2 for Server ApplicationsKingston’s DC3000ME U.2 data center SSD features a high-speed PCIe 5.0 NVMe interface and utilizes 3D eTLC NAND, making it well suited for a wide range of server applications such as AI, HPC, OLTP, databases, cloud infrastructure and edge computing. DC3000ME includes on-board power loss protection to safeguard data in the event of sudden power loss and AES 256-bit encryption for ultimate data security. DC3000ME utilizes the latest high-speed PCIe 5.0 interface and is backward-compatible with PCIe 4.0 servers and backplanes. Like all of Kingston’s data center SSDs, DC3000ME is designed to deliver I/O consistency and low latency as the key design criteria that system integrators, hyperscale data centers and cloud service providers can depend on. DC3000ME is offered in 3.84TB, 7.68TB and 15.36TB* capacities and is backed by Kingston's legendary technical support and a 5-year limited warranty.
Applications and workloadsDC3000ME is ideal for running a wide range of server applications and workloads including:
- AI
- HPC
- Cloud services
- Edge computing
- Software defined storage
- RAID
- General server use
Enterprise PCIe 5.0 performanceDelivers I/O consistency and low latency with sustained speeds of up to 14,000MB/s read and 2,800,000 read IOPS**.
Optimal storage and efficiencyHigh capacity options available offering an exceptional balance of consistent I/O delivery and ultra-high performance. Optimized to handle a wide range of server workloads efficiently.
On-board Power Loss Protection (PLP)Enterprise-class protection to reduce possibility of data loss or corruption on ungraceful power fails including NVMe-MI 1.2b out-of-band management, end-to-end data protection, TCG Opal 2.0.
AES 256-bit encryptionSecure sensitive data with AES 256-bit hardware-based encryption and TCG Opal 2.0.
Specifications
| Hard drive |
|---|
| SSD capacity |
7.68 TB |
| Memory type |
3D eTLC |
| Data transmission |
|---|
| Read speed |
14000 MB/s |
| Write speed |
10000 MB/s |
| Random write (4KB) |
500000 IOPS |
| Random read (4KB) |
2800000 IOPS |
| Write latency |
70 µs |
| Read latency |
10 µs |
| Security |
|---|
| Security algorithms |
256-bit AES, TCG Opal 2.0 |
| Endurance |
|---|
| Mean time between failures (MTBF) |
2000000 h |
| Features |
|---|
| Interface |
PCI Express 5.0 |
| Component for |
Server |
| NVMe |
Yes |
| Power loss protection |
Yes |
| SSD capacity |
7.68 TB |
| Security algorithms |
256-bit AES, TCG Opal 2.0 |
| Read speed |
14000 MB/s |
| Write speed |
10000 MB/s |
| Memory type |
3D eTLC |
| Random write (4KB) |
500000 IOPS |
| Random read (4KB) |
2800000 IOPS |
| Mean time between failures (MTBF) |
2000000 h |
| Write latency |
70 µs |
| Read latency |
10 µs |
| Hardware encryption |
Yes |
| SSD form factor |
U.2 |
| Market segment |
Server |
| Power |
|---|
| Power consumption (write) |
24 W |
| Power consumption (read) |
8.2 W |
| Power consumption (idle) |
8 W |
| Performance |
|---|
| Interface |
PCI Express 5.0 |
| Component for |
Server |
| NVMe |
Yes |
| Power loss protection |
Yes |
| SSD capacity |
7.68 TB |
| Security algorithms |
256-bit AES, TCG Opal 2.0 |
| Read speed |
14000 MB/s |
| Write speed |
10000 MB/s |
| Memory type |
3D eTLC |
| Random write (4KB) |
500000 IOPS |
| Random read (4KB) |
2800000 IOPS |
| Mean time between failures (MTBF) |
2000000 h |
| Write latency |
70 µs |
| Read latency |
10 µs |
| Hardware encryption |
Yes |
| Design |
|---|
| Component for |
Server |
| SSD form factor |
U.2 |
| Market segment |
Server |
| Weight & dimensions |
|---|
| Width |
2.75" (69.8 mm) |
| Weight |
5.34 oz (151.3 g) |
| Height |
0.583" (14.8 mm) |
| Depth |
3.96" (100.5 mm) |
| Package width |
5.1" (129.5 mm) |
| Package depth |
0.66" (16.8 mm) |
| Package height |
7.25" (184.2 mm) |
| Package weight |
6.36 oz (180.4 g) |
| Packaging data |
|---|
| Package width |
5.1" (129.5 mm) |
| Package depth |
0.66" (16.8 mm) |
| Package height |
7.25" (184.2 mm) |
| Package weight |
6.36 oz (180.4 g) |
| Master (outer) case width |
5.35" (135.9 mm) |
| Master (outer) case length |
8" (203.2 mm) |
| Master (outer) case height |
2.75" (69.8 mm) |
| Master (outer) case gross weight |
2.56 lbs (1.16 kg) |
| Products per master (outer) case |
6 pc(s) |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 70 °C |
| Non-operating vibration |
10 G |
| Technical details |
|---|
| Interface |
PCI Express 5.0 |
| Operating temperature (T-T) |
0 - 70 °C |
| Non-operating vibration |
10 G |
| Hardware encryption |
Yes |
| Country of origin |
Malaysia |
| SSD form factor |
U.2 |
| Market segment |
Server |
| Logistics data |
|---|
| Master (outer) case width |
5.35" (135.9 mm) |
| Master (outer) case length |
8" (203.2 mm) |
| Master (outer) case height |
2.75" (69.8 mm) |
| Master (outer) case gross weight |
2.56 lbs (1.16 kg) |
| Products per master (outer) case |
6 pc(s) |
| Country of origin |
Malaysia |
| Other features |
|---|
| Country of origin |
Malaysia |
