Tiny (1L), Intel Core i9-13900, 2x 32 GB SO-DIMM DDR5, 1x 2TB SSD M.2, NVIDIA T1000 8GB, Wi-Fi 6E, Bluetooth, Ethernet , DisplayPort, HDMI, USB-C, USB-A, miniDP, Windows 11 Pro, English
Key Features
- Compact, efficient Tiny with all the power of a regular workstation
- Available with NVIDA professional discrete graphics
- Ideal for architecture, engineering, finance, healthcare, & STEM education
- Up to Intel® Core™ i9-14900
- Up to 64GB DDR5-4800, 2x SO-DIMM
- Up to 2x 2TB M.2 PCIe® NVMe® SSD with RAID 0/1 support
Description
ThinkStation P3 TinyDesigned for ultimate productivity, this compact 1-liter form factor powered by up to 13th Gen Intel Core i9 Processor lets users handle the most demanding workloads without compromising on efficiency. Enhance productivity with optional Wi-Fi 6E that enables faster connection speeds even in densely congested areas while with optional Thunderbolt 4 port, connect devices and share files at high speed. Security features including discrete TPM 2.0, Kensington security slot, and BIOS security keeps data well-protected.
Specifications
| Processor |
|---|
| Processor generation |
13th gen Intel® Core™ i9 |
| Processor cache type |
Smart Cache |
| Processor cache |
36 MB |
| Processor model |
i9-13900 |
| Processor manufacturer |
Intel |
| Processor boost frequency |
5.6 GHz |
| Processor threads |
32 |
| Processor cores |
24 |
| Processor family |
Intel® Core™ i9 |
| Performance cores |
8 |
| Efficient cores |
16 |
| Performance-core base frequency |
2 GHz |
| Efficient-core base frequency |
1.5 GHz |
| Processor base power |
65 W |
| Maximum turbo power |
219 W |
| Efficient-core Max Turbo Frequency |
4.2 GHz |
| Performance-core Max Turbo Frequency |
5.2 GHz |
| Memory |
|---|
| Non-ECC |
Yes |
| ECC |
No |
| Internal memory |
64 GB |
| Memory layout (slots x size) |
2 x 32 GB |
| Maximum internal memory |
96 GB |
| Memory slots |
2x SO-DIMM |
| Internal memory type |
DDR5-SDRAM |
| Memory clock speed |
5600 MHz |
| Memory channels |
Dual-channel |
| Memory data transfer rate |
5200 MT/s |
| Storage |
|---|
| Storage media |
SSD |
| Optical drive type |
No |
| SSD interface |
PCI Express 4.0 |
| SSD capacity |
2 TB |
| Number of SSDs installed |
1 |
| Total storage capacity |
2 TB |
| SSD form factor |
M.2 |
| Total SSDs capacity |
2 TB |
| NVMe |
Yes |
| M.2 SSD size |
2280 (22 x 80 mm) |
| Graphics |
|---|
| Discrete graphics card |
Yes |
| Discrete graphics card memory |
8 GB |
| Graphics card Mini DisplayPort ports quantity |
4 |
| On-board graphics card family |
Intel® UHD Graphics |
| On-board graphics card |
Yes |
| Discrete graphics card model |
NVIDIA T1000 |
| On-board graphics card model |
Intel UHD Graphics 770 |
| Number of discrete graphics cards |
1 |
| Discrete GPU manufacturer |
NVIDIA |
| On-board GPU manufacturer |
Intel |
| Optical drive |
|---|
| Optical drive type |
No |
| Network |
|---|
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Bluetooth |
Yes |
| Bluetooth version |
5.1 |
| Wi-Fi standards |
Wi-Fi 6E (802.11ax) |
| Wake-on-LAN ready |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Cabling technology |
10/100/1000Base-T(X) |
| WLAN controller model |
Intel Wi-Fi 6E AX211 |
| Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
| Antenna type |
2x2 |
| WLAN controller manufacturer |
Intel |
| LAN controller |
Intel® I219-LM |
| Ports & interfaces |
|---|
| Combo headphone/mic port |
Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| Thunderbolt 3 ports quantity |
0 |
| HDMI version |
2.1 |
| USB 2.0 ports quantity |
0 |
| HDMI ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| DisplayPorts quantity |
1 |
| DisplayPort version |
1.4 |
| Expansion slots |
|---|
| PCI Express x8 (Gen 4.x) slots |
1 |
| Technical details |
|---|
| Cable lock slot type |
Kensington |
| Product type |
Mini PC |
| Trusted Platform Module (TPM) |
Yes |
| Product colour |
Black |
| Chassis type |
Mini PC |
| Audio system |
High Definition Audio |
| Placement supported |
Horizontal/Vertical |
| Cable lock slot |
Yes |
| Motherboard chipset |
Intel Q670 |
| Sustainability certificates |
ENERGY STAR, EPEAT Gold, ErP, TCO |
| Compliance certificates |
RoHS |
| Design |
|---|
| VESA mounting |
Yes |
| Volume |
1 L |
| Cable lock slot type |
Kensington |
| Product colour |
Black |
| Chassis type |
Mini PC |
| Placement supported |
Horizontal/Vertical |
| Cable lock slot |
Yes |
| Colour name |
Black |
| Performance |
|---|
| Audio chip |
Realtek ALC256-VB |
| Number of speakers |
1 |
| Password protection |
Yes |
| Password protection type |
Power on, SSD, Supervisor |
| Product type |
Mini PC |
| Trusted Platform Module (TPM) |
Yes |
| Audio system |
High Definition Audio |
| Built-in speaker(s) |
Yes |
| Motherboard chipset |
Intel Q670 |
| Trusted Platform Module (TPM) version |
2.0 |
| Software |
|---|
| Operating system language |
English |
| Operating system architecture |
64-bit |
| Operating system installed |
Windows 11 Pro |
| Power |
|---|
| Power supply input voltage |
100 - 240 V |
| Power supply |
300 W |
| Operational conditions |
|---|
| Operating altitude |
0 - 120000" (0 - 3048 m) |
| Storage temperature (T-T) |
-40 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
10 - 90% |
| Operating temperature (T-T) |
5 - 35 °C |
| Non-operating altitude |
0 - 480000" (0 - 12192 m) |
| Certificates |
|---|
| Compliance certificates |
RoHS |
| Sustainability |
|---|
| Sustainability certificates |
ENERGY STAR, EPEAT Gold, ErP, TCO |
| Ergonomics |
|---|
| VESA mounting |
Yes |
| Weight & dimensions |
|---|
| Volume |
1 L |
| Width |
7.05" (179 mm) |
| Depth |
7.2" (182.9 mm) |
| Height |
1.46" (37 mm) |
| Weight |
3.09 lbs (1.4 kg) |
| Packaging content |
|---|
| Mouse included |
Yes |
| Display included |
No |
| Keyboard included |
Yes |
| Mouse connectivity |
Wired |
| Keyboard connectivity |
Wired |
| Other features |
|---|
| VESA mounting |
Yes |
| Number of speakers |
1 |
| Trusted Platform Module (TPM) |
Yes |
| On-board graphics card |
Yes |
| Processor manufacturer |
Intel |
| Built-in speaker(s) |
Yes |
