Intel Core Ultra 5 235 (24MB Cache), 32GB DDR5-SDRAM, 512GB SSD, Intel Graphics, LAN, WLAN, Bluetooth, Windows 11 Pro 64-bit
Key Features
- Windows 11 Pro 64-bit
- Intel Core Ultra 5 235 (24MB Cache)
- 32GB (5600MHz) DDR5-SDRAM (1 x 32) & 512GB SSD
Description
BIG POWER IN A TINY FORM
Smarter AI for Any SituationBuilt to provide power in small spaces, the ThinkCentre M90q Gen 6 Tiny PC delivers industry-leading AI-driven performance and unparalleled productivity — all in a sleek, modern design. It boasts functionality, security, manageability, expandability, and durability, tapping into limitless potential. Leverage your capabilities without compromise.
REDEFINE AI WORKFLOWS WITH BLAZING PRECISION
IT Manageability With AI-Driven PerformancePowered by Intel® Core™ Ultra processors, the ThinkCentre M90q Gen 6 Tiny PC features an integrated NPU along with Intel vPro® for security and IT manageability. Lenovo AI Now drives AI acceleration, while the AI Turbo Engine optimizes performance by allocating X Processing Unit (XPU) workloads. Plus, up to optional WiFi 7 ensures blazing-fast connectivity.
COMPACT POWER, INFINITE POTENTIAL
Customizable ProductivityEnjoy unmatched productivity with faster USB speeds, connect to up to four displays, and power through tasks with vast memory and expandable storage. With multiple ports and an optional USB-C® (Thunderbolt™ 4) port, expand possibilities further. Bundle the ThinkCentre M90q Gen 6 Tiny PC with Tiny-in-One (TIO) monitor for smarter, cost-effective upgrades.
A SUITE OF ADVANCED PROTECTIONS
No-Compromise SecurityThis secured-core PC (L3) features ThinkShield security, encompassing hardware and software solutions. Get additional safeguards with self-healing BIOS, dTPM chip, a Kensington Security Slot™, and Smart USB Protection. Choose Intel vPro® security for advanced threat protection, while securing your data and business with ThinkCentre Customization.
PEAK PERFORMANCE IN THE TOUGHEST CONDITIONS
Safe, Durable & Efficient 24/7This PC uses the US Department of Defense MIL-STD-810H for a balance of reliability and durability. With TÜV anti-dust, low surface, and shock-resistance certifications, it stands strong in tough environments, while ensuring safety through IEC Electrical Safety and Electromagnetic certifications, offering first-class manageability for any workspace.
CREDIBILITY & COLLABORATION
SustainabilityOur goal is to provide smarter technology that builds a brighter, more sustainable future for our customers, communities, and the planet. That's why we pursue industry leading labels and certifications that demonstrate our commitment to sustainability in product design. Together, we can build a smarter future for all.
Specifications may vary depending upon region / model.
Specifications
| Processor |
|---|
| Processor generation |
Intel Core Ultra (Series 2) |
| Processor cache type |
Smart Cache |
| Processor cache |
24 MB |
| Processor model |
235 |
| Number of processors installed |
1 |
| Processor manufacturer |
Intel |
| Processor boost frequency |
5 GHz |
| Processor threads |
14 |
| Processor cores |
14 |
| Processor family |
Intel Core Ultra 5 |
| Performance cores |
6 |
| Efficient cores |
8 |
| Performance-core base frequency |
3.4 GHz |
| Efficient-core base frequency |
2.9 GHz |
| Processor base power |
65 W |
| Maximum turbo power |
121 W |
| Efficient-core Max Turbo Frequency |
4.4 GHz |
| Performance-core Max Turbo Frequency |
5 GHz |
| Neural processor unit (NPU) |
|---|
| Neural processor unit (NPU) |
Intel AI Boost |
| Sparsity support |
Yes |
| Windows Studio effects support |
Yes |
| AI software frameworks supported by NPU |
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
| Total processor performance up to |
27 TOPs |
| NPU performance up to |
13 TOPs |
| GPU performance up to |
6 TOPs |
| Memory |
|---|
| Internal memory |
32 GB |
| Memory layout (slots x size) |
1 x 32 GB |
| Maximum internal memory |
64 GB |
| Memory slots |
2x SO-DIMM |
| Internal memory type |
DDR5-SDRAM |
| Memory clock speed |
5600 MHz |
| Memory channels |
Dual-channel |
| Storage |
|---|
| Storage media |
SSD |
| Number of storage drives installed |
1 |
| Optical drive type |
No |
| SSD interface |
PCI Express 4.0 |
| SSD capacity |
512 GB |
| Number of SSDs installed |
1 |
| Card reader integrated |
No |
| Total storage capacity |
512 GB |
| SSD form factor |
M.2 |
| Total SSDs capacity |
512 GB |
| NVMe |
Yes |
| M.2 SSD size |
2280 (22 x 80 mm) |
| Graphics |
|---|
| Discrete graphics card |
No |
| On-board graphics card family |
Intel Graphics |
| On-board graphics card |
Yes |
| Discrete graphics card model |
Not available |
| On-board graphics card model |
Intel Graphics |
| On-board GPU manufacturer |
Intel |
| Optical drive |
|---|
| Optical drive type |
No |
| Network |
|---|
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Bluetooth |
Yes |
| Bluetooth version |
5.3 |
| Wi-Fi standards |
Wi-Fi 6E (802.11ax) |
| Ethernet LAN data rates |
100,1000 Mbit/s |
| WLAN controller model |
Intel Wi-Fi 6E AX211 |
| Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
| Antenna type |
2x2 |
| WLAN controller manufacturer |
Intel |
| Ports & interfaces |
|---|
| Combo headphone/mic port |
Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
5 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
0 |
| Thunderbolt 3 ports quantity |
0 |
| HDMI version |
2.1 |
| USB 2.0 ports quantity |
0 |
| HDMI ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| DisplayPorts quantity |
2 |
| USB 3.2 Gen 2x2 Type-C ports quantity |
1 |
| Technical details |
|---|
| Cable lock slot type |
Kensington |
| Product type |
Mini PC |
| Trusted Platform Module (TPM) |
Yes |
| Product colour |
Black |
| Chassis type |
Mini PC |
| Audio system |
High Definition Audio |
| Placement supported |
Horizontal/Vertical |
| Cable lock slot |
Yes |
| Motherboard chipset |
Intel Q870 |
| Design |
|---|
| Volume |
1 L |
| Cable lock slot type |
Kensington |
| Product colour |
Black |
| Chassis type |
Mini PC |
| Placement supported |
Horizontal/Vertical |
| Cable lock slot |
Yes |
| Performance |
|---|
| Audio chip |
Realtek ALC233VB |
| Number of speakers |
1 |
| Password protection |
Yes |
| Password protection type |
BIOS, Power on |
| Product type |
Mini PC |
| Trusted Platform Module (TPM) |
Yes |
| Audio system |
High Definition Audio |
| Motherboard chipset |
Intel Q870 |
| Trusted Platform Module (TPM) version |
2.0 |
| Software |
|---|
| Operating system language |
English |
| Operating system architecture |
64-bit |
| Operating system installed |
Windows 11 Pro |
| Power |
|---|
| Power supply input frequency |
50/60 Hz |
| Power supply input voltage |
100 - 240 V |
| Power supply |
135 W |
| Operational conditions |
|---|
| Operating altitude |
0 - 120000" (0 - 3048 m) |
| Storage temperature (T-T) |
-40 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
10 - 90% |
| Operating temperature (T-T) |
5 - 35 °C |
| Non-operating altitude |
0 - 480000" (0 - 12192 m) |
| Certificates |
|---|
| Certification |
ENERGY STAR,TCO,RoHS |
| Weight & dimensions |
|---|
| Volume |
1 L |
| Width |
7.05" (179 mm) |
| Depth |
7.2" (182.9 mm) |
| Height |
1.44" (36.5 mm) |
| Weight |
2.95 lbs (1.34 kg) |
| Packaging content |
|---|
| Mouse included |
Yes |
| Display included |
No |
| Keyboard included |
Yes |
| Mouse connectivity |
Wired |
| Keyboard connectivity |
Wired |
| Display |
|---|
| Display included |
No |
| Other features |
|---|
| Number of speakers |
1 |
| Trusted Platform Module (TPM) |
Yes |
| On-board graphics card |
Yes |
| Processor manufacturer |
Intel |
