Lenovo ThinkCentre 12V80006FR Intel® Core™ i5 i5-14500 32 GB DDR5-SDRAM 512 GB SSD Windows 11 Pro SFF PC Black

Intel Core i5-14500 (24MB Cache), 32GB DDR5-SDRAM, 512GB SSD, DVD±RW, Intel UHD Graphics 770, LAN, WLAN, Bluetooth, Windows 11 Pro

Key Features

• Windows 11 Pro
• Intel Core i5-14500 (24MB Cache)
• 32GB (4400MHz) DDR5-SDRAM (2 x 16) & 512GB SSD

Description

Peak Processing Performance

No program is too intricate, and no file is too massive to hinder the Lenovo ThinkCentre M90s Gen 5 (Intel) small form factor (SFF) from operating at the speed of human imagination. With cutting-edge Intel vPro® Enterprise technology and Intel® Core™ processors, this desktop delivers real-world, top-notch performance for business needs.

Confidently Secured

Lenovo ThinkShield offers thorough security, combining hardware and software to protect your data. The discrete Trusted Platform Module (dTPM) chip encrypts passwords and data, while BIOS-based Smart USB Protection prevents unauthorized access through peripherals. Leveraging the Intel vPro® platform, this device enhances data and asset security.

Expandable Flexibility

The Smart Cable offers cutting-edge device collaboration through convenient USB-A and USB-C® connections, accommodating all your peripherals, including laptops and tablets. Seamlessly share device control, data, and screen projection between devices with this intelligent feature, supporting high-speed USB-C® data transfers.

Environmentally Aware

This small form factor PC was crafted with a strong emphasis on recycling. Our commitment to sustainability is evident in the integration of recycled post-consumer content (PCC) into various components. The packaging is thoughtfully designed using a combination of recycled and sustainably sourced materials.

Specifications

Processor
Processor generation	Intel® Core™ i5 (14th gen)
Processor cache type	Smart Cache
Processor cache	24 MB
Processor model	i5-14500
Number of processors installed	1
Processor manufacturer	Intel
Processor boost frequency	5 GHz
Processor threads	20
Processor cores	14
Processor family	Intel® Core™ i5
Performance cores	6
Efficient cores	8
Performance-core base frequency	2.6 GHz
Efficient-core base frequency	1.9 GHz
Processor base power	65 W
Maximum turbo power	154 W
Efficient-core Max Turbo Frequency	3.7 GHz
Performance-core Max Turbo Frequency	5 GHz
Memory
Internal memory	32 GB
Memory layout (slots x size)	2 x 16 GB
Maximum internal memory	128 GB
Memory slots	4x DIMM
Internal memory type	DDR5-SDRAM
Memory clock speed	4400 MHz
Memory channels	Dual-channel
Storage
Storage media	SSD
Number of storage drives installed	1
Optical drive type	DVD±RW
SSD interface	PCI Express 4.0
SSD capacity	512 GB
Number of SSDs installed	1
Card reader integrated	No
Total storage capacity	512 GB
SSD form factor	M.2
Total SSDs capacity	512 GB
NVMe	Yes
Graphics
Discrete graphics card	No
On-board graphics card family	Intel® UHD Graphics
On-board graphics card	Yes
Discrete graphics card model	Not available
On-board graphics card model	Intel UHD Graphics 770
On-board GPU manufacturer	Intel
Optical drive
Optical drive type	DVD±RW
Network
Ethernet LAN	Yes
Wi-Fi	Yes
Bluetooth	Yes
Bluetooth version	5.3
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Ethernet LAN data rates	100,1000 Mbit/s
WLAN controller model	Intel Wi-Fi 6E AX211
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Antenna type	2x2
WLAN controller manufacturer	Intel
Ports & interfaces
Combo headphone/mic port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Thunderbolt 3 ports quantity	0
HDMI version	2.1
USB 2.0 ports quantity	0
Microphone in	Yes
Line-out	Yes
HDMI ports quantity	1
Ethernet LAN (RJ-45) ports	1
DisplayPorts quantity	3
Technical details
Cable lock slot type	Kensington
Product type	PC
Trusted Platform Module (TPM)	Yes
Product colour	Black
Chassis type	SFF
Audio system	High Definition Audio
Placement supported	Vertical
Cable lock slot	Yes
Motherboard chipset	Intel Q670
Sustainability certificates	GREENGUARD, TCO
Compliance certificates	RoHS
Design
Volume	8.2 L
Cable lock slot type	Kensington
Product colour	Black
Chassis type	SFF
Placement supported	Vertical
Cable lock slot	Yes
Colour name	Black
Performance
Audio chip	Realtek ALC897Q-CG
Number of speakers	1
Password protection	Yes
Password protection type	BIOS, HDD, Power on
Product type	PC
Trusted Platform Module (TPM)	Yes
Audio system	High Definition Audio
Built-in speaker(s)	Yes
Motherboard chipset	Intel Q670
Trusted Platform Module (TPM) version	2.0
Software
Operating system language	English
Operating system installed	Windows 11 Pro
Power
Power supply input frequency	50/60 Hz
Power supply input voltage	100 - 240 V
Power supply	310 W
Operational conditions
Operating altitude	0 - 120000" (0 - 3048 m)
Storage temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	20 - 80%
Storage relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	5 - 35 °C
Non-operating altitude	0 - 480000" (0 - 12192 m)
Certificates
Certification	MIL-STD-810H ENERGY STAR 8.0 EPEAT Gold Registered ErP Lot 3 GREENGUARD RoHS compliant TCO Certified 9.0
Compliance certificates	RoHS
Sustainability
Sustainability certificates	GREENGUARD, TCO
Weight & dimensions
Volume	8.2 L
Package width	7.68" (195 mm)
Package depth	15.6" (395 mm)
Package height	20.9" (530 mm)
Width	3.64" (92.5 mm)
Depth	11.7" (297.7 mm)
Height	13.4" (339.5 mm)
Package weight	16.8 lbs (7.6 kg)
Weight	11.7 lbs (5.3 kg)
Packaging data
Package width	7.68" (195 mm)
Package depth	15.6" (395 mm)
Package height	20.9" (530 mm)
Package weight	16.8 lbs (7.6 kg)
Packaging content
Mouse included	Yes
Display included	No
Keyboard included	Yes
Mouse connectivity	Wired
Keyboard connectivity	Wired
Other features
Number of speakers	1
Trusted Platform Module (TPM)	Yes
On-board graphics card	Yes
Processor manufacturer	Intel
Built-in speaker(s)	Yes
