Intel Core Ultra 9 185H (24MB Cache), 96GB DDR5-SDRAM, 2000GB SSD, 40.6 cm (16") WQUXGA 3840 x 2400 IPS, Intel Arc Graphics, NVIDIA RTX 3000 Ada (8GB GDDR6), LAN, WLAN, Webcam, Windows 11 Pro 64-bit
Key Features
- Windows 11 Pro 64-bit
- Intel Core Ultra 9 185H (24MB Cache)
- 40.6 cm (16") WQUXGA 3840 x 2400 IPS, NVIDIA RTX 3000 Ada (8GB GDDR6)
- 96GB (5600MHz) DDR5-SDRAM (2 x 48) & 2000GB SSD
Description
Versatile Workstation for Smart WorkDesigned for innovators and professionals, the 16″ ThinkPad P16v Gen 2 mobile workstation packs the power of Intel® Core Ultra™ processors with Intel vPro® and AI-ready integrated Neuro Processing Unit (NPU) for anything you want to do. Even better — it boasts OS alternatives, embracing performance, versatility, mobility, and affordability.
Execute Workloads Like a BossNow, multitask and execute complex workflows in AI effortlessly with up to NVIDIA® RTX™ 3000 Ada laptop GPUs. Produce high-quality images and animations, and create high-end 3D visualizations, thanks to vast memory and storage options. Also, this mobile workstation runs software optimally as it is Independent Software Vendor (ISV)* certified.*See the complete list of ISV certifications
Embark on a Stunning Visual JourneyWith entry-level to premium display options, narrow bezels for an unobstructed gaze, and a range of brightness and colour gamut options, this 16″ ThinkPad mobile workstation is a visual powerhouse. Choose a 5MP + infrared webcam to enjoy stunning clarity during video calls with HDR400 and Dolby Vision® and elevate online meetings.*Dolby Vision® on select panels only
User Experience Functionality ReimaginedWith a spill-resistant, full-sized backlit keyboard containing a numeric pad, LED on some keys, and a large TrackPad (115mm / 4.53″), the 16″ ThinkPad P16v Gen 2 workstation is engineered for accessibility, functionality, and usability. Add a Thunderbolt™ 4 Docking station to expand your useable visual real estate with one or two external displays.
Your Connectivity PlaygroundAccess designs and move large files at lightning-fast data transfer speed (up to 40Gbps) of Thunderbolt™ 4. Delve into seamless online interactions on WiFi, Ethernet, or 4G/5G. Instantly transfer photos from your phone to the device with Magic Move, and sync data to your workstation with just a tap or swipe via Near Field Communication (NFC)*.*NFC is optional
Fearless in Security, Durability, & FormProtected by ThinkShield, the ThinkPad P16v Gen 2 mobile workstation includes a fingerprint reader for easy log in and self-healing BIOS to restore earlier system settings. It is MIL-SPEC tested for ultimate durability, energy efficient with several certifications including EPEAT® Gold, and comprises recycled components and plastic-free packaging.
Specifications
| Design |
|---|
| Colour name |
Black |
| Product type |
Mobile workstation |
| Housing material |
Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC) |
| Form factor |
Clamshell |
| Product colour |
Black |
| Display |
|---|
| HD type |
WQUXGA |
| Panel type |
IPS |
| LED backlight |
Yes |
| Display brightness |
800 cd/m² |
| Contrast ratio (typical) |
1500:1 |
| Touchscreen |
No |
| Display resolution |
3840 x 2400 pixels |
| Display diagonal |
16" |
| Anti-glare screen |
Yes |
| Maximum refresh rate |
60 Hz |
| RGB colour space |
DCI-P3 |
| High Dynamic Range (HDR) technology |
DisplayHDR 400, Dolby Vision |
| Colour gamut |
100% |
| Native aspect ratio |
16:10 |
| High Dynamic Range (HDR) supported |
Yes |
| Processor |
|---|
| Processor generation |
Intel® Core™ Ultra (Series 1) |
| Processor cache type |
Smart Cache |
| Processor cache |
24 MB |
| Processor model |
185H |
| Processor boost frequency |
5.1 GHz |
| Processor cores |
16 |
| Processor threads |
22 |
| Motherboard chipset |
Intel SoC |
| Processor manufacturer |
Intel |
| Processor family |
Intel Core Ultra 9 |
| Processor base power |
45 W |
| Maximum turbo power |
115 W |
| Efficient-core base frequency |
1.8 GHz |
| Performance-core base frequency |
2.3 GHz |
| Efficient-core Max Turbo Frequency |
3.8 GHz |
| Performance-core Max Turbo Frequency |
5.1 GHz |
| Performance cores |
6 |
| Efficient cores |
8 |
| Low Power Efficient-core Base Frequency |
1000 MHz |
| Low Power Efficient-core Max Turbo Frequency |
2.5 GHz |
| Low Power Efficient-cores |
2 |
| Neural processor unit (NPU) |
|---|
| Neural processor unit (NPU) |
Intel AI Boost |
| Sparsity support |
Yes |
| Windows Studio effects support |
Yes |
| AI datatype support on NPU |
FP16, FP32, Int8 |
| AI software frameworks supported by NPU |
DirectML, ONNX RT, OpenVINO, Windows ML |
| Memory |
|---|
| Memory form factor |
SO-DIMM |
| Internal memory |
96 GB |
| Memory layout (slots x size) |
2 x 48 GB |
| Internal memory type |
DDR5-SDRAM |
| Memory clock speed |
5600 MHz |
| Memory slots |
2x SO-DIMM |
| Maximum internal memory |
96 GB |
| Memory channels |
Dual-channel |
| Non-ECC |
Yes |
| Storage |
|---|
| SSD form factor |
M.2 |
| Storage media |
SSD |
| Optical drive type |
No |
| Number of SSDs installed |
1 |
| SSD capacity |
2 TB |
| SSD interface |
PCI Express 4.0 |
| Card reader integrated |
Yes |
| Compatible memory cards |
SD |
| Total storage capacity |
2 TB |
| Total SSDs capacity |
2 TB |
| NVMe |
Yes |
| M.2 SSD size |
2280 (22 x 80 mm) |
| Graphics |
|---|
| Discrete graphics card |
Yes |
| Discrete graphics card memory |
8 GB |
| On-board graphics card family |
Intel Arc Graphics |
| On-board graphics card |
Yes |
| On-board graphics card model |
Intel Arc Graphics |
| Discrete graphics card model |
NVIDIA RTX 3000 Ada |
| Discrete graphics memory type |
GDDR6 |
| Discrete GPU manufacturer |
NVIDIA |
| On-board GPU manufacturer |
Intel |
| Audio |
|---|
| Audio chip |
Realtek ALC3287 |
| Number of microphones |
2 |
| Audio system |
Dolby Audio Premium |
| Number of built-in speakers |
2 |
| Speaker power |
2 W |
| Built-in microphone |
Yes |
| Camera |
|---|
| Front camera |
Yes |
| Front camera resolution (numeric) |
5 MP |
| Privacy camera |
Yes |
| Privacy type |
Privacy shutter |
| Infrared (IR) camera |
Yes |
| Windows Hello |
Yes |
| Optical drive |
|---|
| Optical drive type |
No |
| Network |
|---|
| Mobile network connection |
No |
| Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
| WLAN controller model |
Intel Wi-Fi 6E AX211 |
| Near Field Communication (NFC) |
No |
| Wi-Fi standards |
Wi-Fi 6E (802.11ax) |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
100,1000 Mbit/s |
| Bluetooth |
Yes |
| Bluetooth version |
5.3 |
| WWAN |
Upgradable |
| Antenna type |
2x2 |
| WLAN controller manufacturer |
Intel |
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| USB Sleep-and-Charge ports |
1 |
| USB Sleep-and-Charge |
Yes |
| USB 2.0 ports quantity |
0 |
| HDMI ports quantity |
1 |
| HDMI version |
2.1 |
| Ethernet LAN (RJ-45) ports |
1 |
| Combo headphone/mic port |
Yes |
| USB Power Delivery (USB PD) |
Yes |
| Thunderbolt 4 ports quantity |
2 |
| Intel® Thunderbolt 4 |
Yes |
| Performance |
|---|
| Motherboard chipset |
Intel SoC |
| Keyboard |
|---|
| Pointing device |
ThinkPad UltraNav |
| Numeric keypad |
Yes |
| Spill-resistant keyboard |
Yes |
| Keyboard backlit |
Yes |
| Keyboard language |
German |
| Software |
|---|
| Operating system language |
German |
| Operating system architecture |
64-bit |
| Bundled software |
Intel Connectivity Performance Suite |
| Operating system installed |
Windows 11 Pro |
| Technical details |
|---|
| Housing material |
Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC) |
| Form factor |
Clamshell |
| Product colour |
Black |
| Discrete graphics card memory |
8 GB |
| Sustainability compliance |
Yes |
| Sustainability certificates |
ENERGY STAR, EPEAT Gold, TCO |
| PSTI certified |
Yes |
| Compliance certificates |
RoHS |
| Battery |
|---|
| Battery technology |
Lithium Polymer (LiPo) |
| Battery capacity |
90 Wh |
| Fast charging |
Yes |
| Power |
|---|
| AC adapter power |
170 W |
| AC adapter frequency |
50/60 Hz |
| AC adapter input voltage |
100 - 240 V |
| USB Power Delivery (USB PD) |
Yes |
| USB Type-C charging port |
Yes |
| Security |
|---|
| Password protection |
Yes |
| Cable lock slot type |
Kensington |
| Trusted Platform Module (TPM) |
Yes |
| Password protection type |
BIOS, Power on, SSD, Supervisor |
| Fingerprint reader |
Yes |
| Cable lock slot |
Yes |
| Windows Hello |
Yes |
| Smart card reader |
No |
| Trusted Platform Module (TPM) version |
2.0 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
5 - 35 °C |
| Storage temperature (T-T) |
5 - 43 °C |
| Operating relative humidity (H-H) |
8 - 95% |
| Storage relative humidity (H-H) |
5 - 95% |
| Maximum shipping altitude |
120000" (3048 m) |
| Certificates |
|---|
| Certification |
MIL-STD-810H |
| PSTI certified |
Yes |
| Compliance certificates |
RoHS |
| Sustainability |
|---|
| Sustainability compliance |
Yes |
| Sustainability certificates |
ENERGY STAR, EPEAT Gold, TCO |
| Weight & dimensions |
|---|
| Width |
14.4" (365 mm) |
| Depth |
10.3" (262 mm) |
| Height |
0.971" (24.7 mm) |
| Weight |
4.89 lbs (2.22 kg) |
| Packaging data |
|---|
| AC adapter included |
Yes |
| Packaging content |
|---|
| AC adapter included |
Yes |
| Other features |
|---|
| WLAN controller model |
Intel Wi-Fi 6E AX211 |
| On-board graphics card |
Yes |
| Audio system |
Dolby Audio Premium |
| Maximum shipping altitude |
120000" (3048 m) |
| AC adapter included |
Yes |
| Anti-glare screen |
Yes |
