19" TouchPro PCAP 10 Touch, 1280 x 1024 px, 5:4, 1000:1, 235 cd/m², 2 x 2 W, VGA, HDMI, USB, IPX1
Description
The Elo 02-Series of Touchscreen Monitors designed with seamless style across all sizes includes four options — a 19-inch square aspect ratio display and 22, 24 and 27-inch wide aspect ratio displays. With a compact form factor and clean design for easy integration, the 02-Series monitors are well-suited for point-of-sale, point of information, signage and hospitality applications. And with a variety of peripherals, the monitors can be transformed to meet the demands of your blueprint.
Brilliant Displays from 19 to 27-inchesThe clear glass touchscreens with Elo's industry-leading TouchPro® PCAP technology offer wide viewing angles with impeccable image clarity, resolution, and light transmission for accurate touch response and vivid images. With up to 10 touches enabled, the 02-Series Monitors, provide a tablet-like experience.
Well-Suited for...Not all businesses have the same needs. Whether you need a touchscreen at the point of sale to process a transaction or in a restaurant to enable self-service for guests to view your menu and submit their order, the line of 02-Series monitors can support the installation needs with ease while maintaining a modern, sleek aesthetic.
Privacy MattersOptional privacy screens can help provide a physical safeguard for private information or sensitive data from the view of others. Whether you are the employee or the customer, privacy matters.
One for You. One for Your Customers.Offer your customers a point of interaction by adding a touchscreen for them to review their transactions, participate in loyalty programs or see the latest promotion.
Mount with FlexibilityCustomers demand a seamless shopping experience from first step into the store through check-out. From the stands that come with the monitors to pole mounts, shelf mounts, wall mounts and 3rd party VESA mounts, the touchscreens can be integrated with ease.
Specifications
| Display |
|---|
| LED backlight |
Yes |
| Display number of colours |
16.78 million colors |
| Number of simultaneous touchpoints |
10 |
| Touchscreen |
Yes |
| Display technology |
LCD |
| Display diagonal |
19" |
| Display resolution |
1280 x 1024 pixels |
| Display brightness |
235 cd/m² |
| Response time |
14 ms |
| Contrast ratio (typical) |
1000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Vertical scan range |
50 - 75 Hz |
| Native aspect ratio |
5:4 |
| Horizontal scan range |
30 - 82 kHz |
| Maximum refresh rate |
60 Hz |
| Touchscreen technology |
Projected capacitive system |
| Ports & interfaces |
|---|
| DisplayPorts quantity |
0 |
| HDMI ports quantity |
1 |
| Micro-USB ports quantity |
4 |
| Audio |
|---|
| RMS rated power |
4 W |
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Product colour |
Black |
| Panel mounting interface |
100 x 100 mm |
| VESA mounting |
Yes |
| Screen shape |
Flat |
| Performance |
|---|
| International Protection (IP) code |
IPX1 |
| Mean time between failures (MTBF) |
50000 h |
| On Screen Display (OSD) languages |
Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Russian |
| Power |
|---|
| Power consumption (off) |
0.4 W |
| Power consumption (typical) |
18 W |
| Power consumption (standby) |
0.8 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Weight & dimensions |
|---|
| Width (with stand) |
16.9" (429.6 mm) |
| Height (with stand) |
15.7" (397.7 mm) |
| Depth (with stand) |
7.61" (193.4 mm) |
| Weight (with stand) |
13.9 lbs (6.3 kg) |
| Packaging data |
|---|
| Package width |
20.7" (527 mm) |
| Package depth |
10.2" (260 mm) |
| Package height |
19" (482 mm) |
| Package weight |
21.6 lbs (9.8 kg) |
| Quick start guide |
Yes |
| Cables included |
AC, Audio (3.5mm), HDMI, USB, VGA |
| Packaging content |
|---|
| Quick start guide |
Yes |
| Cables included |
AC, Audio (3.5mm), HDMI, USB, VGA |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Storage relative humidity (H-H) |
10 - 95% |
| Technical details |
|---|
| VESA mounting |
Yes |
| Power supply type |
AC/DC |
| Dimensions (W x D x H) with stand |
16.9 x 7.61 x 15.7" (429.6 x 193.4 x 397.7 mm) |
| Number of simultaneous touchpoints |
10 |
| Weight (without stand) |
9.48 lbs (4.3 kg) |
| Display viewable area (HxV) |
14.8 x 11.8" (374.8 x 299.8 mm) |
| Weight (with stand) |
13.9 lbs (6.3 kg) |
| Logistics data |
|---|
| Harmonized System (HS) code |
85285210 |
| Features |
|---|
| Harmonized System (HS) code |
85285210 |
| Other features |
|---|
| Power supply type |
AC/DC |
| Dimensions (W x D x H) with stand |
16.9 x 7.61 x 15.7" (429.6 x 193.4 x 397.7 mm) |
| Number of simultaneous touchpoints |
10 |
| Weight (without stand) |
9.48 lbs (4.3 kg) |
| Display viewable area (HxV) |
14.8 x 11.8" (374.8 x 299.8 mm) |
| Width (with stand) |
16.9" (429.6 mm) |
| Voltage tolerance |
5% |
| Quick start guide |
Yes |
| Mean time between failures (MTBF) |
50000 h |
| Height (with stand) |
15.7" (397.7 mm) |
| Headphone outputs |
1 |
| Display technology |
LCD |
| Depth (with stand) |
7.61" (193.4 mm) |
| Built-in camera |
No |
| Aspect ratio |
5:4 |
| Weight (with stand) |
13.9 lbs (6.3 kg) |
| Maximum refresh rate |
60 Hz |
| Micro-USB ports quantity |
4 |
