Lenovo ThinkPad P1 Gen 7 Intel Core Ultra 7 165H Mobile workstation 16" WQUXGA 64 GB LPDDR5x-SDRAM 2 TB SSD Wi-Fi 7 (802.11be) Windows 11 Pro English Black

Intel Core Ultra 7 165H (24MB Cache), 64GB LPDDR5x-SDRAM, 2000GB SSD, 40.6 cm (16") WQUXGA 3840 x 2400 OLED, Intel Arc Graphics, WLAN, Webcam, Windows 11 Pro

Key Features

• Windows 11 Pro
• Intel Core Ultra 7 165H (24MB Cache)
• 40.6 cm (16") WQUXGA 3840 x 2400 OLED
• 64GB (7500MHz) LPDDR5x-SDRAM & 2000GB SSD

Description

Looks Good — Performs Even Better

Elevate your work-anywhere experience with the 16″ ThinkPad P1 Gen 7 — a revolution in mobile workstations with its premium power and sleek, visually stunning design. Perfectly balancing form and function, this system redefines portable performance and ensures readiness to excel in remote work scenarios.

Follow Your Pursuits Anywhere

When you’re on the go, you need a battery powerful enough to support time in the field without electrical outlets. The P1 Gen 7 boasts a massive battery that’s also replaceable, should you ever need to upgrade. Plus, it supports rapid-charging technology, so when you need a charge, simply plug in for 60 minutes and get 80% capacity.

When Every Pixel Counts

When premium displays really matter, the P1 Gen 7 laptop has you covered. All of your choices include wide-angle views, low blue light to prevent eye strain, and X-Rite factory color calibration to ensure color accuracy when you’re creating. You can also choose a touchscreen model with millions of pixels for premium visuals.

Optimal Software Performance

Software and apps run flawlessly on the P1 Gen 7 workstation, which boasts a long list of independent software vendor (ISV)* certifications. Whether you work in Adobe®, AutoCAD®, Maya® or something else, you can trust that we’ve eliminated compatibility issues and potential crashes, so you’ll enjoy great project-output quality without hiccups. *See the complete list of ISV certifications

Smooth & Efficient

Go ahead — push your device to perform. The ThinkPad P1 Gen 7 mobile workstation offers advanced thermals, including liquid metal cooling on select models, and an innovative Flex Cooling System, a fan-based cooling mechanism. Plus a dual-outlet exhaust system optimizes airflow and keeps your system running efficiently.

Huge Memory Reserve & Performance Capacity

Compile code faster and streamline app development on the ThinkPad P1 Gen 7 workstation. An industry first, this laptop features customer-replaceable LPCAMM2 memory to align with your evolving needs. It boasts lower latency, better bandwidth, and faster speeds to run multiple applications simultaneously, reducing load times for heavy-duty programs.

Steadfast Security

Biometrics provide extra protection on the P1 Gen 7 workstation, from the fingerprint reader to facial recognition software. ThinkShield, our comprehensive suite of security solutions, boasts discrete Trusted Platform Module (dTPM) to encrypt critical data. Plus Intel® Threat Detection Technology helps prevent ransomware, cryptojacking, and more.

Specifications

Design
Product type	Mobile workstation
Housing material	Aluminum
Form factor	Clamshell
Product colour	Black
Display
HD type	WQUXGA
Panel type	OLED
LED backlight	Yes
Display brightness	400 cd/m²
Contrast ratio (typical)	100000:1
Touchscreen	No
Display resolution	3840 x 2400 pixels
Display diagonal	16"
Maximum refresh rate	60 Hz
RGB colour space	DCI-P3
High Dynamic Range (HDR) technology	DisplayHDR 400, Dolby Vision
Colour gamut	100%
Native aspect ratio	16:10
High Dynamic Range (HDR) supported	Yes
Anti-reflective coating	Yes
Anti-smudge coating	Yes
Processor
Processor generation	Intel® Core™ Ultra (Series 1)
Processor cache type	Smart Cache
Processor cache	24 MB
Processor model	165H
Processor boost frequency	5 GHz
Processor cores	16
Processor threads	22
Processor manufacturer	Intel
Processor family	Intel Core Ultra 7
Processor base power	28 W
Maximum turbo power	115 W
Efficient-core base frequency	0.9 GHz
Performance-core base frequency	1.4 GHz
Efficient-core Max Turbo Frequency	3.8 GHz
Performance-core Max Turbo Frequency	5 GHz
Performance cores	6
Efficient cores	8
Low Power Efficient-core Base Frequency	700 MHz
Low Power Efficient-core Max Turbo Frequency	2.5 GHz
Low Power Efficient-cores	2
Neural processor unit (NPU)
Neural processor unit (NPU)	Intel AI Boost
Sparsity support	Yes
Windows Studio effects support	Yes
AI software frameworks supported by NPU	DirectML, ONNX RT, OpenVINO, Windows ML
Memory
Memory form factor	CAMM module
Internal memory	64 GB
Internal memory type	LPDDR5x-SDRAM
Memory clock speed	7500 MHz
Maximum internal memory	64 GB
Memory channels	Dual-channel
Storage
SSD form factor	M.2
Storage media	SSD
Optical drive type	No
Number of SSDs installed	1
SSD capacity	2 TB
SSD interface	PCI Express 4.0
Card reader integrated	Yes
Compatible memory cards	SD
Total storage capacity	2 TB
Total SSDs capacity	2 TB
NVMe	Yes
Graphics
Discrete graphics card	No
On-board graphics card family	Intel Arc Graphics
On-board graphics card	Yes
On-board graphics card model	Intel Arc Graphics
Discrete graphics card model	Not available
On-board GPU manufacturer	Intel
Audio
Audio chip	Realtek ALC3306
Number of microphones	2
Audio system	Dolby Atmos
Number of built-in speakers	2
Speaker power	2 W
Built-in microphone	Yes
Camera
Front camera	Yes
Front camera resolution (numeric)	5 MP
Privacy camera	Yes
Privacy type	Privacy shutter
Infrared (IR) camera	Yes
Windows Hello	Yes
Optical drive
Optical drive type	No
Network
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
WLAN controller model	Intel Wi-Fi 7 BE200
Near Field Communication (NFC)	No
Wi-Fi standards	Wi-Fi 7 (802.11be)
Ethernet LAN	No
Bluetooth	Yes
Bluetooth version	5.4
WWAN	Not installed
Antenna type	2x2
WLAN controller manufacturer	Intel
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
USB Type-C DisplayPort Alternate Mode	Yes
USB Sleep-and-Charge ports	1
USB Sleep-and-Charge	Yes
USB 2.0 ports quantity	0
HDMI ports quantity	1
HDMI version	2.1
Combo headphone/mic port	Yes
USB Power Delivery (USB PD)	Yes
Thunderbolt 4 ports quantity	2
Intel® Thunderbolt 4	Yes
Keyboard
Pointing device	ThinkPad UltraNav
Numeric keypad	No
Spill-resistant keyboard	Yes
Keyboard backlit	Yes
Keyboard language	English
Software
Operating system language	English, Portuguese
Bundled software	Intel Connectivity Performance Suite
Operating system installed	Windows 11 Pro
Technical details
Housing material	Aluminum
Form factor	Clamshell
Product colour	Black
Sustainability certificates	ENERGY STAR, EPEAT Gold, TCO
Compliance certificates	RoHS
Battery
Battery technology	Lithium Polymer (LiPo)
Battery capacity	90 Wh
Fast charging	Yes
Power
AC adapter power	135 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
USB Power Delivery (USB PD)	Yes
USB Type-C charging port	Yes
Security
Password protection	Yes
Cable lock slot type	Kensington
Trusted Platform Module (TPM)	Yes
Password protection type	Power on, SSD, Supervisor
Fingerprint reader	Yes
Cable lock slot	Yes
Windows Hello	Yes
Smart card reader	No
Trusted Platform Module (TPM) version	2.0
Operational conditions
Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	5 - 43 °C
Operating relative humidity (H-H)	8 - 95%
Storage relative humidity (H-H)	5 - 95%
Maximum shipping altitude	120000" (3048 m)
Certificates
Certification	MIL-STD-810H military test passed
Compliance certificates	RoHS
Sustainability
Sustainability certificates	ENERGY STAR, EPEAT Gold, TCO
Weight & dimensions
Width	14" (354.4 mm)
Depth	9.5" (241.2 mm)
Height	0.671" (17.1 mm)
Weight	4.01 lbs (1.82 kg)
Packaging data
AC adapter included	Yes
Packaging content
AC adapter included	Yes
Other features
WLAN controller model	Intel Wi-Fi 7 BE200
On-board graphics card	Yes
Audio system	Dolby Atmos
Maximum shipping altitude	120000" (3048 m)
AC adapter included	Yes
