14.5" 3K IPS, 430 nits, Intel Core Ultra 7 165H, Intel AI Boost, 96 GB SO-DIMM DDR5-5600, 2 TB SSD M.2 2280 PCIe, NVIDIA RTX 500 Ada Generation 4GB GDDR6, 5.0MP, Wi-Fi 6E, Bluetooth, RJ-45, HDMI, USB-C, USB-A, Windows 11 Pro, English
Key Features
- Up to Intel® Core™ Ultra 9 185H
- Up to Windows® 11 Pro
- Up to NVIDIA® RTX 500 Ada Generation 4GB GDDR6
- Brand new 14.5" display, up to 3K 430nits, 100% DCI-P3
- Standard support for TÜV Low Blue Light, Eyesafe® Certified 2.0
Description
ThinkPad P14s Gen 5 IntelThis notebook combines advanced technology with unparalleled durability, setting the standard for high-performance computing. Equipped with up to Intel® H Series Core™ Ultra 9 Processor and optional NVIDIA® RTX 500 GPU, it allows creative professionals to bring their visions to life with unparalleled speed and precision. Whether rendering complex 3D models, editing highresolution videos, or designing immersive digital experiences, it delivers uncompromising performance to enhance the creative output. With support for up to 96GB DDR5 memory, users can tackle multiple tasks simultaneously without any
slowdown.
Specifications
| Design |
|---|
| Colour name |
Black |
| Product type |
Laptop |
| Housing material |
Aluminum |
| Form factor |
Clamshell |
| Product colour |
Black |
| Display |
|---|
| HD type |
3K |
| Panel type |
IPS |
| Display brightness |
430 cd/m² |
| Touchscreen |
No |
| Display resolution |
3072 x 1920 pixels |
| Display diagonal |
14.5" |
| Anti-glare screen |
Yes |
| Maximum refresh rate |
120 Hz |
| RGB colour space |
DCI-P3 |
| Colour gamut |
100% |
| Native aspect ratio |
16:10 |
| Low Blue Light technology |
Yes |
| Processor |
|---|
| Processor generation |
Intel® Core™ Ultra (Series 1) |
| Processor cache type |
Smart Cache |
| Processor cache |
24 MB |
| Processor model |
165H |
| Processor boost frequency |
5 GHz |
| Processor cores |
16 |
| Processor threads |
22 |
| Motherboard chipset |
Intel SoC |
| Processor manufacturer |
Intel |
| Processor family |
Intel Core Ultra 7 |
| Processor base power |
28 W |
| Maximum turbo power |
115 W |
| Efficient-core base frequency |
0.9 GHz |
| Performance-core base frequency |
1.4 GHz |
| Efficient-core Max Turbo Frequency |
3.8 GHz |
| Performance-core Max Turbo Frequency |
5 GHz |
| Performance cores |
6 |
| Efficient cores |
8 |
| Low Power Efficient-core Base Frequency |
700 MHz |
| Low Power Efficient-core Max Turbo Frequency |
2.5 GHz |
| Low Power Efficient-cores |
2 |
| Neural processor unit (NPU) |
|---|
| Neural processor unit (NPU) |
Intel AI Boost |
| Sparsity support |
Yes |
| Windows Studio effects support |
Yes |
| AI software frameworks supported by NPU |
DirectML, ONNX RT, OpenVINO, Windows ML |
| Memory |
|---|
| ECC |
No |
| Memory form factor |
SO-DIMM |
| Internal memory |
96 GB |
| Memory layout (slots x size) |
2 x 48 GB |
| Internal memory type |
DDR5-SDRAM |
| Memory clock speed |
5600 MHz |
| Memory slots |
2x SO-DIMM |
| Maximum internal memory |
96 GB |
| Memory channels |
Dual-channel |
| Non-ECC |
Yes |
| Storage |
|---|
| SSD form factor |
M.2 |
| Storage media |
SSD |
| Optical drive type |
No |
| Number of SSDs installed |
1 |
| SSD capacity |
2 TB |
| SSD interface |
PCI Express 4.0 |
| Card reader integrated |
No |
| Total storage capacity |
2 TB |
| Total SSDs capacity |
2 TB |
| NVMe |
Yes |
| M.2 SSD size |
2280 (22 x 80 mm) |
| Graphics |
|---|
| Discrete graphics card |
Yes |
| Discrete graphics card memory |
4 GB |
| On-board graphics card family |
Intel Arc Graphics |
| On-board graphics card |
Yes |
| On-board graphics card model |
Intel Arc Graphics |
| Discrete graphics card model |
NVIDIA RTX 500 Ada |
| Discrete graphics memory type |
GDDR6 |
| Discrete GPU manufacturer |
NVIDIA |
| On-board GPU manufacturer |
Intel |
| Audio |
|---|
| Audio chip |
Realtek ALC3287 |
| Number of microphones |
2 |
| Audio system |
High Definition Audio |
| Number of built-in speakers |
2 |
| Speaker power |
2 W |
| Built-in microphone |
Yes |
| Camera |
|---|
| Front camera |
Yes |
| Front camera resolution (numeric) |
5 MP |
| Privacy camera |
Yes |
| Privacy type |
Privacy shutter |
| Infrared (IR) camera |
Yes |
| Windows Hello |
Yes |
| Optical drive |
|---|
| Optical drive type |
No |
| Network |
|---|
| Mobile network connection |
No |
| Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
| WLAN controller model |
Intel Wi-Fi 6E AX211 |
| Near Field Communication (NFC) |
No |
| Wi-Fi standards |
Wi-Fi 6E (802.11ax) |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
100,1000 Mbit/s |
| Bluetooth |
Yes |
| Bluetooth version |
5.3 |
| WWAN |
Not installed |
| Antenna type |
2x2 |
| WLAN controller manufacturer |
Intel |
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| USB Sleep-and-Charge |
Yes |
| USB 2.0 ports quantity |
0 |
| HDMI ports quantity |
1 |
| HDMI version |
2.1 |
| Ethernet LAN (RJ-45) ports |
1 |
| Combo headphone/mic port |
Yes |
| USB4 Gen 2x2 ports quantity |
2 |
| Intel® Thunderbolt 4 |
Yes |
| Performance |
|---|
| Motherboard chipset |
Intel SoC |
| Keyboard |
|---|
| Pointing device |
ThinkPad UltraNav |
| Numeric keypad |
No |
| Spill-resistant keyboard |
Yes |
| Keyboard backlit |
Yes |
| Keyboard language |
English |
| Software |
|---|
| Operating system language |
English |
| Operating system architecture |
64-bit |
| Operating system installed |
Windows 11 Pro |
| Technical details |
|---|
| Housing material |
Aluminum |
| Form factor |
Clamshell |
| Product colour |
Black |
| Discrete graphics card memory |
4 GB |
| Sustainability certificates |
ENERGY STAR, EPEAT Gold, TCO |
| Compliance certificates |
RoHS |
| Battery |
|---|
| Battery technology |
Lithium Polymer (LiPo) |
| Battery capacity |
75 Wh |
| Power |
|---|
| AC adapter power |
135 W |
| AC adapter frequency |
50/60 Hz |
| AC adapter input voltage |
100 - 240 V |
| USB Type-C charging port |
Yes |
| Security |
|---|
| Password protection |
Yes |
| Cable lock slot type |
Kensington |
| Trusted Platform Module (TPM) |
Yes |
| Password protection type |
BIOS, SSD, Supervisor, User |
| Fingerprint reader |
Yes |
| Cable lock slot |
Yes |
| Windows Hello |
Yes |
| Smart card reader |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
5 - 35 °C |
| Storage temperature (T-T) |
5 - 43 °C |
| Operating relative humidity (H-H) |
8 - 95% |
| Storage relative humidity (H-H) |
5 - 95% |
| Certificates |
|---|
| Compliance certificates |
RoHS |
| Sustainability |
|---|
| Sustainability certificates |
ENERGY STAR, EPEAT Gold, TCO |
| Weight & dimensions |
|---|
| Width |
12.8" (325.5 mm) |
| Depth |
8.96" (227.6 mm) |
| Height |
0.728" (18.5 mm) |
| Weight |
3.55 lbs (1.61 kg) |
| Packaging data |
|---|
| AC adapter included |
Yes |
| Packaging content |
|---|
| AC adapter included |
Yes |
| Other features |
|---|
| WLAN controller model |
Intel Wi-Fi 6E AX211 |
| On-board graphics card |
Yes |
| Audio system |
High Definition Audio |
| AC adapter included |
Yes |
| Anti-glare screen |
Yes |
